hashicorp raft 源码走读 1

上文讲到如何基于 hashicorp[1] raft 构建分布式 kv 存储。那么我们读一下源码，具体看如何实现 raft, 如何对应论文中提到的几个问题与优化。先看 leader election

整体架构

还是上文的图，除了 fsm 需要用户实现，其它都由 hashicorp 提供，完全开箱即用的产品。接下来我们带着论文描述的问题，来阅读一下源码实现

结构体

我其实很讨厌分析源码，上来就拿出结构体一顿乱讲，很烦 :( 好在不太多... 读过论文的都会熟悉

// Log entries are replicated to all members of the Raft cluster
// and form the heart of the replicated state machine.
type Log struct {
 // Index holds the index of the log entry.
 Index uint64
 // Term holds the election term of the log entry.
 Term uint64
 // Type holds the type of the log entry.
 Type LogType
 // Data holds the log entry's type-specific data.
 Data []byte
}

Log 结构体代表日志里的一个 entry, Index 是索引号，Term 代表当前产生日志时的 leader 任期，Type 是日志类别，表示 Data 具体是做什么的，比如成员变更，或是用户产生的。

type RequestVoteRequest struct {
 // Provide the term and our id
 Term      uint64
 Candidate []byte
 // Used to ensure safety
 LastLogIndex uint64
 LastLogTerm  uint64
 // Used to indicate to peers if this vote was triggered by a leadership
 // transfer. It is required for leadership transfer to work, because servers
 // wouldn't vote otherwise if they are aware of an existing leader.
 LeadershipTransfer bool
}

// RequestVoteResponse is the response returned from a RequestVoteRequest.
type RequestVoteResponse struct {
 // Newer term if leader is out of date.
 Term uint64
 // Peers is deprecated, but required by servers that only understand
 // protocol version 0. This is not populated in protocol version 2
 // and later.
 Peers []byte
 // Is the vote granted.
 Granted bool
}

一起看一下 RequestVote 请求的 req 和 resp

1. Term 与 Candidate 是当前发起选举的任期和唯一标识
2. LastLogIndex, LastLogTerm 表示 candidate 拥有最新的日志 index 与 term
3. LeadershipTransfer 表示是否是强制转移 leader, 因为 follower 已有 leader 的时候是不会投票的，只有 leader 能发起强制转移
4. resp 如果同意，那么 Granted 为 true. 另外如果节点的 term 比这个 candidate 大，也会同时返回最新的 term

通信 Transport

hashicorp 提供了 Transport 接口，只要符合的都可以传输数据，比如我们常用的 TCPTransport. 对外提供两个功能：

1. 调用函数 AppendEntries 发送日志, RequestVote 发起选举, InstallSnapshot 安装发送快照，还有其它函数
2. 对外提供 RPC channel, 打通 raft 与底层 transport 交互通道

通过 NewTCPTransport 会创建一个基于 tcp 的传输层，如上图所示，数据使用 MsgPack 编解码，同时启动一个异步监听端口的 trans.listen 函数

// listen is used to handling incoming connections.
func (n *NetworkTransport) listen() {
 const baseDelay = 5 * time.Millisecond
 const maxDelay = 1 * time.Second
 var loopDelay time.Duration
 for {
  // Accept incoming connections
  conn, err := n.stream.Accept()
  ......
  n.logger.Debug("accepted connection", "local-address", n.LocalAddr(), "remote-address", conn.RemoteAddr().String())
  // Handle the connection in dedicated routine
  go n.handleConn(n.getStreamContext(), conn)
 }
}

每当创建一个连接，都会新启动 goroutine handleConn 来处理请求

func (n *NetworkTransport) handleConn(connCtx context.Context, conn net.Conn) {
 defer conn.Close()
 r := bufio.NewReader(conn)
 w := bufio.NewWriter(conn)
 dec := codec.NewDecoder(r, &codec.MsgpackHandle{})
 enc := codec.NewEncoder(w, &codec.MsgpackHandle{})

 for {
  select {
  case <-connCtx.Done():
   n.logger.Debug("stream layer is closed")
   return
  default:
  }

  if err := n.handleCommand(r, dec, enc); err != nil {
   if err != io.EOF {
    n.logger.Error("failed to decode incoming command", "error", err)
   }
   return
  }
  if err := w.Flush(); err != nil {
   n.logger.Error("failed to flush response", "error", err)
   return
  }
 }
}

1. 对 conn 网络连接封装编解码，MsgPack, 市面上其它的 raft 实现都使用 pb
2. handleCommand 具体的处理单个请求，最后调用 Flush 把数据刷到网络发送出去

