通过/proc文件系统探究虚拟内存 我们会通过/proc文件系统找到正在运行的进程的字符串所在的虚拟内存地址，并通过更改此内存地址的内容来更改字符串内容，使你更深入了解虚拟内存这个概念！这之前先介绍下虚拟内存的定义！
虚拟内存
虚拟内存是一种实现在计算机软硬件之间的内存管理技术，它将程序使用到的内存地址(虚拟地址)映射到计算机内存中的物理地址，虚拟内存使得应用程序从繁琐的管理内存空间任务中解放出来，提高了内存隔离带来的安全性，虚拟内存地址通常是连续的地址空间，由操作系统的内存管理模块控制，在触发缺页中断时利用分页技术将实际的物理内存分配给虚拟内存，而且64位机器虚拟内存的空间大小远超出实际物理内存的大小，使得进程可以使用比物理内存大小更多的内存空间。
在深入研究虚拟内存前，有几个关键点：
上图并不是特别详细的内存管理图，高地址其实还有内核空间等等，但这不是这篇文章的主题。从图中可以看到高地址存储着命令行参数和环境变量，之后是栈空间、堆空间和可执行程序，其中栈空间向下延申，堆空间向上增长，堆空间需要使用malloc分配，是动态分配的内存的一部分。
首先通过一个简单的C程序探究虚拟内存。
#include <stdlib.h>
#include <stdio.h>
#include <string.h>
/**
* main - 使用strdup创建一个字符串的拷贝，strdup内部会使用malloc分配空间，
* 返回新空间的地址，这段地址空间需要外部自行使用free释放
*
* Return: EXIT_FAILURE if malloc failed. Otherwise EXIT_SUCCESS
*/
int main(void)
{
char *s;
s = strdup("test_memory");
if (s == NULL)
{
fprintf(stderr, "Can't allocate mem with malloc\n");
return (EXIT_FAILURE);
}
printf("%p\n", (void *)s);
return (EXIT_SUCCESS);
}
编译运行：gcc -Wall -Wextra -pedantic -Werror main.c -o test; ./test
输出：0x88f010我的机器是64位机器，进程的虚拟内存高地址为0xffffffffffffffff， 低地址为0x0，而0x88f010远小于0xffffffffffffffff，因此大概可以推断出被复制的字符串的地址(堆地址)是在内存低地址附近，具体可以通过/proc文件系统验证. ls /proc目录可以看到好多文件，这里主要关注/proc/[pid]/mem和/proc/[pid]/maps
man proc
/proc/[pid]/mem
This file can be used to access the pages of a process's memory through open(2), read(2), and lseek(2).
/proc/[pid]/maps
A file containing the currently mapped memory regions and their access permissions.
See mmap(2) for some further information about memory mappings.
The format of the file is:
address perms offset dev inode pathname
00400000-00452000 r-xp 00000000 08:02 173521 /usr/bin/dbus-daemon
00651000-00652000 r--p 00051000 08:02 173521 /usr/bin/dbus-daemon
00652000-00655000 rw-p 00052000 08:02 173521 /usr/bin/dbus-daemon
00e03000-00e24000 rw-p 00000000 00:00 0 [heap]
00e24000-011f7000 rw-p 00000000 00:00 0 [heap]
...
35b1800000-35b1820000 r-xp 00000000 08:02 135522 /usr/lib64/ld-2.15.so
35b1a1f000-35b1a20000 r--p 0001f000 08:02 135522 /usr/lib64/ld-2.15.so
35b1a20000-35b1a21000 rw-p 00020000 08:02 135522 /usr/lib64/ld-2.15.so
35b1a21000-35b1a22000 rw-p 00000000 00:00 0
35b1c00000-35b1dac000 r-xp 00000000 08:02 135870 /usr/lib64/libc-2.15.so
35b1dac000-35b1fac000 ---p 001ac000 08:02 135870 /usr/lib64/libc-2.15.so
35b1fac000-35b1fb0000 r--p 001ac000 08:02 135870 /usr/lib64/libc-2.15.so
35b1fb0000-35b1fb2000 rw-p 001b0000 08:02 135870 /usr/lib64/libc-2.15.so
...
f2c6ff8c000-7f2c7078c000 rw-p 00000000 00:00 0 [stack:986]
...
7fffb2c0d000-7fffb2c2e000 rw-p 00000000 00:00 0 [stack]
7fffb2d48000-7fffb2d49000 r-xp 00000000 00:00 0 [vdso]
The address field is the address space in the process that the mapping occupies.
The perms field is a set of permissions:
r = read
w = write
x = execute
s = shared
p = private (copy on write)
The offset field is the offset into the file/whatever;
dev is the device (major:minor); inode is the inode on that device. 0 indicates
that no inode is associated with the memory region,
as would be the case with BSS (uninitialized data).
The pathname field will usually be the file that is backing the mapping.
For ELF files, you can easily coordinate with the offset field
by looking at the Offset field in the ELF program headers (readelf -l).
There are additional helpful pseudo-paths:
[stack]
The initial process's (also known as the main thread's) stack.
[stack:<tid>] (since Linux 3.4)
A thread's stack (where the <tid> is a thread ID).
It corresponds to the /proc/[pid]/task/[tid]/ path.
[vdso] The virtual dynamically linked shared object.
[heap] The process's heap.
If the pathname field is blank, this is an anonymous mapping as obtained via the mmap(2) function.
There is no easy way to coordinate
this back to a process's source, short of running it through gdb(1), strace(1), or similar.
Under Linux 2.0 there is no field giving pathname.通过mem文件可以访问和修改整个进程的内存页，通过maps可以看到进程当前已映射的内存区域，有地址和访问权限偏移量等，从maps中可以看到堆空间是在低地址而栈空间是在高地址. 从maps中可以看到heap的访问权限是rw，即可写，所以可以通过堆地址找到上个示例程序中字符串的地址，并通过修改mem文件对应地址的内容，就可以修改字符串的内容啦，程序：
#include <stdlib.h>
#include <stdio.h>
#include <string.h>
#include <unistd.h>
/**
* main - uses strdup to create a new string, loops forever-ever
*
* Return: EXIT_FAILURE if malloc failed. Other never returns
*/
int main(void)
{
char *s;
unsigned long int i;
s = strdup("test_memory");
if (s == NULL)
{
fprintf(stderr, "Can't allocate mem with malloc\n");
return (EXIT_FAILURE);
}
i = 0;
while (s)
{
printf("[%lu] %s (%p)\n", i, s, (void *)s);
sleep(1);
i++;
}
return (EXIT_SUCCESS);
}
编译运行：gcc -Wall -Wextra -pedantic -Werror main.c -o loop; ./loop
输出：
[0] test_memory (0x21dc010)
[1] test_memory (0x21dc010)
[2] test_memory (0x21dc010)
[3] test_memory (0x21dc010)
[4] test_memory (0x21dc010)
[5] test_memory (0x21dc010)
[6] test_memory (0x21dc010)
...
这里可以写一个脚本通过/proc文件系统找到字符串所在位置并修改其内容，相应的输出也会更改。
首先找到进程的进程号
ps aux | grep ./loop | grep -v grep
zjucad 2542 0.0 0.0 4352 636 pts/3 S+ 12:28 0:00 ./loop2542即为loop程序的进程号，cat /proc/2542/maps得到
00400000-00401000 r-xp 00000000 08:01 811716 /home/zjucad/wangzhiqiang/loop
00600000-00601000 r--p 00000000 08:01 811716 /home/zjucad/wangzhiqiang/loop
00601000-00602000 rw-p 00001000 08:01 811716 /home/zjucad/wangzhiqiang/loop
021dc000-021fd000 rw-p 00000000 00:00 0 [heap]
7f2adae2a000-7f2adafea000 r-xp 00000000 08:01 8661324 /lib/x86_64-linux-gnu/libc-2.23.so
7f2adafea000-7f2adb1ea000 ---p 001c0000 08:01 8661324 /lib/x86_64-linux-gnu/libc-2.23.so
7f2adb1ea000-7f2adb1ee000 r--p 001c0000 08:01 8661324 /lib/x86_64-linux-gnu/libc-2.23.so
7f2adb1ee000-7f2adb1f0000 rw-p 001c4000 08:01 8661324 /lib/x86_64-linux-gnu/libc-2.23.so
7f2adb1f0000-7f2adb1f4000 rw-p 00000000 00:00 0
7f2adb1f4000-7f2adb21a000 r-xp 00000000 08:01 8661310 /lib/x86_64-linux-gnu/ld-2.23.so
7f2adb3fa000-7f2adb3fd000 rw-p 00000000 00:00 0
7f2adb419000-7f2adb41a000 r--p 00025000 08:01 8661310 /lib/x86_64-linux-gnu/ld-2.23.so
7f2adb41a000-7f2adb41b000 rw-p 00026000 08:01 8661310 /lib/x86_64-linux-gnu/ld-2.23.so
7f2adb41b000-7f2adb41c000 rw-p 00000000 00:00 0
7ffd51bb3000-7ffd51bd4000 rw-p 00000000 00:00 0 [stack]
7ffd51bdd000-7ffd51be0000 r--p 00000000 00:00 0 [vvar]
7ffd51be0000-7ffd51be2000 r-xp 00000000 00:00 0 [vdso]
ffffffffff600000-ffffffffff601000 r-xp 00000000 00:00 0 [vsyscall]看见堆地址范围021dc000-021fd000，并且可读可写，而且021dc000<0x21dc010<021fd000，这就可以确认字符串的地址在堆中，在堆中的索引是0x10(至于为什么是0x10，后面会讲到)，这时可以通过mem文件到0x21dc010地址修改内容，字符串输出的内容也会随之更改，这里通过python脚本实现此功能.
