Java 如何实现二维码？

来源：http://suo.im/5R6ewH

步骤1

第一步首先创建一个普通的 Maven 项目，然后要实现二维码功能，我们肯定要使用别人提供好的 Jar 包，这里我用的是 google 提供的 jar，pom.xml 文件配置如下：

<?xml version="1.0" encoding="UTF-8"?>
<project xmlns="http://maven.apache.org/POM/4.0.0"
         xmlns:xsi="http://www.w3.org/2001/XMLSchema-instance"
         xsi:schemaLocation="http://maven.apache.org/POM/4.0.0 http://maven.apache.org/xsd/maven-4.0.0.xsd">
    <modelVersion>4.0.0</modelVersion>

    <groupId>org.javaboy</groupId>
    <artifactId>QRCode</artifactId>
    <version>1.0-SNAPSHOT</version>


    <dependencies>
        <!-- 添加 google 提供的二维码依赖 -->
        <dependency>
            <groupId>com.google.zxing</groupId>
            <artifactId>core</artifactId>
            <version>3.3.0</version>
        </dependency>
    </dependencies>

</project>

步骤2

然后使用 google 提供的工具类，在项目根目录下创建一个 util 包，将所需要的工具类放进去。

工具类1 (BufferedImageLuminanceSource)

不废话，直接上代码

/**
 * @author bai <br/>
 * @date 2020/7/1 9:27<br/>
 */
public class BufferedImageLuminanceSource extends LuminanceSource {

    private final BufferedImage image;
    private final int left;
    private final int top;

    public BufferedImageLuminanceSource(BufferedImage image) {
        this(image, 0, 0, image.getWidth(), image.getHeight());
    }

    public BufferedImageLuminanceSource(BufferedImage image, int left, int top, int width, int height) {
        super(width, height);

        int sourceWidth = image.getWidth();
        int sourceHeight = image.getHeight();
        if (left + width > sourceWidth || top + height > sourceHeight) {
            throw new IllegalArgumentException("Crop rectangle does not fit within image data.");
        }

        for (int y = top; y < top + height; y++) {
            for (int x = left; x < left + width; x++) {
                if ((image.getRGB(x, y) & 0xFF000000) == 0) {
                    image.setRGB(x, y, 0xFFFFFFFF); // = white
                }
            }
        }

        this.image = new BufferedImage(sourceWidth, sourceHeight, BufferedImage.TYPE_BYTE_GRAY);
        this.image.getGraphics().drawImage(image, 0, 0, null);
        this.left = left;
        this.top = top;
    }

    @Override
    public byte[] getRow(int y, byte[] row) {
        if (y < 0 || y >= getHeight()) {
            throw new IllegalArgumentException("Requested row is outside the image: " + y);
        }
        int width = getWidth();
        if (row == null || row.length < width) {
            row = new byte[width];
        }
        image.getRaster().getDataElements(left, top + y, width, 1, row);
        return row;
    }

    @Override
    public byte[] getMatrix() {
        int width = getWidth();
        int height = getHeight();
        int area = width * height;
        byte[] matrix = new byte[area];
        image.getRaster().getDataElements(left, top, width, height, matrix);
        return matrix;
    }

    @Override
    public boolean isCropSupported() {
        return true;
    }

    @Override
    public LuminanceSource crop(int left, int top, int width, int height) {
        return new BufferedImageLuminanceSource(image, this.left + left, this.top + top, width, height);
    }

    @Override
    public boolean isRotateSupported() {
        return true;
    }

    @Override
    public LuminanceSource rotateCounterClockwise() {
        int sourceWidth = image.getWidth();
        int sourceHeight = image.getHeight();
        AffineTransform transform = new AffineTransform(0.0, -1.0, 1.0, 0.0, 0.0, sourceWidth);
        BufferedImage rotatedImage = new BufferedImage(sourceHeight, sourceWidth, BufferedImage.TYPE_BYTE_GRAY);
        Graphics2D g = rotatedImage.createGraphics();
        g.drawImage(image, transform, null);
        g.dispose();
        int width = getWidth();
        return new BufferedImageLuminanceSource(rotatedImage, top, sourceWidth - (left + width), getHeight(), width);
    }

}

工具类2 (QRCodeUtil)

这里面可以修改一些参数，例如二维码的尺寸，宽高等等。

/**
 * @author bai <br/>
 * @date 2020/7/1 9:29<br/>
 */
public class QRCodeUtil {
    private static final String CHARSET = "utf-8";
    private static final String FORMAT_NAME = "JPG";
    // 二维码尺寸
    private static final int QRCODE_SIZE = 300;
    // LOGO宽度
    private static final int WIDTH = 60;
    // LOGO高度
    private static final int HEIGHT = 60;

    private static BufferedImage createImage(String content, String imgPath, boolean needCompress) throws Exception {
        Hashtable hints = new Hashtable();
        hints.put(EncodeHintType.ERROR_CORRECTION, ErrorCorrectionLevel.H);
        hints.put(EncodeHintType.CHARACTER_SET, CHARSET);
        hints.put(EncodeHintType.MARGIN, 1);
        BitMatrix bitMatrix = new MultiFormatWriter().encode(content, BarcodeFormat.QR_CODE, QRCODE_SIZE, QRCODE_SIZE,
                hints);
        int width = bitMatrix.getWidth();
        int height = bitMatrix.getHeight();
        BufferedImage image = new BufferedImage(width, height, BufferedImage.TYPE_INT_RGB);
        for (int x = 0; x < width; x++) {
            for (int y = 0; y < height; y++) {
                image.setRGB(x, y, bitMatrix.get(x, y) ? 0xFF000000 : 0xFFFFFFFF);
            }
        }
        if (imgPath == null || "".equals(imgPath)) {
            return image;
        }
        // 插入图片
        QRCodeUtil.insertImage(image, imgPath, needCompress);
        return image;
    }