// handleCommand is used to decode and dispatch a single command.
func (n *NetworkTransport) handleCommand(r *bufio.Reader, dec *codec.Decoder, enc *codec.Encoder) error {
 // Get the rpc type
 rpcType, err := r.ReadByte()
 if err != nil {
  return err
 }

 // Create the RPC object
 respCh := make(chan RPCResponse, 1)
 rpc := RPC{
  RespChan: respCh,
 }

 // Decode the command
 isHeartbeat := false
 switch rpcType {
 case rpcAppendEntries:
  var req AppendEntriesRequest
  if err := dec.Decode(&req); err != nil {
   return err
  }
  rpc.Command = &req

  // Check if this is a heartbeat
  if req.Term != 0 && req.Leader != nil &&
   req.PrevLogEntry == 0 && req.PrevLogTerm == 0 &&
   len(req.Entries) == 0 && req.LeaderCommitIndex == 0 {
   isHeartbeat = true
  }

 case rpcRequestVote:
  var req RequestVoteRequest
  if err := dec.Decode(&req); err != nil {
   return err
  }
  rpc.Command = &req

 case rpcInstallSnapshot:
  var req InstallSnapshotRequest
  if err := dec.Decode(&req); err != nil {
   return err
  }
  rpc.Command = &req
  rpc.Reader = io.LimitReader(r, req.Size)

 case rpcTimeoutNow:
  var req TimeoutNowRequest
  if err := dec.Decode(&req); err != nil {
   return err
  }
  rpc.Command = &req

 default:
  return fmt.Errorf("unknown rpc type %d", rpcType)
 }
 // Check for heartbeat fast-path
 if isHeartbeat {
  n.heartbeatFnLock.Lock()
  fn := n.heartbeatFn
  n.heartbeatFnLock.Unlock()
  if fn != nil {
   fn(rpc)
   goto RESP
  }
 }

 // Dispatch the RPC
 select {
 case n.consumeCh <- rpc:
 case <-n.shutdownCh:
  return ErrTransportShutdown
 }

 // Wait for response
RESP:
 select {
 case resp := <-respCh:
  // Send the error first
  respErr := ""
  if resp.Error != nil {
   respErr = resp.Error.Error()
  }
  if err := enc.Encode(respErr); err != nil {
   return err
  }

  // Send the response
  if err := enc.Encode(resp.Response); err != nil {
   return err
  }
 case <-n.shutdownCh:
  return ErrTransportShutdown
 }
 return nil
}

1. 首先读一个 byte, 表示接下来的数据是什么类型 rpcType
2. 根据不同类型解码成不同的结构体 rpcAppendEntries, rpcRequestVote, rpcInstallSnapshot, rpcTimeoutNow, 并封装成 RPC 结构体
3. 将 RPC 请求结构体发送到 n.consumeCh 供上层 raft 模块调用
4. 另外如果是心跳包的话，那么调用 heartbeatFn 回调快速响应
5. 阻塞读 respCh, 最后上面 raft 模块将返回数据写到 RPC.respCh channel 里，handleCommand 把数据 Encode 编码到 conn 刷新数据写到网络

至此，Transport 模块分析完，只需要记住暴露了 n.consumeCh 供 raft 模块读请求即可。至于如何写数据呢，稍后再讲。

选举 Election

raft 有三种角色，leader, candidate, follower 上图是转换状态机，如果收不到 leader 的心跳，follower 就会变成 candidate 发起选举

1. candidate 发起选举

NewRaft 创建时会启动三个 goroutine: run, runFSM, runSnapshots 分别运行 raft, fsm apply 和 快照。我们此时只需关心 run 函数。

// run is a long running goroutine that runs the Raft FSM.
func (r *Raft) run() {
 for {
  // Check if we are doing a shutdown
  select {
  ......
  // Enter into a sub-FSM
  switch r.getState() {
  case Follower:
   r.runFollower()
  case Candidate:
   r.runCandidate()
  case Leader:
   r.runLeader()
  }
 }
}

run 函数其实是一个死循环，根据状态运行不同的角色函数，我们先来看一下 follower 如何触发选举

// runFollower runs the FSM for a follower.
func (r *Raft) runFollower() {
 didWarn := false
 r.logger.Info("entering follower state", "follower", r, "leader", r.Leader())
 metrics.IncrCounter([]string{"raft", "state", "follower"}, 1)
 heartbeatTimer := randomTimeout(r.conf.HeartbeatTimeout)

 for r.getState() == Follower {
  select {
  ......
  case <-heartbeatTimer:
   // Restart the heartbeat timer
   heartbeatTimer = randomTimeout(r.conf.HeartbeatTimeout)

   // Check if we have had a successful contact
   lastContact := r.LastContact()
   if time.Now().Sub(lastContact) < r.conf.HeartbeatTimeout {
    continue
   }