#!/usr/bin/env python3
'''
Locates and replaces the first occurrence of a string in the heap
of a process
Usage: ./read_write_heap.py PID search_string replace_by_string
Where:
- PID is the pid of the target process
- search_string is the ASCII string you are looking to overwrite
- replace_by_string is the ASCII string you want to replace
search_string with
'''
import sys
def print_usage_and_exit():
print('Usage: {} pid search write'.format(sys.argv[0]))
sys.exit(1)
# check usage
if len(sys.argv) != 4:
print_usage_and_exit()
# get the pid from args
pid = int(sys.argv[1])
if pid <= 0:
print_usage_and_exit()
search_string = str(sys.argv[2])
if search_string == "":
print_usage_and_exit()
write_string = str(sys.argv[3])
if search_string == "":
print_usage_and_exit()
# open the maps and mem files of the process
maps_filename = "/proc/{}/maps".format(pid)
print("[*] maps: {}".format(maps_filename))
mem_filename = "/proc/{}/mem".format(pid)
print("[*] mem: {}".format(mem_filename))
# try opening the maps file
try:
maps_file = open('/proc/{}/maps'.format(pid), 'r')
except IOError as e:
print("[ERROR] Can not open file {}:".format(maps_filename))
print(" I/O error({}): {}".format(e.errno, e.strerror))
sys.exit(1)
for line in maps_file:
sline = line.split(' ')
# check if we found the heap
if sline[-1][:-1] != "[heap]":
continue
print("[*] Found [heap]:")
# parse line
addr = sline[0]
perm = sline[1]
offset = sline[2]
device = sline[3]
inode = sline[4]
pathname = sline[-1][:-1]
print("\tpathname = {}".format(pathname))
print("\taddresses = {}".format(addr))
print("\tpermisions = {}".format(perm))
print("\toffset = {}".format(offset))
print("\tinode = {}".format(inode))
# check if there is read and write permission
if perm[0] != 'r' or perm[1] != 'w':
print("[*] {} does not have read/write permission".format(pathname))
maps_file.close()
exit(0)
# get start and end of the heap in the virtual memory
addr = addr.split("-")
if len(addr) != 2: # never trust anyone, not even your OS :)
print("[*] Wrong addr format")
maps_file.close()
exit(1)
addr_start = int(addr[0], 16)
addr_end = int(addr[1], 16)
print("\tAddr start [{:x}] | end [{:x}]".format(addr_start, addr_end))
# open and read mem
try:
mem_file = open(mem_filename, 'rb+')
except IOError as e:
print("[ERROR] Can not open file {}:".format(mem_filename))
print(" I/O error({}): {}".format(e.errno, e.strerror))
maps_file.close()
exit(1)
# read heap
mem_file.seek(addr_start)
heap = mem_file.read(addr_end - addr_start)
# find string
try:
i = heap.index(bytes(search_string, "ASCII"))
except Exception:
print("Can't find '{}'".format(search_string))
maps_file.close()
mem_file.close()
exit(0)
print("[*] Found '{}' at {:x}".format(search_string, i))
# write the new string
print("[*] Writing '{}' at {:x}".format(write_string, addr_start + i))
mem_file.seek(addr_start + i)
mem_file.write(bytes(write_string, "ASCII"))
# close files
maps_file.close()
mem_file.close()
# there is only one heap in our example
break运行这个Python脚本
zjucad@zjucad-ONDA-H110-MINI-V3-01:~/wangzhiqiang$ sudo ./loop.py 2542 test_memory test_hello
[*] maps: /proc/2542/maps
[*] mem: /proc/2542/mem
[*] Found [heap]:
pathname = [heap]
addresses = 021dc000-021fd000
permisions = rw-p
offset = 00000000
inode = 0
Addr start [21dc000] | end [21fd000]
[*] Found 'test_memory' at 10
[*] Writing 'test_hello' at 21dc010同时字符串输出的内容也已更改
[633] test_memory (0x21dc010)
[634] test_memory (0x21dc010)
[635] test_memory (0x21dc010)
[636] test_memory (0x21dc010)
[637] test_memory (0x21dc010)
[638] test_memory (0x21dc010)
[639] test_memory (0x21dc010)
[640] test_helloy (0x21dc010)
[641] test_helloy (0x21dc010)
[642] test_helloy (0x21dc010)
[643] test_helloy (0x21dc010)
[644] test_helloy (0x21dc010)
[645] test_helloy (0x21dc010)实验成功.
再列出内存空间分布图
基本上每个人或多或少都了解虚拟内存的空间分布，那如何验证它呢，下面会提到.
首先验证栈空间的位置，我们都知道C中局部变量是存储在栈空间的，malloc分配的内存是存储在堆空间，所以可以通过打印出局部变量地址和malloc的返回内存地址的方式来验证堆栈空间在整个虚拟空间中的位置.
#include <stdlib.h>
#include <stdio.h>
#include <string.h>
/**
* main - print locations of various elements
*
* Return: EXIT_FAILURE if something failed. Otherwise EXIT_SUCCESS
*/
int main(void)
{
int a;
void *p;
printf("Address of a: %p\n", (void *)&a);
p = malloc(98);
if (p == NULL)
{
fprintf(stderr, "Can't malloc\n");
return (EXIT_FAILURE);
}
printf("Allocated space in the heap: %p\n", p);
return (EXIT_SUCCESS);
}
编译运行:gcc -Wall -Wextra -pedantic -Werror main.c -o test; ./test
输出：
Address of a: 0x7ffedde9c7fc
Allocated space in the heap: 0x55ca5b360670通过结果可以看出堆地址空间在栈地址空间下面，整理如图:
可执行程序也在虚拟内存中，可以通过打印main函数的地址，并与堆栈地址相比较，即可知道可执行程序地址相对于堆栈地址的分布.
#include <stdlib.h>
#include <stdio.h>
#include <string.h>
/**
* main - print locations of various elements
*
* Return: EXIT_FAILURE if something failed. Otherwise EXIT_SUCCESS
*/
int main(void)
{
int a;
void *p;
printf("Address of a: %p\n", (void *)&a);
p = malloc(98);
if (p == NULL)
{
fprintf(stderr, "Can't malloc\n");
return (EXIT_FAILURE);
}
printf("Allocated space in the heap: %p\n", p);
printf("Address of function main: %p\n", (void *)main);
return (EXIT_SUCCESS);
}
编译运行:gcc main.c -o test; ./test
输出：
Address of a: 0x7ffed846de2c
Allocated space in the heap: 0x561b9ee8c670
Address of function main: 0x561b9deb378a由于main(0x561b9deb378a) < heap(0x561b9ee8c670) < (0x7ffed846de2c)，可以画出分布图如下:
程序入口main函数可以携带参数:
通过程序可以看见这些元素在虚拟内存中的位置：
#include <stdlib.h>
#include <stdio.h>
#include <string.h>
/**
* main - print locations of various elements
*
* Return: EXIT_FAILURE if something failed. Otherwise EXIT_SUCCESS
*/
int main(int ac, char **av, char **env)
{
int a;
void *p;
int i;
printf("Address of a: %p\n", (void *)&a);
p = malloc(98);
if (p == NULL)
{
fprintf(stderr, "Can't malloc\n");
return (EXIT_FAILURE);
}
printf("Allocated space in the heap: %p\n", p);
printf("Address of function main: %p\n", (void *)main);
printf("First bytes of the main function:\n\t");
for (i = 0; i < 15; i++)
{
printf("%02x ", ((unsigned char *)main)[i]);
}
printf("\n");
printf("Address of the array of arguments: %p\n", (void *)av);
printf("Addresses of the arguments:\n\t");
for (i = 0; i < ac; i++)
{
printf("[%s]:%p ", av[i], av[i]);
}
printf("\n");
printf("Address of the array of environment variables: %p\n", (void *)env);
printf("Address of the first environment variable: %p\n", (void *)(env[0]));
return (EXIT_SUCCESS);
}
编译运行:gcc main.c -o test; ./test nihao hello
输出：
Address of a: 0x7ffcc154a748
Allocated space in the heap: 0x559bd1bee670
Address of function main: 0x559bd09807ca
First bytes of the main function:
55 48 89 e5 48 83 ec 40 89 7d dc 48 89 75 d0
Address of the array of arguments: 0x7ffcc154a848
Addresses of the arguments:
[./test]:0x7ffcc154b94f [nihao]:0x7ffcc154b956 [hello]:0x7ffcc154b95c
Address of the array of environment variables: 0x7ffcc154a868
Address of the first environment variable: 0x7ffcc154b962结果如下： main(0x559bd09807ca) < heap(0x559bd1bee670) < stack(0x7ffcc154a748) < argv(0x7ffcc154a848) < env(0x7ffcc154a868) < arguments(0x7ffcc154b94f->0x7ffcc154b95c + 6)(6为hello+1('\0')) < env first(0x7ffcc154b962) 可以看出所有的命令行参数都是相邻的，并且紧接着就是环境变量.
