一引言

一篇有关Windows VPN代理技术分享，并不讨论VPN方案和隧道加密代理，而是NDIS小端数据包到应用层原理技术探讨分享。

个人Windows下用过两个OpenVpn驱动版本，tap-windows 5.0(Ndis 5.0)版本 <= win7，tap-windows 6.0(Ndis 6.0)版本 >= win8。

Jason Donenfeld并满意OpenVPN tap-Windows驱动，自研WireGuard Wintun代替tap-Windows的NDIS,后来减少r3r0上下文切换等优化，就有了WireGuard NT。

WirGuard口碑很不错，被Linux集成在了内核称艺术品。商用化方案越来越多使用WirGuard代替OpenVpn。r3也提供了高效开发，也不用关注驱动可以Go一把梭。

二源码

OpenVpn TapWin下载地址：https://github.com/OpenVPN/tap-windows6

WireGuard Nt下载地址：https://git.zx2c4.com/wireguard-nt/

三 Tap-windows：

tap-windows5.0用Wdk7600编译，tap-windows6.0高版本wdk编译，用两套xp~win7 tap-5.0支持比较友好，tap-Win 5.0高版本系统会有问题，具体的可以看Github中Issues。

这里并不是讲OpenVpn它本身如何做隧道的，而是通过假设代理方案举例：

初始化tap驱动，注册小端生成虚拟网卡。
应用层设置路由表和虚拟网卡，指定IP路由到虚拟网卡。
NDIS捕获完成IRP发送应用层，应用层拿到数据包Socket5或者私有代理。
代理回包应用层写回虚拟网卡。

Tap-windows5.0和6.0捕获数据包传输使用都是I/O，异步ReadFile/WriteFile MDL读写。这套方案做代理需要面对一些问题，NDIS提取网络层数据包应用层代理？

UDP处理稍微简单一些，TCP代理有点复杂，考虑TCP的每一个数据包(Wirshark抓到的一样)，包括握手挥手超时恢复等都要自己处理。

虽然有lWIP用来解决该问题，应用层帮你去维护阻塞控制、RTT、快速恢复转发等，最后通过IOCP或者Asio等框架转发链路数据至Server服务，BadVpn好像也是使的该方案。

数据包流动实现:

应用层：

初始化驱动以后，起线程异步读取发送ReadFile I/O：

for (i = 0; i < 8; i++)
{
    readBytes = 0;
    memset(&ol, 0, sizeof(ol));
    ol.hEvent = g_ioEvent;
    if (!ReadFile(hDevice, &rr, sizeof(rr), NULL, &ol))
    {
        if (GetLastError() != ERROR_IO_PENDING)
        {
            OutputDebugString(L"ReadFile Error!");
            goto finish;
        }
    }
    for (;;)
    {
        dwRes = WaitForMultipleObjects(
            sizeof(events) / sizeof(events[0]),
            events,
            FALSE,
            waitTimeout);
    ......
    }
    ......
}

内核层:

驱动接收应用层发来的I/O，先把Read IRP Pending，AdapterCreate->CreateTapDevice->TapDeviceRead(IRP_MJ_READ),尝试拉取AdapterSendNetBufferLists捕获的数据包副本，如果有的话完成I/O反馈。


IoCsqInsertIrp(&adapter->PendingReadIrpQueue.CsqQueue, Irp, NULL);
tapProcessSendPacketQueue(adapter);
ntStatus = STATUS_PENDING;

另一种写法Read I/O只负责Pendig IRP存入链表，Event来唤醒单独的内核线程尝试拉取副本完成IRP。

IoMarkIrpPending(irp);
InsertTailList(&g_pendedIoRequests, &irp->Tail.Overlay.ListEntry);
status = STATUS_PENDING;
KeSetEvent(&ThreadEvent, IO_NO_INCREMENT, FALSE);

AdapterSendNetBufferLists判断是否打开tap和已就绪，NdisDeviceStateD0是网络适配发出的电源状态，表示电源管理已准备就绪并且已激活,case里面过滤初始化和适配器不指示接收的情况。