   // Heartbeat failed! Transition to the candidate state
   lastLeader := r.Leader()
   r.setLeader("")
  ......
    r.logger.Warn("heartbeat timeout reached, starting election", "last-leader", lastLeader)
    metrics.IncrCounter([]string{"raft", "transition", "heartbeat_timeout"}, 1)
    r.setState(Candidate)
    return
   }
  }
 }
}

忽略其它 case 分支，当 heartbeatTimer 超时到期后，判断 lastContact 与 leader 上一次通信的时间，过长的话认为心跳失败。经过简单判断后，将状态设置成 Candidate，返回后 run 继续根据状态来运行 runCandidate 函数

// runCandidate runs the FSM for a candidate.
func (r *Raft) runCandidate() {
 r.logger.Info("entering candidate state", "node", r, "term", r.getCurrentTerm()+1)
 metrics.IncrCounter([]string{"raft", "state", "candidate"}, 1)

 // Start vote for us, and set a timeout
 voteCh := r.electSelf()

 // Make sure the leadership transfer flag is reset after each run. Having this
 // flag will set the field LeadershipTransfer in a RequestVoteRequst to true,
 // which will make other servers vote even though they have a leader already.
 // It is important to reset that flag, because this priviledge could be abused
 // otherwise.
 defer func() { r.candidateFromLeadershipTransfer = false }()

 electionTimer := randomTimeout(r.conf.ElectionTimeout)

 // Tally the votes, need a simple majority
 grantedVotes := 0
 votesNeeded := r.quorumSize()
 r.logger.Debug("votes", "needed", votesNeeded)

 for r.getState() == Candidate {
  select {
  case rpc := <-r.rpcCh:
   r.processRPC(rpc)

  case vote := <-voteCh:
   // Check if the term is greater than ours, bail
   if vote.Term > r.getCurrentTerm() {
    r.logger.Debug("newer term discovered, fallback to follower")
    r.setState(Follower)
    r.setCurrentTerm(vote.Term)
    return
   }

   // Check if the vote is granted
   if vote.Granted {
    grantedVotes++
    r.logger.Debug("vote granted", "from", vote.voterID, "term", vote.Term, "tally", grantedVotes)
   }

   // Check if we've become the leader
   if grantedVotes >= votesNeeded {
    r.logger.Info("election won", "tally", grantedVotes)
    r.setState(Leader)
    r.setLeader(r.localAddr)
    return
   }
  ......
  case <-electionTimer:
   // Election failed! Restart the election. We simply return,
   // which will kick us back into runCandidate
   r.logger.Warn("Election timeout reached, restarting election")
   return

  case <-r.shutdownCh:
   return
  }
 }
}

1. 首先 electSelf 给自己投票，并且并行的将 RequestVote 发送给集群中所有其它节点
2. processRPC 正常的接收 rpc 请求，如果是 leader 发来的，那么当前节点要退出 Candidate 状态，变为 follower
3. 从 voteCh 里收到投票结果，如果达到 quorumSize 那么成功当选 leader
4. 最后如果出现了 split vote 情况，那么 electionTimer 选举超时，重新触发一次选举

func (r *Raft) electSelf() <-chan *voteResult {
 // Create a response channel
 respCh := make(chan *voteResult, len(r.configurations.latest.Servers))

 // Increment the term
 r.setCurrentTerm(r.getCurrentTerm() + 1)

 // Construct the request
 lastIdx, lastTerm := r.getLastEntry()
 req := &RequestVoteRequest{
  RPCHeader:          r.getRPCHeader(),
  Term:               r.getCurrentTerm(),
  Candidate:          r.trans.EncodePeer(r.localID, r.localAddr),
  LastLogIndex:       lastIdx,
  LastLogTerm:        lastTerm,
  LeadershipTransfer: r.candidateFromLeadershipTransfer,
 }

 // Construct a function to ask for a vote
 askPeer := func(peer Server) {
  r.goFunc(func() {
   defer metrics.MeasureSince([]string{"raft", "candidate", "electSelf"}, time.Now())
   resp := &voteResult{voterID: peer.ID}
   err := r.trans.RequestVote(peer.ID, peer.Address, req, &resp.RequestVoteResponse)
   if err != nil {
    r.logger.Error("failed to make requestVote RPC",
     "target", peer,
     "error", err)
    resp.Term = req.Term
    resp.Granted = false
   }
   respCh <- resp
  })
 }