上例中argv有4个元素，命令行中有三个参数，还有一个NULL指向标记数组的末尾，每个指针是8字节，8*4=32, argv(0x7ffcc154a848) + 32(0x20) = env(0x7ffcc154a868)，所以argv和env数组指针是相邻的.
首先需要获取环境变量数组的大小，环境变量数组是以NULL结束的，所以可以遍历env数组，检查是否为NULL，获取数组大小，代码如下：
#include <stdlib.h>
#include <stdio.h>
#include <string.h>
/**
* main - print locations of various elements
*
* Return: EXIT_FAILURE if something failed. Otherwise EXIT_SUCCESS
*/
int main(int ac, char **av, char **env)
{
int a;
void *p;
int i;
int size;
printf("Address of a: %p\n", (void *)&a);
p = malloc(98);
if (p == NULL)
{
fprintf(stderr, "Can't malloc\n");
return (EXIT_FAILURE);
}
printf("Allocated space in the heap: %p\n", p);
printf("Address of function main: %p\n", (void *)main);
printf("First bytes of the main function:\n\t");
for (i = 0; i < 15; i++)
{
printf("%02x ", ((unsigned char *)main)[i]);
}
printf("\n");
printf("Address of the array of arguments: %p\n", (void *)av);
printf("Addresses of the arguments:\n\t");
for (i = 0; i < ac; i++)
{
printf("[%s]:%p ", av[i], av[i]);
}
printf("\n");
printf("Address of the array of environment variables: %p\n", (void *)env);
printf("Address of the first environment variables:\n");
for (i = 0; i < 3; i++)
{
printf("\t[%p]:\"%s\"\n", env[i], env[i]);
}
/* size of the env array */
i = 0;
while (env[i] != NULL)
{
i++;
}
i++; /* the NULL pointer */
size = i * sizeof(char *);
printf("Size of the array env: %d elements -> %d bytes (0x%x)\n", i, size, size);
return (EXIT_SUCCESS);
}
编译运行:gcc main.c -o test; ./test nihao hello
输出：
Address of a: 0x7ffd5ebadff4
Allocated space in the heap: 0x562ba4e13670
Address of function main: 0x562ba2f1881a
First bytes of the main function:
55 48 89 e5 48 83 ec 40 89 7d dc 48 89 75 d0
Address of the array of arguments: 0x7ffd5ebae0f8
Addresses of the arguments:
[./test]:0x7ffd5ebae94f [nihao]:0x7ffd5ebae956 [hello]:0x7ffd5ebae95c
Address of the array of environment variables: 0x7ffd5ebae118
Address of the first environment variables:
[0x7ffd5ebae962]:"LS_COLORS=rs=0:di=01;34:ln=01;36:mh=00:pi=40;33:so=01;35:do=01;35:bd=40;33;01:cd=40;33;01:or=40;31;01:mi=00:su=37;41:sg=30;43:ca=30;41:tw=30;42:ow=34;42:st=37;44:ex=01;32:*.tar=01;31:*.tgz=01;31:*.arc=01;31:*.arj=01;31:*.taz=01;31:*.lha=01;31:*.lz4=01;31:*.lzh=01;31:*.lzma=01;31:*.tlz=01;31:*.txz=01;31:*.tzo=01;31:*.t7z=01;31:*.zip=01;31:*.z=01;31:*.Z=01;31:*.dz=01;31:*.gz=01;31:*.lrz=01;31:*.lz=01;31:*.lzo=01;31:*.xz=01;31:*.zst=01;31:*.tzst=01;31:*.bz2=01;31:*.bz=01;31:*.tbz=01;31:*.tbz2=01;31:*.tz=01;31:*.deb=01;31:*.rpm=01;31:*.jar=01;31:*.war=01;31:*.ear=01;31:*.sar=01;31:*.rar=01;31:*.alz=01;31:*.ace=01;31:*.zoo=01;31:*.cpio=01;31:*.7z=01;31:*.rz=01;31:*.cab=01;31:*.wim=01;31:*.swm=01;31:*.dwm=01;31:*.esd=01;31:*.jpg=01;35:*.jpeg=01;35:*.mjpg=01;35:*.mjpeg=01;35:*.gif=01;35:*.bmp=01;35:*.pbm=01;35:*.pgm=01;35:*.ppm=01;35:*.tga=01;35:*.xbm=01;35:*.xpm=01;35:*.tif=01;35:*.tiff=01;35:*.png=01;35:*.svg=01;35:*.svgz=01;35:*.mng=01;35:*.pcx=01;35:*.mov=01;35:*.mpg=01;35:*.mpeg=01;35:*.m2v=01;35:*.mkv=01;35:*.webm=01;35:*.ogm=01;35:*.mp4=01;35:*.m4v=01;35:*.mp4v=01;35:*.vob=01;35:*.qt=01;35:*.nuv=01;35:*.wmv=01;35:*.asf=01;35:*.rm=01;35:*.rmvb=01;35:*.flc=01;35:*.avi=01;35:*.fli=01;35:*.flv=01;35:*.gl=01;35:*.dl=01;35:*.xcf=01;35:*.xwd=01;35:*.yuv=01;35:*.cgm=01;35:*.emf=01;35:*.ogv=01;35:*.ogx=01;35:*.aac=00;36:*.au=00;36:*.flac=00;36:*.m4a=00;36:*.mid=00;36:*.midi=00;36:*.mka=00;36:*.mp3=00;36:*.mpc=00;36:*.ogg=00;36:*.ra=00;36:*.wav=00;36:*.oga=00;36:*.opus=00;36:*.spx=00;36:*.xspf=00;36:"
[0x7ffd5ebaef4e]:"HOSTNAME=3e8650948c0c"
[0x7ffd5ebaef64]:"OLDPWD=/"
Size of the array env: 11 elements -> 88 bytes (0x58)
运算结果如下：
root@3e8650948c0c:/ubuntu# bc
bc 1.07.1
Copyright 1991-1994, 1997, 1998, 2000, 2004, 2006, 2008, 2012-2017 Free Software Foundation, Inc.
This is free software with ABSOLUTELY NO WARRANTY.
For details type `warranty'.
obase=16
ibase=16
58+7ffd5ebae118
(standard_in) 3: syntax error
58+7FFD5EBAE118
7FFD5EBAE170
quit通过结果可知7FFD5EBAE170 != 0x7ffd5ebae94f，所以命令行参数地址不是紧随环境变量地址之后。
截至目前画出图表如下：
可以通过调用函数来确认，如果真的是向下增长，那么调用函数的地址应该高于被调用函数地址, 代码如下：
#include <stdlib.h>
#include <stdio.h>
#include <string.h>
void f(void)
{
int a;
int b;
int c;
a = 98;
b = 1024;
c = a * b;
printf("[f] a = %d, b = %d, c = a * b = %d\n", a, b, c);
printf("[f] Adresses of a: %p, b = %p, c = %p\n", (void *)&a, (void *)&b, (void *)&c);
}
int main(int ac, char **av, char **env)
{
int a;
void *p;
int i;
int size;
printf("Address of a: %p\n", (void *)&a);
p = malloc(98);
if (p == NULL)
{
fprintf(stderr, "Can't malloc\n");
return (EXIT_FAILURE);
}
printf("Allocated space in the heap: %p\n", p);
printf("Address of function main: %p\n", (void *)main);
f();
return (EXIT_SUCCESS);
}
编译运行:gcc main.c -o test; ./test
输出：
Address of a: 0x7ffefc75083c
Allocated space in the heap: 0x564d46318670
Address of function main: 0x564d45b9880e
[f] a = 98, b = 1024, c = a * b = 100352
[f] Adresses of a: 0x7ffefc7507ec, b = 0x7ffefc7507f0, c = 0x7ffefc7507f4结果可知: f{a} 0x7ffefc7507ec < main{a} 0x7ffefc75083c
可画图如下：
其实也可以写一个简单的代码，通过查看/proc文件系统中map内容来查看内存分布，这里就不举例啦.
malloc是常用的动态分配内存的函数，malloc申请的内存分配在堆中，注意malloc是glibc函数，不是系统调用.
man malloc:
[...] allocate dynamic memory[...]
void *malloc(size_t size);
[...]