    private static void insertImage(BufferedImage source, String imgPath, boolean needCompress) throws Exception {
        File file = new File(imgPath);
        if (!file.exists()) {
            System.err.println("" + imgPath + " 该文件不存在！");
            return;
        }
        Image src = ImageIO.read(new File(imgPath));
        int width = src.getWidth(null);
        int height = src.getHeight(null);
        if (needCompress) { // 压缩LOGO
            if (width > WIDTH) {
                width = WIDTH;
            }
            if (height > HEIGHT) {
                height = HEIGHT;
            }
            Image image = src.getScaledInstance(width, height, Image.SCALE_SMOOTH);
            BufferedImage tag = new BufferedImage(width, height, BufferedImage.TYPE_INT_RGB);
            Graphics g = tag.getGraphics();
            g.drawImage(image, 0, 0, null); // 绘制缩小后的图
            g.dispose();
            src = image;
        }
        // 插入LOGO
        Graphics2D graph = source.createGraphics();
        int x = (QRCODE_SIZE - width) / 2;
        int y = (QRCODE_SIZE - height) / 2;
        graph.drawImage(src, x, y, width, height, null);
        Shape shape = new RoundRectangle2D.Float(x, y, width, width, 6, 6);
        graph.setStroke(new BasicStroke(3f));
        graph.draw(shape);
        graph.dispose();
    }

    public static void encode(String content, String imgPath, String destPath, boolean needCompress) throws Exception {
        BufferedImage image = QRCodeUtil.createImage(content, imgPath, needCompress);
        mkdirs(destPath);
        // String file = new Random().nextInt(99999999)+".jpg";
        // ImageIO.write(image, FORMAT_NAME, new File(destPath+"/"+file));
        ImageIO.write(image, FORMAT_NAME, new File(destPath));
    }

    public static BufferedImage encode(String content, String imgPath, boolean needCompress) throws Exception {
        BufferedImage image = QRCodeUtil.createImage(content, imgPath, needCompress);
        return image;
    }

    public static void mkdirs(String destPath) {
        File file = new File(destPath);
        // 当文件夹不存在时，mkdirs会自动创建多层目录，区别于mkdir．(mkdir如果父目录不存在则会抛出异常)
        if (!file.exists() && !file.isDirectory()) {
            file.mkdirs();
        }
    }

    public static void encode(String content, String imgPath, String destPath) throws Exception {
        QRCodeUtil.encode(content, imgPath, destPath, false);
    }
    // 被注释的方法
    /*
     * public static void encode(String content, String destPath, boolean
     * needCompress) throws Exception { QRCodeUtil.encode(content, null, destPath,
     * needCompress); }
     */

    public static void encode(String content, String destPath) throws Exception {
        QRCodeUtil.encode(content, null, destPath, false);
    }

    public static void encode(String content, String imgPath, OutputStream output, boolean needCompress)
            throws Exception {
        BufferedImage image = QRCodeUtil.createImage(content, imgPath, needCompress);
        ImageIO.write(image, FORMAT_NAME, output);
    }

    public static void encode(String content, OutputStream output) throws Exception {
        QRCodeUtil.encode(content, null, output, false);
    }

    public static String decode(File file) throws Exception {
        BufferedImage image;
        image = ImageIO.read(file);
        if (image == null) {
            return null;
        }
        BufferedImageLuminanceSource source = new BufferedImageLuminanceSource(image);
        BinaryBitmap bitmap = new BinaryBitmap(new HybridBinarizer(source));
        Result result;
        Hashtable hints = new Hashtable();
        hints.put(DecodeHintType.CHARACTER_SET, CHARSET);
        result = new MultiFormatReader().decode(bitmap, hints);
        String resultStr = result.getText();
        return resultStr;
    }

    public static String decode(String path) throws Exception {
        return QRCodeUtil.decode(new File(path));
    }

}

启动类

这一步就是调用方法，一般大家使用这种功能都是为了实现业务，例如常见的扫描二维码跳转链接（页面），扫描二维码出现文字等等。有些二维码中间还带有 Logo 这种图片，将需要嵌入二维码的图片路径准备好就没有问题。

/**
 * @author bai <br/>
 * @date 2020/7/1 9:31<br/>
 */
public class QRCodeApplication {
    public static void main(String[] args) throws Exception {
        // 存放在二维码中的内容
        // 二维码中的内容可以是文字，可以是链接等
        String text = "http://www.baidu.com";
        // 嵌入二维码的图片路径
        //String imgPath = "C:\\Users\\Administrator\\Pictures\\img\\dog.jpg";
        // 生成的二维码的路径及名称
        String destPath = "C:\\Users\\bai\\Pictures\\img\\code" + System.currentTimeMillis() + ".jpg";
        //生成二维码
        QRCodeUtil.encode(text, null, destPath, true);
        // 解析二维码
        String str = QRCodeUtil.decode(destPath);
        // 打印出解析出的内容
        System.out.println(str);
    }
}

效果截图

源码奉上

码云：https://gitee.com/jian_bo_bai/QRCode