` ` `
if(adapter->TapFileObject == NULL)
{
    //
    // Complete all NBLs and return if adapter not ready.
    //
    tapSendNetBufferListsComplete(
        adapter,
        NetBufferLists,
        NDIS_STATUS_SUCCESS,
        DispatchLevel
        );

    return;
}
if(!Adapter->LogicalMediaState)
{
    status = NDIS_STATUS_MEDIA_DISCONNECTED;
}
else if(Adapter->CurrentPowerState != NdisDeviceStateD0)
{
    status = NDIS_STATUS_LOW_POWER_STATE;
}
else if(Adapter->ResetInProgress)
{
    status = NDIS_STATUS_RESET_IN_PROGRESS;
}
else
{
    switch(Adapter->Locked.AdapterState)
    {
    case MiniportPausingState:
    case MiniportPausedState:
        status = NDIS_STATUS_PAUSED;
        break;

    case MiniportHaltedState:
        status = NDIS_STATUS_INVALID_STATE;
        break;

    default:
        status = NDIS_STATUS_SUCCESS;
        break;
    }
}
` ` `

检测Net_Buf大小范围，大于等于以太网帧头大小(64byte)+IP头大小(20byte)，最大不能超以太网报头+MTU(MAX 1500)+VLAN。


// Minimum packet size is size of Ethernet plus IPv4 headers.
ASSERT(packetLength >= (ETHERNET_HEADER_SIZE + IP_HEADER_SIZE));

if(packetLength < (ETHERNET_HEADER_SIZE + IP_HEADER_SIZE))
{
    return FALSE;
}

// Maximum size should be Ethernet header size plus MTU plus modest pad for
// VLAN tag.
ASSERT( packetLength <= (ETHERNET_HEADER_SIZE + VLAN_TAG_SIZE + Adapter->MtuSize));

if(packetLength > (ETHERNET_HEADER_SIZE + VLAN_TAG_SIZE + Adapter->MtuSize))
{
    return FALSE;
}

接下来对多种协议处理，拷贝完整的数据包到副本，插入PacketQueue传输队列。接下来和步骤1中完成IRP调用函数一致，IoCompleteRequest完成pending IRP，将数据反馈至应用层。

ETH_HEADR大小是 6 + 6 + 2 = 14byte


#define MACADDR_SIZE    6
typedef unsigned char MACADDR[MACADDR_SIZE];
typedef struct
{
    MACADDR dest;               /* destination eth addr    */
    MACADDR src;                /* source ether addr    */
    USHORT proto;               /* packet type ID field    */
} ETH_HEADER, *PETH_HEADER;

Proto这里处理类型如下：


#define NDIS_ETH_TYPE_IPV4              0x0800  // IPV4
#define NDIS_ETH_TYPE_ARP               0x0806  // ARP
#define NDIS_ETH_TYPE_IPV6              0x86dd  // IPV6

DHCP在哪里设置标志的？TAP_WIN_IOCTL_CONFIG_DHCP_MASQ

case TAP_WIN_IOCTL_CONFIG_DHCP_MASQ:
    {
        if(inBufLength >= sizeof(IPADDR)*4)
        {
            adapter->m_dhcp_enabled = FALSE;
            adapter->m_dhcp_server_arp = FALSE;
            adapter->m_dhcp_user_supplied_options_buffer_len = 0;

            // Adapter IP addr / netmask
            adapter->m_dhcp_addr =
                ((IPADDR*) (Irp->AssociatedIrp.SystemBuffer))[0];
            adapter->m_dhcp_netmask =
                ((IPADDR*) (Irp->AssociatedIrp.SystemBuffer))[1];

            // IP addr of DHCP masq server
            adapter->m_dhcp_server_ip =
                ((IPADDR*) (Irp->AssociatedIrp.SystemBuffer))[2];

            // Lease time in seconds
            adapter->m_dhcp_lease_time =
                ((IPADDR*) (Irp->AssociatedIrp.SystemBuffer))[3];

            GenerateRelatedMAC(
                adapter->m_dhcp_server_mac,
                adapter->CurrentAddress,
                2
                );

            adapter->m_dhcp_enabled = TRUE;
            adapter->m_dhcp_server_arp = TRUE;

            CheckIfDhcpAndTunMode (adapter);

            Irp->IoStatus.Information = 1; // Simple boolean value

            DEBUGP (("[Boom] Configured DHCP MASQ.\n"));
        }
        else
        {
            NOTE_ERROR();
            Irp->IoStatus.Status = ntStatus = STATUS_INVALID_PARAMETER;
        }
    }
    break;