The malloc() function allocates size bytes and returns a pointer to the allocated memory.看一段不调用malloc的代码
#include <stdlib.h>
#include <stdio.h>
/**
* main - do nothing
*
* Return: EXIT_FAILURE if something failed. Otherwise EXIT_SUCCESS
*/
int main(void)
{
getchar();
return (EXIT_SUCCESS);
}
编译运行：gcc test.c -o 2; ./2
step 1 : ps aux | grep \ \./2$
输出：
zjucad 3023 0.0 0.0 4352 788 pts/3 S+ 13:58 0:00 ./2
step 2 : /proc/3023/maps
输出：
00400000-00401000 r-xp 00000000 08:01 811723 /home/zjucad/wangzhiqiang/2
00600000-00601000 r--p 00000000 08:01 811723 /home/zjucad/wangzhiqiang/2
00601000-00602000 rw-p 00001000 08:01 811723 /home/zjucad/wangzhiqiang/2
007a4000-007c5000 rw-p 00000000 00:00 0 [heap]
7f954ca02000-7f954cbc2000 r-xp 00000000 08:01 8661324 /lib/x86_64-linux-gnu/libc-2.23.so
7f954cbc2000-7f954cdc2000 ---p 001c0000 08:01 8661324 /lib/x86_64-linux-gnu/libc-2.23.so
7f954cdc2000-7f954cdc6000 r--p 001c0000 08:01 8661324 /lib/x86_64-linux-gnu/libc-2.23.so
7f954cdc6000-7f954cdc8000 rw-p 001c4000 08:01 8661324 /lib/x86_64-linux-gnu/libc-2.23.so
7f954cdc8000-7f954cdcc000 rw-p 00000000 00:00 0
7f954cdcc000-7f954cdf2000 r-xp 00000000 08:01 8661310 /lib/x86_64-linux-gnu/ld-2.23.so
7f954cfd2000-7f954cfd5000 rw-p 00000000 00:00 0
7f954cff1000-7f954cff2000 r--p 00025000 08:01 8661310 /lib/x86_64-linux-gnu/ld-2.23.so
7f954cff2000-7f954cff3000 rw-p 00026000 08:01 8661310 /lib/x86_64-linux-gnu/ld-2.23.so
7f954cff3000-7f954cff4000 rw-p 00000000 00:00 0
7ffed68a1000-7ffed68c2000 rw-p 00000000 00:00 0 [stack]
7ffed690e000-7ffed6911000 r--p 00000000 00:00 0 [vvar]
7ffed6911000-7ffed6913000 r-xp 00000000 00:00 0 [vdso]
ffffffffff600000-ffffffffff601000 r-xp 00000000 00:00 0 [vsyscall]可以看到，如果不调用malloc，maps中就没有[heap]
下面运行一个带有malloc的程序
#include <stdio.h>
#include <stdlib.h>
/**
* main - prints the malloc returned address
*
* Return: EXIT_FAILURE if something failed. Otherwise EXIT_SUCCESS
*/
int main(void)
{
void *p;
p = malloc(1);
printf("%p\n", p);
getchar();
return (EXIT_SUCCESS);
}
编译运行：gcc test.c -o 3; ./3
输出：0xcc7010
验证步骤及输出：
zjucad@zjucad-ONDA-H110-MINI-V3-01:~/wangzhiqiang$ ps aux | grep \ \./3$
zjucad 3113 0.0 0.0 4352 644 pts/3 S+ 14:06 0:00 ./3
zjucad@zjucad-ONDA-H110-MINI-V3-01:~/wangzhiqiang$ cat /proc/3113/maps
00400000-00401000 r-xp 00000000 08:01 811726 /home/zjucad/wangzhiqiang/3
00600000-00601000 r--p 00000000 08:01 811726 /home/zjucad/wangzhiqiang/3
00601000-00602000 rw-p 00001000 08:01 811726 /home/zjucad/wangzhiqiang/3
00cc7000-00ce8000 rw-p 00000000 00:00 0 [heap]
7fc7e9128000-7fc7e92e8000 r-xp 00000000 08:01 8661324 /lib/x86_64-linux-gnu/libc-2.23.so
7fc7e92e8000-7fc7e94e8000 ---p 001c0000 08:01 8661324 /lib/x86_64-linux-gnu/libc-2.23.so
7fc7e94e8000-7fc7e94ec000 r--p 001c0000 08:01 8661324 /lib/x86_64-linux-gnu/libc-2.23.so
7fc7e94ec000-7fc7e94ee000 rw-p 001c4000 08:01 8661324 /lib/x86_64-linux-gnu/libc-2.23.so
7fc7e94ee000-7fc7e94f2000 rw-p 00000000 00:00 0
7fc7e94f2000-7fc7e9518000 r-xp 00000000 08:01 8661310 /lib/x86_64-linux-gnu/ld-2.23.so
7fc7e96f8000-7fc7e96fb000 rw-p 00000000 00:00 0
7fc7e9717000-7fc7e9718000 r--p 00025000 08:01 8661310 /lib/x86_64-linux-gnu/ld-2.23.so
7fc7e9718000-7fc7e9719000 rw-p 00026000 08:01 8661310 /lib/x86_64-linux-gnu/ld-2.23.so
7fc7e9719000-7fc7e971a000 rw-p 00000000 00:00 0
7ffc91c18000-7ffc91c39000 rw-p 00000000 00:00 0 [stack]
7ffc91d5f000-7ffc91d62000 r--p 00000000 00:00 0 [vvar]
7ffc91d62000-7ffc91d64000 r-xp 00000000 00:00 0 [vdso]
ffffffffff600000-ffffffffff601000 r-xp 00000000 00:00 0 [vsyscall]程序中带有malloc，那maps中就有[heap]段，并且malloc返回的地址在heap的地址段中，但是返回的地址却不再heap的最开始地址上，相差了0x10字节，为什么呢?看下面：
malloc不是系统调用，它是一个正常函数，它必须调用某些系统调用才可以操作堆内存，通过使用strace工具可以追踪进程的系统调用和信号，为了确认系统调用是malloc产生的，所以在malloc前后添加write系统调用方便定位问题。
#include <stdio.h>
#include <stdlib.h>
#include <unistd.h>
/**
* main - let's find out which syscall malloc is using
*
* Return: EXIT_FAILURE if something failed. Otherwise EXIT_SUCCESS
*/
int main(void)
{
void *p;
write(1, "BEFORE MALLOC\n", 14);
p = malloc(1);
write(1, "AFTER MALLOC\n", 13);
printf("%p\n", p);
getchar();
return (EXIT_SUCCESS);
}
编译运行：gcc test.c -o 4
zjucad@zjucad-ONDA-H110-MINI-V3-01:~/wangzhiqiang$ strace ./4
execve("./4", ["./4"], [/* 34 vars */]) = 0
brk(NULL) = 0x781000
access("/etc/ld.so.nohwcap", F_OK) = -1 ENOENT (No such file or directory)
access("/etc/ld.so.preload", R_OK) = -1 ENOENT (No such file or directory)
open("/etc/ld.so.cache", O_RDONLY|O_CLOEXEC) = 3
fstat(3, {st_mode=S_IFREG|0644, st_size=111450, ...}) = 0
mmap(NULL, 111450, PROT_READ, MAP_PRIVATE, 3, 0) = 0x7f37720fa000
close(3) = 0
access("/etc/ld.so.nohwcap", F_OK) = -1 ENOENT (No such file or directory)
open("/lib/x86_64-linux-gnu/libc.so.6", O_RDONLY|O_CLOEXEC) = 3
read(3, "\177ELF\2\1\1\3\0\0\0\0\0\0\0\0\3\0>\0\1\0\0\0P\t\2\0\0\0\0\0"..., 832) = 832
fstat(3, {st_mode=S_IFREG|0755, st_size=1868984, ...}) = 0
mmap(NULL, 4096, PROT_READ|PROT_WRITE, MAP_PRIVATE|MAP_ANONYMOUS, -1, 0) = 0x7f37720f9000
mmap(NULL, 3971488, PROT_READ|PROT_EXEC, MAP_PRIVATE|MAP_DENYWRITE, 3, 0) = 0x7f3771b27000
mprotect(0x7f3771ce7000, 2097152, PROT_NONE) = 0
mmap(0x7f3771ee7000, 24576, PROT_READ|PROT_WRITE, MAP_PRIVATE|MAP_FIXED|MAP_DENYWRITE, 3, 0x1c0000) = 0x7f3771ee7000
mmap(0x7f3771eed000, 14752, PROT_READ|PROT_WRITE, MAP_PRIVATE|MAP_FIXED|MAP_ANONYMOUS, -1, 0) = 0x7f3771eed000
close(3) = 0
mmap(NULL, 4096, PROT_READ|PROT_WRITE, MAP_PRIVATE|MAP_ANONYMOUS, -1, 0) = 0x7f37720f8000
mmap(NULL, 4096, PROT_READ|PROT_WRITE, MAP_PRIVATE|MAP_ANONYMOUS, -1, 0) = 0x7f37720f7000
arch_prctl(ARCH_SET_FS, 0x7f37720f8700) = 0
mprotect(0x7f3771ee7000, 16384, PROT_READ) = 0
mprotect(0x600000, 4096, PROT_READ) = 0
mprotect(0x7f3772116000, 4096, PROT_READ) = 0
munmap(0x7f37720fa000, 111450) = 0
write(1, "BEFORE MALLOC\n", 14BEFORE MALLOC
) = 14
brk(NULL) = 0x781000
brk(0x7a2000) = 0x7a2000
write(1, "AFTER MALLOC\n", 13AFTER MALLOC
) = 13
fstat(1, {st_mode=S_IFCHR|0620, st_rdev=makedev(136, 3), ...}) = 0
write(1, "0x781010\n", 90x781010
) = 9
fstat(0, {st_mode=S_IFCHR|0620, st_rdev=makedev(136, 3), ...}) = 0最后几行的输出可知，malloc主要调用brk系统调用来操作堆内存.
