源码剖析：探究 Repeat 中 GCD 的应用

作者 | Dylan_王兴彬

简介

Repeat 是 Daniele 开发的一个基于 GCD - Grand Central Dispatch 的轻量定时器，可用于替代 NSTimer，解决其多项不足。

特性

Daniel 着重强调的一些特性：

• 接口简洁明了不冗余

• 避免强引用，解决潜在的内存泄露问题

• 支持注册多个观察者对象监听定时器

• 支持暂停、开始、恢复、重置等操作

• 支持设置多种重复模式

• infinite：无限定时重复
• finite：有限次定时重复
• once：单次定时执行

针对以上特性，我们接下来阅读源码时可以着重看看 Daniel 是怎样实现的。

另外，这个库还扩展提供了两个有趣的特性：

• Debouncer: 防抖动，避免方法调用过于密集，总是执行每隔一定时间段内最后一个调用。

• Throttler: 节流阀，确保每隔一定时间段内仅执行一次，并忽略其他调用。

这两个特性对于用过 RxSwift 的开发者肯定不陌生，有了定时器，实现这两者也是顺理成章。

接口的设计、使用与实现

首先，从接口的设计来看看其是否「简洁明了」、「不冗余」，再逐步深入其内部实现。

定时器

注意：Repeater 被设计成和其他许多对象一样，需要被持有来避免被释放。

创建单次定时器

• 接口设计与调用

// 创建单次执行定时器
log("当时只道是寻常")
self.timer = Repeater.once(after: .seconds(5)) { timer in
    // 5s 后运行
    log("岁月如歌,简单爱一次")
}

输出：

2019-10-14 15:12:04 +0000: 当时只道是寻常
2019-10-14 15:12:09 +0000: 岁月如歌,简单爱一次

• 单元测试设计

func test_timer_once() {
  let exp = expectation(description: "test_once")

  let timer = Repeater.once(after: .seconds(5)) { _ in
    exp.fulfill()
  }

  print("Allocated timer \(timer)")
  wait(for: [exp], timeout: 6)
}

创建有限次重复的定时器

• 接口设计与调用

log("当时只道是寻常")
self.timer = Repeater.every(.seconds(10), count: 5) { timer in
    // 每 10s 运行 1 次，5 次后结束
    log("岁月如歌,简单爱一次")
}

输出：

2019-10-14 15:18:56 +0000: 当时只道是寻常
2019-10-14 15:19:06 +0000: 岁月如歌,简单爱一次
2019-10-14 15:19:16 +0000: 岁月如歌,简单爱一次
2019-10-14 15:19:26 +0000: 岁月如歌,简单爱一次
2019-10-14 15:19:36 +0000: 岁月如歌,简单爱一次
2019-10-14 15:19:46 +0000: 岁月如歌,简单爱一次

• 单元测试设计

func test_timer_finiteAndRestart() {
  let exp = expectation(description: "test_finiteAndRestart")

  var count: Int = 0
  var finishedFirstTime: Bool = false
  let timer = Repeater(interval: .seconds(0.5), mode: .finite(5)) { _ in
    count += 1
    print("Iteration #\(count)")
  }
  timer.onStateChanged = { (_, state) in
    print("State changed: \(state)")
    if state.isFinished {
      if finishedFirstTime == false {
        print("Now restart")
        timer.start()
        finishedFirstTime = true
      } else {
        exp.fulfill()
      }
    }
  }

  timer.start()

  wait(for: [exp], timeout: 30)
}

单元测试输出：

State changed: running
State changed: executing
Iteration #1
State changed: executing
Iteration #2
State changed: executing
Iteration #3
State changed: executing
Iteration #4
State changed: executing
Iteration #5
State changed: finished
Now restart
State changed: idle/paused
State changed: running
State changed: executing
Iteration #6
State changed: executing
Iteration #7
State changed: executing
Iteration #8
State changed: executing
Iteration #9
State changed: executing
Iteration #10
State changed: finished

可以看到，有限次的定时器在次数达到结束后，还可以继续调用 start() 重新开始再次复用，而不必另外创建新实例。

创建无限重复定时器

• 接口设计与调用

log("当时只道是寻常")
let timer = Repeater.every(.seconds(5)) { timer in
    // 每 5s 运行一次，直到 timer 生命周期结束
    log("岁月如歌,简单爱一次")
}

输出：

2019-10-14 15:24:05 +0000: 当时只道是寻常
2019-10-14 15:24:10 +0000: 岁月如歌,简单爱一次
2019-10-14 15:24:15 +0000: 岁月如歌,简单爱一次
2019-10-14 15:24:20 +0000: 岁月如歌,简单爱一次
2019-10-14 15:24:25 +0000: 岁月如歌,简单爱一次
2019-10-14 15:24:30 +0000: 岁月如歌,简单爱一次
2019-10-14 15:24:35 +0000: 岁月如歌,简单爱一次
2019-10-14 15:24:40 +0000: 岁月如歌,简单爱一次
2019-10-14 15:24:45 +0000: 岁月如歌,简单爱一次
...