AdapterSendNetBufferLists拷贝代码：


` ` `
// Allocate TAP packet memory
tapPacket = (PTAP_PACKET )NdisAllocateMemoryWithTagPriority(
                Adapter->MiniportAdapterHandle,
                TAP_PACKET_SIZE (packetLength+addHeaderSize),
                TAP_PACKET_TAG,
                NormalPoolPriority
                );
// 提取Buf数据
packetData = NdisGetDataBuffer(NetBuffer,packetLength,tapPacket->m_Data+addHeaderSize,1,0);

// 拷贝数据到tapPacket+addHeaderSize后的位置，预留出来addHeaderSize
if(packetData != (tapPacket->m_Data+addHeaderSize))
{
    // Packet data was contiguous and not yet copied to m_Data.
    NdisMoveMemory(tapPacket->m_Data+addHeaderSize,packetData,packetLength);
}

// 填充addHeaderSize大小数据
if(addHeaderSize > 0)
{
    // Add an 802.1Q header between the ethernet header and the payload
    NdisMoveMemory(tapPacket->m_Data,tapPacket->m_Data+addHeaderSize,ETHERNET_HEADER_SIZE-2);
    PETH_HEADER header = (PETH_HEADER)tapPacket->m_Data;
    PETH_8021Q_HEADER tag = (PETH_8021Q_HEADER)(header+1);
    header->proto = htons(0x8100);
    USHORT tagValue = 0;
    tagValue |= packetPriority.TagHeader.UserPriority<<13;
    tagValue |= packetPriority.TagHeader.VlanId & 0xFFF;
    tag->Tag = tagValue;

    packetLength += addHeaderSize;
}

// DHCP的处理从数据链路层(ETH_HEADER) 到 网络层(IP_HDR) 到  UDPHDR(传输层) DHCP
......
const ETH_HEADER *eth = (ETH_HEADER *) tapPacket->m_Data;
const IPHDR *ip = (IPHDR *) (tapPacket->m_Data + sizeof (ETH_HEADER));
const UDPHDR *udp = (UDPHDR *) (tapPacket->m_Data + sizeof (ETH_HEADER) + sizeof (IPHDR));
......
else if (packetLength >= sizeof (ETH_HEADER) + sizeof (IPHDR) + sizeof (UDPHDR) + sizeof (DHCP)
&& eth->proto == htons (NDIS_ETH_TYPE_IPV4)
&& ip->version_len == 0x45 // IPv4, 20 byte header
&& ip->protocol == IPPROTO_UDP
&& udp->dest == htons (BOOTPS_PORT)
)
......

// 首先要从Ethernet->proto确认协议
ETH_HEADER *e;
e = (ETH_HEADER *) tapPacket->m_Data;
switch (ntohs (e->proto))

// ARP处理
if (packetLength != sizeof (ARP_PACKET))
{
    goto no_queue;
}

ProcessARP (
    Adapter,
    (PARP_PACKET) tapPacket->m_Data,
    Adapter->m_localIP,
    Adapter->m_remoteNetwork,
    Adapter->m_remoteNetmask,
    Adapter->m_TapToUser.dest
    );

// ipv4/ipv6处理
case NDIS_ETH_TYPE_IPV4:

    // Make sure that packet is large enough to be IPv4.
    if (packetLength < (ETHERNET_HEADER_SIZE + IP_HEADER_SIZE))
    {
        goto no_queue;
    }

    // Only accept directed packets, not broadcasts.
    if (memcmp (e, &Adapter->m_TapToUser, ETHERNET_HEADER_SIZE))
    {
        goto no_queue;
    }

    // Packet looks like IPv4, queue it. :-)
    tapPacket->m_SizeFlags |= TP_TUN;
    break;

case NDIS_ETH_TYPE_IPV6:
    // Make sure that packet is large enough to be IPv6.
    if (packetLength < (ETHERNET_HEADER_SIZE + IPV6_HEADER_SIZE))
    {
        goto no_queue;
    }

    // Broadcasts and multicasts are handled specially
    // (to be implemented)

    // Neighbor discovery packets to fe80::8 are special
    // OpenVPN sets this next-hop to signal "handled by tapdrv"
    if ( HandleIPv6NeighborDiscovery(Adapter,tapPacket->m_Data,
                                     packetLength) )
    {
        goto no_queue;
    }