man brk
...
int brk(void *addr);
void *sbrk(intptr_t increment);
...
DESCRIPTION
brk() and sbrk() change the location of the program break, which defines
the end of the process's data segment (i.e., the program break is the first
location after the end of the uninitialized data segment). Increasing the
program break has the effect of allocating memory to the process; decreas‐
ing the break deallocates memory.
brk() sets the end of the data segment to the value specified by addr, when
that value is reasonable, the system has enough memory, and the process
does not exceed its maximum data size (see setrlimit(2)).
sbrk() increments the program's data space by increment bytes. Calling
sbrk() with an increment of 0 can be used to find the current location of
the program break.程序中断是虚拟内存中程序数据段结束后的第一个位置的地址，malloc通过调用brk或者sbrk，增加程序中断的值就可以创建新空间来动态分配内存，首次调用brk会返回当前程序中断的地址，第二次调用brk也会返回程序中断的地址，可以发现第二次brk返回地址大于第一次brk返回地址，brk就是通过增加程序中断地址的方式来分配内存，可以看出现在的堆地址范围是0x781000-0x7a2000，通过cat /proc/[pid]/maps也可以验证，此处就不贴上实际验证的结果啦。
如果多次malloc会出现什么现象呢，代码如下：
#include <stdio.h>
#include <stdlib.h>
#include <unistd.h>
/**
* main - many calls to malloc
*
* Return: EXIT_FAILURE if something failed. Otherwise EXIT_SUCCESS
*/
int main(void)
{
void *p;
write(1, "BEFORE MALLOC #0\n", 17);
p = malloc(1024);
write(1, "AFTER MALLOC #0\n", 16);
printf("%p\n", p);
write(1, "BEFORE MALLOC #1\n", 17);
p = malloc(1024);
write(1, "AFTER MALLOC #1\n", 16);
printf("%p\n", p);
write(1, "BEFORE MALLOC #2\n", 17);
p = malloc(1024);
write(1, "AFTER MALLOC #2\n", 16);
printf("%p\n", p);
write(1, "BEFORE MALLOC #3\n", 17);
p = malloc(1024);
write(1, "AFTER MALLOC #3\n", 16);
printf("%p\n", p);
getchar();
return (EXIT_SUCCESS);
}
编译运行：gcc test.c -o 5; strace ./5
摘要输出结果如下：
write(1, "BEFORE MALLOC #0\n", 17BEFORE MALLOC #0
) = 17
brk(NULL) = 0x561605c7a000
brk(0x561605c9b000) = 0x561605c9b000
write(1, "AFTER MALLOC #0\n", 16AFTER MALLOC #0
) = 16
fstat(1, {st_mode=S_IFCHR|0620, st_rdev=makedev(136, 0), ...}) = 0
write(1, "0x561605c7a260\n", 150x561605c7a260
) = 15
write(1, "BEFORE MALLOC #1\n", 17BEFORE MALLOC #1
) = 17
write(1, "AFTER MALLOC #1\n", 16AFTER MALLOC #1
) = 16
write(1, "0x561605c7aa80\n", 150x561605c7aa80
) = 15
write(1, "BEFORE MALLOC #2\n", 17BEFORE MALLOC #2
) = 17
write(1, "AFTER MALLOC #2\n", 16AFTER MALLOC #2
) = 16
write(1, "0x561605c7ae90\n", 150x561605c7ae90
) = 15
write(1, "BEFORE MALLOC #3\n", 17BEFORE MALLOC #3
) = 17
write(1, "AFTER MALLOC #3\n", 16AFTER MALLOC #3
) = 16
write(1, "0x561605c7b2a0\n", 150x561605c7b2a0
) = 15
fstat(0, {st_mode=S_IFCHR|0620, st_rdev=makedev(136, 0), ...}) = 0可以发现并不是每次调用malloc都会触发brk系统调用，首次调用malloc，内部会通过brk系统调用更改程序中断地址，分配出一大块内存空间，后续再调用malloc，malloc内部会优先使用之前分配出来的内存空间，直到内部内存空间已经不够再次分配给外部时才会再次触发brk系统调用.
上面分析可以看见程序第一次调用malloc返回的地址并不是heap段的首地址，而是相差了0x10个字节，那这16个字节究竟是什么，可以通过程序打印出这前16个字节的内容.
编译运行：gcc test.c -o test;./test
输出：
0x5589436ce260
bytes at 0x5589436ce250:
00 00 00 00 00 00 00 00 11 04 00 00 00 00 00 00
0x5589436cea80
bytes at 0x5589436cea70:
00 00 00 00 00 00 00 00 11 08 00 00 00 00 00 00
0x5589436cf290
bytes at 0x5589436cf280:
00 00 00 00 00 00 00 00 11 0c 00 00 00 00 00 00
0x5589436cfea0
bytes at 0x5589436cfe90:
00 00 00 00 00 00 00 00 11 10 00 00 00 00 00 00
0x5589436d0eb0
bytes at 0x5589436d0ea0:
00 00 00 00 00 00 00 00 11 14 00 00 00 00 00 00
0x5589436d22c0
bytes at 0x5589436d22b0:
00 00 00 00 00 00 00 00 11 18 00 00 00 00 00 00
0x5589436d3ad0
bytes at 0x5589436d3ac0:
00 00 00 00 00 00 00 00 11 1c 00 00 00 00 00 00
0x5589436d56e0
bytes at 0x5589436d56d0:
00 00 00 00 00 00 00 00 11 20 00 00 00 00 00 00
0x5589436d76f0
bytes at 0x5589436d76e0:
00 00 00 00 00 00 00 00 11 24 00 00 00 00 00 00
0x5589436d9b00
bytes at 0x5589436d9af0:
00 00 00 00 00 00 00 00 11 28 00 00 00 00 00 00可以看出规律：这16个字节相当于malloc出来的地址的头，包含一些信息，目前可以看出它包括已经分配的地址空间的大小，第一次malloc申请了0x400(1024)字节，可以发现11 04 00 00 00 00 00 00大于0x400(1024)，这8个字节表示数字 0x 00 00 00 00 00 00 04 11 = 0x400(1024) + 0x10(头的大小16) + 1(后面会说明它的含义)，可以发现每次调用malloc，这前8个字节代表的含义都是malloc字节数+16+1.
可以猜测，malloc内部会把这前16个字节强转成某种数据结构，数据结构包含某些信息，最主要的是已经分配的字节数，尽管我们不了解具体结构，但是也可以通过代码操作这16个字节验证我们上面总结的规律是否正确，注意代码中不调用free释放内存.