• 单元测试设计

func test_timer_infinite() {
  let exp = expectation(description: "test_once")

  var count: Int = 0
  let timer = Repeater.every(.seconds(0.5), { _ in
    count += 1
    if count == 20 {
      exp.fulfill()
    }
  })

  print("Allocated timer \(timer)")
  wait(for: [exp], timeout: 10)
}

手动管理计时器

• 接口设计与调用

log("当时只道是寻常")
self.timer = Repeater(interval: .seconds(5), mode: .infinite) { _ in
    // 每 5s 运行一次，直到 timer 生命周期结束
    log("岁月如歌,简单爱一次")
}
timer.start()

输出：

2019-10-14 23:13:46 +0000: 当时只道是寻常
2019-10-14 23:13:51 +0000: 岁月如歌,简单爱一次
2019-10-14 23:13:56 +0000: 岁月如歌,简单爱一次
2019-10-14 23:14:01 +0000: 岁月如歌,简单爱一次
2019-10-14 23:14:06 +0000: 岁月如歌,简单爱一次
2019-10-14 23:14:11 +0000: 岁月如歌,简单爱一次
2019-10-14 23:14:16 +0000: 岁月如歌,简单爱一次
2019-10-14 23:14:21 +0000: 岁月如歌,简单爱一次
2019-10-14 23:14:26 +0000: 岁月如歌,简单爱一次
...

其他方法：

• start(): 开始一个已暂停或新创建的定时器

• pause()：暂停一个正在运行的定时器

• reset(_ interval: Interval, restart: Bool)：重置一个正在运行的定时器，更改时间间隔并重新开始

• fire()：额外手动调用一次定时器绑定事件

属性：

• .mode：定时器类型模式

infinite：无限定时重复
finite：有限次定时重复
once：单次定时执行

• .remainingIterations：针对 .finite 有限次重复模式结束前的剩余迭代次数

添加或移除多个定时处理

一般而言，初始化定时器时会指定一个处理方法。除此之外， Repeat 的定时器还支持通过observe()额外添加处理方法，并且支持通过token再移除。

// 添加额外的处理监听
let token = timber.observe { _ in
    // 额外的新处理
  log("一个闹钟能够同时叫醒相爱的两个人。")
}
timer.start()

// 移除
timer.remove(token)

观察定时器的状态变化

每个定时器维护着一个状态机，处在以下某个状态：

• .paused：空闲（未被开始过）或已暂停

• .running：正在计时中

• .executing：注册的定时处理方法正在执行

• .finished：计时结束

可以通过.onStateChanged属性添加状态变化回调监听：

timer.onStateChanged = { timer, newState in
    // 观察定时器状态变化并做相应处理
    log("你永远叫不醒一个装睡的人")
}

防抖动器

TBD

节流阀

TBD

源码探究

接下来，进一步看看以上的接口都是如何实现的吧。

文件目录结构

.
├── CHANGELOG.md
├── Configs
│   ├── Repeat.plist
│   └── RepeatTests.plist
├── LICENSE
├── Package.swift
├── README.md
├── Repeat.podspec
├── Repeat.xcodeproj
├── Sources
│   └── Repeat
│       ├── Debouncer.swift
│       ├── Repeater.swift
│       └── Throttler.swift
└── Tests
    ├── LinuxMain.swift
    └── RepeatTests
        └── RepeatTests.swift

主要文件：

• Sources/Repeat/Repeater.swift：核心定时器实现

• Sources/Repeat/Debouncer.swift：扩展「防抖动器」实现

• Sources/Repeat/Throttler.swift：扩展「节流阀」实现

• Tests/RepeatTests/RepeatTests.swift：单元测试

类图与方法概览

工厂类方法实现以及与 Timer 的异同

在接口设计与使用中可以看到，Repeater 提供了便捷工厂类方法，并且生成的定时器都会「自动开始」，与 Timer 的工厂类方法相似：

/// Alternative API for timer creation with a block.
/// - Experiment: This is a draft API currently under consideration for official import into Foundation as a suitable alternative to creation via selector
/// - Note: Since this API is under consideration it may be either removed or revised in the near future
/// - Warning: Capturing the timer or the owner of the timer inside of the block may cause retain cycles. Use with caution
open class func scheduledTimer(withTimeInterval interval: TimeInterval,
                               repeats: Bool,
                               block: @escaping (Timer) -> Void) -> Timer {
    let timer = Timer(fire: Date(timeIntervalSinceNow: interval), interval: interval, repeats: repeats, block: block)
    CFRunLoopAddTimer(CFRunLoopGetCurrent(), timer._timer!, kCFRunLoopDefaultMode)
    return timer
}