 // For each peer, request a vote
 for _, server := range r.configurations.latest.Servers {
  if server.Suffrage == Voter {
   if server.ID == r.localID {
    // Persist a vote for ourselves
    if err := r.persistVote(req.Term, req.Candidate); err != nil {
     r.logger.Error("failed to persist vote", "error", err)
     return nil
    }
    // Include our own vote
    respCh <- &voteResult{
     RequestVoteResponse: RequestVoteResponse{
      RPCHeader: r.getRPCHeader(),
      Term:      req.Term,
      Granted:   true,
     },
     voterID: r.localID,
    }
   } else {
    askPeer(server)
   }
  }
 }

 return respCh
}

我们来看一下 candidate 如何发起选举请求

1. 构建 RequestVoteRequest 请求，term ++, 填充 LastLogIndex, LastLogTerm
2. askPeer 通过 transport 广播 RequestVote 给其它节点

2. 其它节点接收 vote

其它节点通过 processRPC 来处理 rpc 请求，对应于 requestVote 函数

// requestVote is invoked when we get an request vote RPC call.
func (r *Raft) requestVote(rpc RPC, req *RequestVoteRequest) {
 defer metrics.MeasureSince([]string{"raft", "rpc", "requestVote"}, time.Now())
 r.observe(*req)

 // Setup a response
 resp := &RequestVoteResponse{
  RPCHeader: r.getRPCHeader(),
  Term:      r.getCurrentTerm(),
  Granted:   false,
 }

  ......

 // Check if we have an existing leader [who's not the candidate] and also
 // check the LeadershipTransfer flag is set. Usually votes are rejected if
 // there is a known leader. But if the leader initiated a leadership transfer,
 // vote!
 candidate := r.trans.DecodePeer(req.Candidate)
 if leader := r.Leader(); leader != "" && leader != candidate && !req.LeadershipTransfer {
  r.logger.Warn("rejecting vote request since we have a leader",
   "from", candidate,
   "leader", leader)
  return
 }

 // Ignore an older term
 if req.Term < r.getCurrentTerm() {
  return
 }

 // Increase the term if we see a newer one
 if req.Term > r.getCurrentTerm() {
  // Ensure transition to follower
  r.logger.Debug("lost leadership because received a requestVote with a newer term")
  r.setState(Follower)
  r.setCurrentTerm(req.Term)
  resp.Term = req.Term
 }

 // Check if we have voted yet
 lastVoteTerm, err := r.stable.GetUint64(keyLastVoteTerm)
 if err != nil && err.Error() != "not found" {
  r.logger.Error("failed to get last vote term", "error", err)
  return
 }
 lastVoteCandBytes, err := r.stable.Get(keyLastVoteCand)
 if err != nil && err.Error() != "not found" {
  r.logger.Error("failed to get last vote candidate", "error", err)
  return
 }

 // Check if we've voted in this election before
 if lastVoteTerm == req.Term && lastVoteCandBytes != nil {
  r.logger.Info("duplicate requestVote for same term", "term", req.Term)
  if bytes.Compare(lastVoteCandBytes, req.Candidate) == 0 {
   r.logger.Warn("duplicate requestVote from", "candidate", candidate)
   resp.Granted = true
  }
  return
 }

 // Reject if their term is older
 lastIdx, lastTerm := r.getLastEntry()
 if lastTerm > req.LastLogTerm {
  r.logger.Warn("rejecting vote request since our last term is greater",
   "candidate", candidate,
   "last-term", lastTerm,
   "last-candidate-term", req.LastLogTerm)
  return
 }

 if lastTerm == req.LastLogTerm && lastIdx > req.LastLogIndex {
  r.logger.Warn("rejecting vote request since our last index is greater",
   "candidate", candidate,
   "last-index", lastIdx,
   "last-candidate-index", req.LastLogIndex)
  return
 }

 // Persist a vote for safety
 if err := r.persistVote(req.Term, req.Candidate); err != nil {
  r.logger.Error("failed to persist vote", "error", err)
  return
 }

 resp.Granted = true
 r.setLastContact()
 return
}

1. 如果己知有 leader 节点了，并且未设置 LeadershipTransfer 那么拒绝
2. 查看 lastVoteTerm, lastVoteCandBytes 检查本次 term 内是否己经投完票了，raft paper 要求一个 term 内对一个节点只能投票一次
3. 如果 term 大于请求节点的 LastLogTerm, 拒绝
4. 如果 term 相等，lastIdx 大于请求节点的 LastLogIndex, 拒绝
5. persistVote 将投票结果持久化，最后 Granted 设为 true, 设置 lastContact 后返回

小结

这次分享就这些，以后面还会分享更多 etcd 与 raft 的内容。

参考资料

[1]hashicorp raft: https://github.com/hashicorp/raft,

本文由哈喽比特于3年以前收录，如有侵权请联系我们。
文章来源：https://mp.weixin.qq.com/s/yOBBMG2bKaSACjleEWklMA