#include <stdio.h>
#include <stdlib.h>
#include <unistd.h>
/**
* pmem - print mem
* @p: memory address to start printing from
* @bytes: number of bytes to print
*
* Return: nothing
*/
void pmem(void *p, unsigned int bytes)
{
unsigned char *ptr;
unsigned int i;
ptr = (unsigned char *)p;
for (i = 0; i < bytes; i++)
{
if (i != 0)
{
printf(" ");
}
printf("%02x", *(ptr + i));
}
printf("\n");
}
/**
* main - confirm the source code
*
* Return: EXIT_FAILURE if something failed. Otherwise EXIT_SUCCESS
*/
int main(void)
{
void *p;
int i;
size_t size_of_the_chunk;
size_t size_of_the_previous_chunk;
void *chunks[10];
for (i = 0; i < 10; i++)
{
p = malloc(1024 * (i + 1));
chunks[i] = (void *)((char *)p - 0x10);
printf("%p\n", p);
}
free((char *)(chunks[3]) + 0x10);
free((char *)(chunks[7]) + 0x10);
for (i = 0; i < 10; i++)
{
p = chunks[i];
printf("chunks[%d]: ", i);
pmem(p, 0x10);
size_of_the_chunk = *((size_t *)((char *)p + 8)) - 1;
size_of_the_previous_chunk = *((size_t *)((char *)p));
printf("chunks[%d]: %p, size = %li, prev = %li\n",
i, p, size_of_the_chunk, size_of_the_previous_chunk);
}
return (EXIT_SUCCESS);
}
编译运行输出：
root@3e8650948c0c:/ubuntu# gcc test.c -o test
root@3e8650948c0c:/ubuntu# ./test
0x559721de4260
0x559721de4a80
0x559721de5290
0x559721de5ea0
0x559721de6eb0
0x559721de82c0
0x559721de9ad0
0x559721deb6e0
0x559721ded6f0
0x559721defb00
chunks[0]: 00 00 00 00 00 00 00 00 11 04 00 00 00 00 00 00
chunks[0]: 0x559721de4250, size = 1040, prev = 0
chunks[1]: 00 00 00 00 00 00 00 00 11 08 00 00 00 00 00 00
chunks[1]: 0x559721de4a70, size = 2064, prev = 0
chunks[2]: 00 00 00 00 00 00 00 00 11 0c 00 00 00 00 00 00
chunks[2]: 0x559721de5280, size = 3088, prev = 0
chunks[3]: 00 00 00 00 00 00 00 00 11 10 00 00 00 00 00 00
chunks[3]: 0x559721de5e90, size = 4112, prev = 0
chunks[4]: 10 10 00 00 00 00 00 00 10 14 00 00 00 00 00 00
chunks[4]: 0x559721de6ea0, size = 5135, prev = 4112
chunks[5]: 00 00 00 00 00 00 00 00 11 18 00 00 00 00 00 00
chunks[5]: 0x559721de82b0, size = 6160, prev = 0
chunks[6]: 00 00 00 00 00 00 00 00 11 1c 00 00 00 00 00 00
chunks[6]: 0x559721de9ac0, size = 7184, prev = 0
chunks[7]: 00 00 00 00 00 00 00 00 11 20 00 00 00 00 00 00
chunks[7]: 0x559721deb6d0, size = 8208, prev = 0
chunks[8]: 10 20 00 00 00 00 00 00 10 24 00 00 00 00 00 00
chunks[8]: 0x559721ded6e0, size = 9231, prev = 8208
chunks[9]: 00 00 00 00 00 00 00 00 11 28 00 00 00 00 00 00
chunks[9]: 0x559721defaf0, size = 10256, prev = 0结果可以看出，malloc返回的地址往前的16个字节可以表示已经分配的内存大小, 如图：
注意上述是没有调用free释放内存的结果，然而malloc只用了8个字节表示已经分配的内存大小，那么另外8个字节被用来表示什么含义呢，看下malloc函数的注释:
1055 /*
1056 malloc_chunk details:
1057
1058 (The following includes lightly edited explanations by Colin Plumb.)
1059
1060 Chunks of memory are maintained using a `boundary tag' method as
1061 described in e.g., Knuth or Standish. (See the paper by Paul
1062 Wilson ftp://ftp.cs.utexas.edu/pub/garbage/allocsrv.ps for a
1063 survey of such techniques.) Sizes of free chunks are stored both
1064 in the front of each chunk and at the end. This makes
1065 consolidating fragmented chunks into bigger chunks very fast. The
1066 size fields also hold bits representing whether chunks are free or
1067 in use.
1068
1069 An allocated chunk looks like this:
1070
1071
1072 chunk-> +-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
1073 | Size of previous chunk, if unallocated (P clear) |
1074 +-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
1075 | Size of chunk, in bytes |A|M|P|
1076 mem-> +-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
1077 | User data starts here... .
1078 . .
1079 . (malloc_usable_size() bytes) .
1080 . |
1081 nextchunk-> +-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
1082 | (size of chunk, but used for application data) |
1083 +-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
1084 | Size of next chunk, in bytes |A|0|1|
1085 +-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+-+
1086
1087 Where "chunk" is the front of the chunk for the purpose of most of
1088 the malloc code, but "mem" is the pointer that is returned to the
1089 user. "Nextchunk" is the beginning of the next contiguous chunk.可以看出这16字节有两个含义，前8个字节表示之前的空间有多少没有被分配的字节大小，后8个字节表示当前malloc已经分配的字节大小，通过一段调用free的代码查看：
#include <stdio.h>
#include <stdlib.h>
#include <unistd.h>
/**
* pmem - print mem
* @p: memory address to start printing from
* @bytes: number of bytes to print
*
* Return: nothing
*/
void pmem(void *p, unsigned int bytes)
{
unsigned char *ptr;
unsigned int i;
ptr = (unsigned char *)p;
for (i = 0; i < bytes; i++)
{
if (i != 0)
{
printf(" ");
}
printf("%02x", *(ptr + i));
}
printf("\n");
}
/**
* main - confirm the source code
*
* Return: EXIT_FAILURE if something failed. Otherwise EXIT_SUCCESS
*/
int main(void)
{
void *p;
int i;
size_t size_of_the_chunk;
size_t size_of_the_previous_chunk;
void *chunks[10];
for (i = 0; i < 10; i++)
{
p = malloc(1024 * (i + 1));
chunks[i] = (void *)((char *)p - 0x10);
printf("%p\n", p);
}
free((char *)(chunks[3]) + 0x10);
free((char *)(chunks[7]) + 0x10);
for (i = 0; i < 10; i++)
{
p = chunks[i];
printf("chunks[%d]: ", i);
pmem(p, 0x10);
size_of_the_chunk = *((size_t *)((char *)p + 8)) - 1;
size_of_the_previous_chunk = *((size_t *)((char *)p));
printf("chunks[%d]: %p, size = %li, prev = %li\n",
i, p, size_of_the_chunk, size_of_the_previous_chunk);
}
return (EXIT_SUCCESS);
}
编译运行输出：
root@3e8650948c0c:/ubuntu# gcc test.c -o test
root@3e8650948c0c:/ubuntu# ./test
0x55fbebf20260
0x55fbebf20a80
0x55fbebf21290
0x55fbebf21ea0
0x55fbebf22eb0
0x55fbebf242c0
0x55fbebf25ad0
0x55fbebf276e0
0x55fbebf296f0
0x55fbebf2bb00
chunks[0]: 00 00 00 00 00 00 00 00 11 04 00 00 00 00 00 00
chunks[0]: 0x55fbebf20250, size = 1040, prev = 0
chunks[1]: 00 00 00 00 00 00 00 00 11 08 00 00 00 00 00 00
chunks[1]: 0x55fbebf20a70, size = 2064, prev = 0
chunks[2]: 00 00 00 00 00 00 00 00 11 0c 00 00 00 00 00 00
chunks[2]: 0x55fbebf21280, size = 3088, prev = 0
chunks[3]: 00 00 00 00 00 00 00 00 11 10 00 00 00 00 00 00