Tips & Declaration：Timer.swift，注释中有特别提醒注意循环引用的问题。

对比一下 Repeater 的类工厂方法实现：

/// Create and schedule a timer that will call `handler` once after the specified time.
///
/// - Parameters:
///   - interval: interval delay for single fire
///   - queue: destination queue, if `nil` a new `DispatchQueue` is created automatically.
///   - observer: handler to call when timer fires.
/// - Returns: timer instance
@discardableResult
public class func once(after interval: Interval,
                       tolerance: DispatchTimeInterval = .nanoseconds(0),
                       queue: DispatchQueue? = nil,
                       _ observer: @escaping Observer) -> Repeater {
      let timer = Repeater(interval: interval, mode: .once, tolerance: tolerance, queue: queue, observer: observer)
  timer.start()
  return timer
}

/// Create and schedule a timer that will fire every interval optionally by limiting the number of fires.
///
/// - Parameters:
///   - interval: interval of fire
///   - count: a non `nil` and > 0  value to limit the number of fire, `nil` to set it as infinite.
///   - queue: destination queue, if `nil` a new `DispatchQueue` is created automatically.
///   - handler: handler to call on fire
/// - Returns: timer
@discardableResult
public class func every(_ interval: Interval,
                        count: Int? = nil,
                        tolerance: DispatchTimeInterval = .nanoseconds(0),
                        queue: DispatchQueue? = nil,
                        _ handler: @escaping Observer) -> Repeater {
  let mode: Mode = (count != nil ? .finite(count!) : .infinite)
      let timer = Repeater(interval: interval, mode: mode, tolerance: tolerance, queue: queue, observer: handler)
  timer.start()
  return timer
}

两者的做法大相径庭，都是创建一个定时器实例并「自动开始」，只是开始的方式由于内部固有的实现方式有所不同：

• Timer 依赖 RunLoop，需要将创建定时器生成的 CFRunLoopTimer 加入当前 Runloop

• Repeater 依赖 GCD 的 DispatchSourceTimer，start 内部会调 DispatchSourceTimer 的 实例方法resume

初始化方法

/// Initialize a new timer.
///
/// - Parameters:
///   - interval: interval of the timer
///   - mode: mode of the timer
///   - tolerance: tolerance of the timer, 0 is default.
///   - queue: queue in which the timer should be executed; if `nil` a new queue is created automatically.
///   - observer: observer
public init(interval: Interval, mode: Mode = .infinite, tolerance: DispatchTimeInterval = .nanoseconds(0), queue: DispatchQueue? = nil, observer: @escaping Observer) {
  self.mode = mode
  self.interval = interval
  self.tolerance = tolerance
  self.remainingIterations = mode.countIterations
  self.queue = (queue ?? DispatchQueue(label: "com.repeat.queue"))
  self.timer = configureTimer()
  self.observe(observer)
}

初始化方法参数列表：

• interval：定时器时间间隔

• mode：定时器重复模式，默认为.infinite，无限重复

• tolerance：容许误差（这个最终是作为DispatchSourceTimer的leeway参数）

• queue：指定定时器运行的队列，若未指定，则自动创建默认队列

• observer：定时器运行的回调方法

创建并配置 DispatchSourceTimer

private func configureTimer() -> DispatchSourceTimer {
  let associatedQueue = (queue ?? DispatchQueue(label: "com.repeat.\(NSUUID().uuidString)"))
  let timer = DispatchSource.makeTimerSource(queue: associatedQueue)
  let repeatInterval = interval.value
  let deadline: DispatchTime = (DispatchTime.now() + repeatInterval)
  if self.mode.isRepeating {
    timer.schedule(deadline: deadline, repeating: repeatInterval, leeway: tolerance)
  } else {
    timer.schedule(deadline: deadline, leeway: tolerance)
  }

  timer.setEventHandler { [weak self] in
    if let unwrapped = self {
      unwrapped.timeFired()
    }
  }
  return timer
}

• 根据初始化传入的参数，初始化并配置一个 DispatchSourceTimer

• 将 DispatchSourceTimer 的处理回调通过timeFired方法处理

这一段代码是 Repeat 中 GCD 的应用关键，Repeat 的核心计时器即是 DispatchSourceTimer，进一步封装并屏蔽部分复杂逻辑，以提供简洁易用的接口。