chunks[3]: 0x55fbebf21e90, size = 4112, prev = 0
chunks[4]: 10 10 00 00 00 00 00 00 10 14 00 00 00 00 00 00
chunks[4]: 0x55fbebf22ea0, size = 5135, prev = 4112
chunks[5]: 00 00 00 00 00 00 00 00 11 18 00 00 00 00 00 00
chunks[5]: 0x55fbebf242b0, size = 6160, prev = 0
chunks[6]: 00 00 00 00 00 00 00 00 11 1c 00 00 00 00 00 00
chunks[6]: 0x55fbebf25ac0, size = 7184, prev = 0
chunks[7]: 00 00 00 00 00 00 00 00 11 20 00 00 00 00 00 00
chunks[7]: 0x55fbebf276d0, size = 8208, prev = 0
chunks[8]: 10 20 00 00 00 00 00 00 10 24 00 00 00 00 00 00
chunks[8]: 0x55fbebf296e0, size = 9231, prev = 8208
chunks[9]: 00 00 00 00 00 00 00 00 11 28 00 00 00 00 00 00
chunks[9]: 0x55fbebf2baf0, size = 10256, prev = 0程序代码通过free释放了3和7数据块的空间，所以4和8的前8个字节已经不全是0啦，和其它不同，它们表示之前数据块没有被分配的大小，也可以注意到4和8块的后8个字节不像其它块一样需要加1啦，可以得出结论，malloc通过是否加1来作为前一个数据块是否已经分配的标志，加1表示前一个数据块已经分配。所以之前的程序代码可以修改为如下形式：
#include <stdio.h>
#include <stdlib.h>
#include <unistd.h>
/**
* pmem - print mem
* @p: memory address to start printing from
* @bytes: number of bytes to print
*
* Return: nothing
*/
void pmem(void *p, unsigned int bytes)
{
unsigned char *ptr;
unsigned int i;
ptr = (unsigned char *)p;
for (i = 0; i < bytes; i++)
{
if (i != 0)
{
printf(" ");
}
printf("%02x", *(ptr + i));
}
printf("\n");
}
/**
* main - updating with correct checks
*
* Return: EXIT_FAILURE if something failed. Otherwise EXIT_SUCCESS
*/
int main(void)
{
void *p;
int i;
size_t size_of_the_chunk;
size_t size_of_the_previous_chunk;
void *chunks[10];
char prev_used;
for (i = 0; i < 10; i++)
{
p = malloc(1024 * (i + 1));
chunks[i] = (void *)((char *)p - 0x10);
}
free((char *)(chunks[3]) + 0x10);
free((char *)(chunks[7]) + 0x10);
for (i = 0; i < 10; i++)
{
p = chunks[i];
printf("chunks[%d]: ", i);
pmem(p, 0x10);
size_of_the_chunk = *((size_t *)((char *)p + 8));
prev_used = size_of_the_chunk & 1;
size_of_the_chunk -= prev_used;
size_of_the_previous_chunk = *((size_t *)((char *)p));
printf("chunks[%d]: %p, size = %li, prev (%s) = %li\n",
i, p, size_of_the_chunk,
(prev_used? "allocated": "unallocated"), size_of_the_previous_chunk);
}
return (EXIT_SUCCESS);
}
编译运行输出：
root@3e8650948c0c:/ubuntu# gcc test.c -o test
root@3e8650948c0c:/ubuntu# ./test
chunks[0]: 00 00 00 00 00 00 00 00 11 04 00 00 00 00 00 00
chunks[0]: 0x56254f888250, size = 1040, prev (allocated) = 0
chunks[1]: 00 00 00 00 00 00 00 00 11 08 00 00 00 00 00 00
chunks[1]: 0x56254f888660, size = 2064, prev (allocated) = 0
chunks[2]: 00 00 00 00 00 00 00 00 11 0c 00 00 00 00 00 00
chunks[2]: 0x56254f888e70, size = 3088, prev (allocated) = 0
chunks[3]: 00 00 00 00 00 00 00 00 11 04 00 00 00 00 00 00
chunks[3]: 0x56254f889a80, size = 1040, prev (allocated) = 0
chunks[4]: 00 0c 00 00 00 00 00 00 10 14 00 00 00 00 00 00
chunks[4]: 0x56254f88aa90, size = 5136, prev (unallocated) = 3072
chunks[5]: 00 00 00 00 00 00 00 00 11 18 00 00 00 00 00 00
chunks[5]: 0x56254f88bea0, size = 6160, prev (allocated) = 0
chunks[6]: 00 00 00 00 00 00 00 00 11 1c 00 00 00 00 00 00
chunks[6]: 0x56254f88d6b0, size = 7184, prev (allocated) = 0
chunks[7]: 00 00 00 00 00 00 00 00 11 20 00 00 00 00 00 00
chunks[7]: 0x56254f88f2c0, size = 8208, prev (allocated) = 0
chunks[8]: 10 20 00 00 00 00 00 00 10 24 00 00 00 00 00 00
chunks[8]: 0x56254f8912d0, size = 9232, prev (unallocated) = 8208
chunks[9]: 00 00 00 00 00 00 00 00 11 28 00 00 00 00 00 00
chunks[9]: 0x56254f8936e0, size = 10256, prev (allocated) = 0通过代码验证：
#include <stdio.h>
#include <stdlib.h>
#include <unistd.h>
/**
* main - moving the program break
*
* Return: EXIT_FAILURE if something failed. Otherwise EXIT_SUCCESS
*/
int main(void)
{
int i;
write(1, "START\n", 6);
malloc(1);
getchar();
write(1, "LOOP\n", 5);
for (i = 0; i < 0x25000 / 1024; i++)
{
malloc(1024);
}
write(1, "END\n", 4);
getchar();
return (EXIT_SUCCESS);
}
编译运行部分摘要输出：
root@3e8650948c0c:/ubuntu# gcc test.c -o test
root@3e8650948c0c:/ubuntu# strace ./test
execve("./test", ["./test"], 0x7ffe0d7cbd80 /* 10 vars */) = 0
brk(NULL) = 0x555a2428f000
access("/etc/ld.so.nohwcap", F_OK) = -1 ENOENT (No such file or directory)
access("/etc/ld.so.preload", R_OK) = -1 ENOENT (No such file or directory)
openat(AT_FDCWD, "/etc/ld.so.cache", O_RDONLY|O_CLOEXEC) = 3
fstat(3, {st_mode=S_IFREG|0644, st_size=13722, ...}) = 0
mmap(NULL, 13722, PROT_READ, MAP_PRIVATE, 3, 0) = 0x7f6423455000
close(3) = 0
access("/etc/ld.so.nohwcap", F_OK) = -1 ENOENT (No such file or directory)
openat(AT_FDCWD, "/lib/x86_64-linux-gnu/libc.so.6", O_RDONLY|O_CLOEXEC) = 3
read(3, "\177ELF\2\1\1\3\0\0\0\0\0\0\0\0\3\0>\0\1\0\0\0\260\34\2\0\0\0\0\0"..., 832) = 832
fstat(3, {st_mode=S_IFREG|0755, st_size=2030544, ...}) = 0
mmap(NULL, 8192, PROT_READ|PROT_WRITE, MAP_PRIVATE|MAP_ANONYMOUS, -1, 0) = 0x7f6423453000
mmap(NULL, 4131552, PROT_READ|PROT_EXEC, MAP_PRIVATE|MAP_DENYWRITE, 3, 0) = 0x7f6422e41000
mprotect(0x7f6423028000, 2097152, PROT_NONE) = 0
mmap(0x7f6423228000, 24576, PROT_READ|PROT_WRITE, MAP_PRIVATE|MAP_FIXED|MAP_DENYWRITE, 3, 0x1e7000) = 0x7f6423228000
mmap(0x7f642322e000, 15072, PROT_READ|PROT_WRITE, MAP_PRIVATE|MAP_FIXED|MAP_ANONYMOUS, -1, 0) = 0x7f642322e000
close(3) = 0
arch_prctl(ARCH_SET_FS, 0x7f64234544c0) = 0
mprotect(0x7f6423228000, 16384, PROT_READ) = 0
mprotect(0x555a22f5f000, 4096, PROT_READ) = 0
mprotect(0x7f6423459000, 4096, PROT_READ) = 0
munmap(0x7f6423455000, 13722) = 0
write(1, "START\n", 6START
) = 6
brk(NULL) = 0x555a2428f000
brk(0x555a242b0000) = 0x555a242b0000
fstat(0, {st_mode=S_IFCHR|0620, st_rdev=makedev(136, 0), ...}) = 0
read(0,
"\n", 1024) = 1
write(1, "LOOP\n", 5LOOP
) = 5
brk(0x555a242d1000) = 0x555a242d1000
brk(0x555a242f2000) = 0x555a242f2000
brk(0x555a24313000) = 0x555a24313000
brk(0x555a24334000) = 0x555a24334000
brk(0x555a24355000) = 0x555a24355000
brk(0x555a24376000) = 0x555a24376000
brk(0x555a24397000) = 0x555a24397000
brk(0x555a243b8000) = 0x555a243b8000
brk(0x555a243d9000) = 0x555a243d9000
brk(0x555a243fa000) = 0x555a243fa000可以看出堆空间是向上增长的.
从开始到现在运行了好多个进程，通过查看对应进程的maps，发现每个进程的heap的起始地址和可执行程序的结束地址都不紧邻，而且差距还每次都不相同.
[3718]: 01195000 – 00602000 = b93000
[3834]: 024d6000 – 00602000 = 1ed4000
[4014]: 00e70000 – 00602000 = 86e000
[4172]: 01314000 – 00602000 = d12000
[7972]: 00901000 – 00602000 = 2ff000可以看出这个差值是随机的，查看fs/binfmt_elf.c源代码
if ((current->flags & PF_RANDOMIZE) && (randomize_va_space > 1)) {
current->mm->brk = current->mm->start_brk =
arch_randomize_brk(current->mm);
#ifdef compat_brk_randomized
current->brk_randomized = 1;
#endif
}
// current->mm->brk是当前进程程序中断的地址arch_randomize_brk函数在arch/x86/kernel/process.c中
unsigned long arch_randomize_brk(struct mm_struct *mm)
{
unsigned long range_end = mm->brk + 0x02000000;
return randomize_range(mm->brk, range_end, 0) ? : mm->brk;
}randomize_range函数在drivers/char/random.c中
/*
* randomize_range() returns a start address such that
*
* [...... <range> .....]
* start end
*
* a <range> with size "len" starting at the return value is inside in the
* area defined by [start, end], but is otherwise randomized.
*/
unsigned long
randomize_range(unsigned long start, unsigned long end, unsigned long len)
{
unsigned long range = end - len - start;
if (end <= start + len)
return 0;
return PAGE_ALIGN(get_random_int() % range + start);
}可以看出上面所说的这个差值其实就是0-0x02000000中的一个随机数，这种技术称为ASLR(Address Space Layout Randomisation)，是一种计算机安全技术，随机安排虚拟内存中堆栈空间的位置，可以有效防止黑客攻击。通过以上分析，可以画出内存分布图如下：
当调用malloc(0)会发生什么，代码如下：
#include <stdio.h>
#include <stdlib.h>
#include <unistd.h>
/**
* pmem - print mem
* @p: memory address to start printing from
* @bytes: number of bytes to print
*
* Return: nothing
*/
void pmem(void *p, unsigned int bytes)
{
unsigned char *ptr;
unsigned int i;
ptr = (unsigned char *)p;
for (i = 0; i < bytes; i++)
{
if (i != 0)
{
printf(" ");
}
printf("%02x", *(ptr + i));
}
printf("\n");
}
/**
* main - moving the program break
*
* Return: EXIT_FAILURE if something failed. Otherwise EXIT_SUCCESS
*/
int main(void)
{
void *p;
size_t size_of_the_chunk;
char prev_used;
p = malloc(0);
printf("%p\n", p);
pmem((char *)p - 0x10, 0x10);
size_of_the_chunk = *((size_t *)((char *)p - 8));
prev_used = size_of_the_chunk & 1;
size_of_the_chunk -= prev_used;
printf("chunk size = %li bytes\n", size_of_the_chunk);
return (EXIT_SUCCESS);
}
编译运行输出如下：
root@3e8650948c0c:/ubuntu# gcc test.c -o test
root@3e8650948c0c:/ubuntu# ./test
0x564ece64b260
00 00 00 00 00 00 00 00 21 00 00 00 00 00 00 00
chunk size = 32 bytes可以看出malloc(0)实际使用了32个字节，其中包括我们之前说的16个字节头部，然而有时候malloc(0)可能会有不同的结果输出，也有可能会返回NULL.
man malloc
NULL may also be returned by a successful call to malloc() with a size of zero示例代码主要在两种环境下跑过：
ubuntu 16.04
gcc (Ubuntu 7.4.0-1ubuntu1~16.04~ppa1) 7.4.0
ubuntu 18.04 docker
gcc (Ubuntu 7.4.0-1ubuntu1~18.04.1) 7.4.0本文是从这一系列文章翻译并结合自己理解提炼出来的，代码都自己实践过，有时间的也可以直接阅读英文原链接
Hack The Virtual Memory: C strings & /proc Hack the Virtual Memory: drawing the VM diagram
Hack the Virtual Memory: malloc, the heap & the program break
本文由哈喽比特于3年以前收录，如有侵权请联系我们。
文章来源：https://mp.weixin.qq.com/s/Ek3vyBDYejgOkBU6R_EH_Q
京东创始人刘强东和其妻子章泽天最近成为了互联网舆论关注的焦点。有关他们“移民美国”和在美国购买豪宅的传言在互联网上广泛传播。然而，京东官方通过微博发言人发布的消息澄清了这些传言，称这些言论纯属虚假信息和蓄意捏造。
日前，据博主“@超能数码君老周”爆料，国内三大运营商中国移动、中国电信和中国联通预计将集体采购百万台规模的华为Mate60系列手机。
据报道，荷兰半导体设备公司ASML正看到美国对华遏制政策的负面影响。阿斯麦（ASML）CEO彼得·温宁克在一档电视节目中分享了他对中国大陆问题以及该公司面临的出口管制和保护主义的看法。彼得曾在多个场合表达了他对出口管制以及中荷经济关系的担忧。
今年早些时候，抖音悄然上线了一款名为“青桃”的 App，Slogan 为“看见你的热爱”，根据应用介绍可知，“青桃”是一个属于年轻人的兴趣知识视频平台，由抖音官方出品的中长视频关联版本，整体风格有些类似B站。
日前，威马汽车首席数据官梅松林转发了一份“世界各国地区拥车率排行榜”，同时，他发文表示：中国汽车普及率低于非洲国家尼日利亚，每百户家庭仅17户有车。意大利世界排名第一，每十户中九户有车。
近日，一项新的研究发现，维生素 C 和 E 等抗氧化剂会激活一种机制，刺激癌症肿瘤中新血管的生长，帮助它们生长和扩散。
据媒体援引消息人士报道，苹果公司正在测试使用3D打印技术来生产其智能手表的钢质底盘。消息传出后，3D系统一度大涨超10%，不过截至周三收盘，该股涨幅回落至2%以内。
9月2日，坐拥千万粉丝的网红主播“秀才”账号被封禁，在社交媒体平台上引发热议。平台相关负责人表示，“秀才”账号违反平台相关规定，已封禁。据知情人士透露，秀才近期被举报存在违法行为，这可能是他被封禁的部分原因。据悉，“秀才”年龄39岁，是安徽省亳州市蒙城县人，抖音网红，粉丝数量超1200万。他曾被称为“中老年...
9月3日消息，亚马逊的一些股东，包括持有该公司股票的一家养老基金，日前对亚马逊、其创始人贝索斯和其董事会提起诉讼，指控他们在为 Project Kuiper 卫星星座项目购买发射服务时“违反了信义义务”。
据消息，为推广自家应用，苹果现推出了一个名为“Apps by Apple”的网站，展示了苹果为旗下产品（如 iPhone、iPad、Apple Watch、Mac 和 Apple TV）开发的各种应用程序。
特斯拉本周在美国大幅下调Model S和X售价，引发了该公司一些最坚定支持者的不满。知名特斯拉多头、未来基金（Future Fund）管理合伙人加里·布莱克发帖称，降价是一种“短期麻醉剂”，会让潜在客户等待进一步降价。
据外媒9月2日报道，荷兰半导体设备制造商阿斯麦称，尽管荷兰政府颁布的半导体设备出口管制新规9月正式生效，但该公司已获得在2023年底以前向中国运送受限制芯片制造机器的许可。
近日，根据美国证券交易委员会的文件显示，苹果卫星服务提供商 Globalstar 近期向马斯克旗下的 SpaceX 支付 6400 万美元（约 4.65 亿元人民币）。用于在 2023-2025 年期间，发射卫星，进一步扩展苹果 iPhone 系列的 SOS 卫星服务。
据报道，马斯克旗下社交平台𝕏（推特）日前调整了隐私政策，允许 𝕏 使用用户发布的信息来训练其人工智能（AI）模型。新的隐私政策将于 9 月 29 日生效。新政策规定，𝕏可能会使用所收集到的平台信息和公开可用的信息，来帮助训练 𝕏 的机器学习或人工智能模型。
9月2日，荣耀CEO赵明在采访中谈及华为手机回归时表示，替老同事们高兴，觉得手机行业，由于华为的回归，让竞争充满了更多的可能性和更多的魅力，对行业来说也是件好事。
《自然》30日发表的一篇论文报道了一个名为Swift的人工智能（AI）系统，该系统驾驶无人机的能力可在真实世界中一对一冠军赛里战胜人类对手。
近日，非营利组织纽约真菌学会（NYMS）发出警告，表示亚马逊为代表的电商平台上，充斥着各种AI生成的蘑菇觅食科普书籍，其中存在诸多错误。
社交媒体平台𝕏（原推特）新隐私政策提到：“在您同意的情况下，我们可能出于安全、安保和身份识别目的收集和使用您的生物识别信息。”
2023年德国柏林消费电子展上，各大企业都带来了最新的理念和产品，而高端化、本土化的中国产品正在不断吸引欧洲等国际市场的目光。
罗永浩日前在直播中吐槽苹果即将推出的 iPhone 新品，具体内容为：“以我对我‘子公司’的了解，我认为 iPhone 15 跟 iPhone 14 不会有什么区别的，除了序（列）号变了，这个‘不要脸’的东西，这个‘臭厨子’。