计时器启动、暂停与重置

/// Reset the state of the timer, optionally changing the fire interval.
///
/// - Parameters:
///   - interval: new fire interval; pass `nil` to keep the latest interval set.
///   - restart: `true` to automatically restart the timer, `false` to keep it stopped after configuration.
public func reset(_ interval: Interval?, restart: Bool = true) {
  if self.state.isRunning {
    self.setPause(from: self.state)
  }

  // For finite counter we want to also reset the repeat count
  if case .finite(let count) = self.mode {
    self.remainingIterations = count
  }

  // Create a new instance of timer configured
  if let newInterval = interval {
    self.interval = newInterval
  } // update interval
  self.destroyTimer()
  self.timer = configureTimer()
  self.state = .paused

  if restart {
    self.timer?.resume()
    self.state = .running
  }
}

/// Start timer. If timer is already running it does nothing.
@discardableResult
public func start() -> Bool {
  guard self.state.isRunning == false else {
    return false
  }

  // If timer has not finished its lifetime we want simply
  // restart it from the current state.
  guard self.state.isFinished == true else {
    self.state = .running
    self.timer?.resume()
    return true
  }

  // Otherwise we need to reset the state based upon the mode
  // and start it again.
  self.reset(nil, restart: true)
  return true
}

/// Pause a running timer. If timer is paused it does nothing.
@discardableResult
public func pause() -> Bool {
  guard state != .paused && state != .finished else {
    return false
  }

  return self.setPause(from: self.state)
}

/// Pause a running timer optionally changing the state with regard to the current state.
///
/// - Parameters:
///   - from: the state which the timer should only be paused if it is the current state
///   - to: the new state to change to if the timer is paused
/// - Returns: `true` if timer is paused
@discardableResult
private func setPause(from currentState: State, to newState: State = .paused) -> Bool {
  guard self.state == currentState else {
    return false
  }

  self.timer?.suspend()
  self.state = newState

  return true
}

• start方法主要是做状态判断并进行相应处理返回结果，其开始计时的核心是调用内部 DispatchSourceTimer 的 resume 方法

• pause 方法类似，调用的是 suspend 方法，并更新内部计时器状态

• reset 重置内部的一些计时标志位的同时，会将内部的 DispatchSourceTimer 销毁并新建

添加或移除多个定时观察者

/// List of the observer of the timer
private var observers = [ObserverToken: Observer]()

/// Next token of the timer
private var nextObserverID: UInt64 = 0

/// Add new a listener to the timer.
///
/// - Parameter callback: callback to call for fire events.
/// - Returns: token used to remove the handler
@discardableResult
public func observe(_ observer: @escaping Observer) -> ObserverToken {
  var (new, overflow) = self.nextObserverID.addingReportingOverflow(1)
  if overflow { // you need to add an incredible number of offset...sure you can't
    self.nextObserverID = 0
    new = 0
  }
  self.nextObserverID = new
  self.observers[new] = observer
  return new
}

/// Remove an observer of the timer.
///
/// - Parameter id: id of the observer to remove
public func remove(observer identifier: ObserverToken) {
  self.observers.removeValue(forKey: identifier)
}

• 通过字典储存观察者回调事件，通过 UInt64 的 ObserverToken 来进行标识

• 观察者数量上限控制在 UInt64 的溢出范围

定时事件触发

/// Called when timer is fired
private func timeFired() {
  self.state = .executing

  if case .finite = self.mode {
    self.remainingIterations! -= 1
  }

  // dispatch to observers
  self.observers.values.forEach { $0(self) }

  // manage lifetime
  switch self.mode {
  case .once:
    // once timer's lifetime is finished after the first fire
    // you can reset it by calling `reset()` function.
    self.setPause(from: .executing, to: .finished)
  case .finite:
    // for finite intervals we decrement the left iterations count...
    if self.remainingIterations! == 0 {
      // ...if left count is zero we just pause the timer and stop
      self.setPause(from: .executing, to: .finished)
    }
  case .infinite:
    // infinite timer does nothing special on the state machine
    break
  }

}

• timeFired 方法被两个地方调用，一个是配置DispatchSourceTimer时设置的事件回调，一个是对外暴露的手动触发方法 fire(andPause:) 中

• 根据计时模式更新计时器状态，计时模式的实现核心逻辑即在于此 遍历所有观察者逐个回调，触发真正的计时器绑定事件

总结

致谢与参考

文中涉及源码大部分来自开源社区，以及部分其他文献参考。

•Repeat by Daniele Margutti, under The MIT License (MIT) https://github.com/malcommac/Repeat

• swift-corelibs-foundation Licensed under Apache License v2.0 with Runtime Library Exception https://github.com/apple/swift-corelibs-foundation

• A Background Repeating Timer in Swift by Daniel Galasko https://medium.com/over-engineering/a-background-repeating-timer-in-swift-412cecfd2ef9