    // Packet looks like IPv6, queue it. :-)
    tapPacket->m_SizeFlags |= TP_TUN;
}
` ` `

ipv6处理时候会检测fe80::xxx，这类的本地单播不处理，有可能是自动配置地址，邻居发现等等。


static IPV6ADDR IPV6_NS_TARGET_MCAST =
    { 0xff, 0x02, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00,
          0x00, 0x00, 0x00, 0x01, 0xff, 0x00, 0x00, 0x08 };
static IPV6ADDR IPV6_NS_TARGET_UNICAST =
    { 0xfe, 0x80, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00,
      0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x00, 0x08 };
if ( memcmp( ipv6->daddr, IPV6_NS_TARGET_MCAST,
    sizeof(IPV6ADDR) ) != 0 &&
    memcmp( ipv6->daddr, IPV6_NS_TARGET_UNICAST,
    sizeof(IPV6ADDR) ) != 0 )
{
    return FALSE;                // wrong target address
}

// ICMPv6 type+code must be 135/0 for NS
if ( icmpv6_ns->type != ICMPV6_TYPE_NS ||
    icmpv6_ns->code != ICMPV6_CODE_0 )
{
    return FALSE;                // wrong ICMPv6 type
}

// 需要计算和填充checksum
icmpv6_csum = icmpv6_checksum (
                (UCHAR*) &(na->icmpv6),
                icmpv6_len,
                na->ipv6.saddr,
                na->ipv6.daddr
                );

最后调用tapProcessSendPacketQueue完成。

应用层拿到数据包以后代理后，代理回包如何处理(recv)？这就和Write操作有关dispatchTable[IRP_MJ_WRITE] = TapDeviceWrite;

......
......
// 拿到应用层传递过来的数据包
unsigned char* packetBuffer = (unsigned char *) Irp->AssociatedIrp.SystemBuffer;
ULONG packetLength = irpSp->Parameters.Write.Length;
PVOID packetPriority = 0;

DUMP_PACKET ("IRP_MJ_WRITE ETH",
    packetBuffer,
    packetLength);

// 8021Q处理
packetPriority = TapStrip8021Q(&packetBuffer, &packetLength);

// 发送包到虚拟网卡
ntStatus = TapSharedSendPacket(
adapter,
Irp,
packetBuffer,
packetLength,
packetPriority,
NULL,
0
);

TapSharedSendPacket-


// 小于60byte拷贝副本在MDL映射到NetBufferList
// Copy packet data to flat buffer.
......
if(PrefixLength > 0)
{
    NdisMoveMemory(allocBuffer, PrefixData, PrefixLength);
}
NdisMoveMemory (allocBuffer + PrefixLength, PacketBuffer, PacketLength);
NdisZeroMemory(allocBuffer + fullLength, paddedLength - fullLength);
......
// 标记注入包
TAP_RX_NBL_FLAGS_CLEAR_ALL(netBufferList);
TAP_RX_NBL_FLAG_SET(netBufferList,TAP_RX_NBL_FLAGS_IS_INJECTED);

// 设置pending
IoMarkIrpPending(Irp);
IoSetCancelRoutine(Irp,NULL);

// Stash IRP pointer in NBL MiniportReserved[0] field.
netBufferList->MiniportReserved[0] = Irp;
netBufferList->MiniportReserved[1] = NULL;

NET_BUFFER_LIST_INFO(netBufferList, Ieee8021QNetBufferListInfo) = PacketPriority;

// Increment in-flight receive NBL count.
nblCount = NdisInterlockedIncrement(&Adapter->ReceiveNblInFlightCount);
ASSERT(nblCount > 0 );

//
// Indicate the packet
// -------------------
// This NBL contains the complete packet including Ethernet header and payload.
//
// 完整的数据调用ReceiveNet完成包
NdisMIndicateReceiveNetBufferLists(
    Adapter->MiniportAdapterHandle,
    netBufferList,
    NDIS_DEFAULT_PORT_NUMBER,
    1,      // NumberOfNetBufferLists
    0       // 清除所有标志
    );

// 注意返回标志是Pending
return STATUS_PENDING;

tap 5.0 Recv NBL实现和6.0有些异同，直接发送：

if (!l_Adapter->m_tun && ((l_IrpSp->Parameters.Write.Length) >= ETHERNET_HEADER_SIZE))
{
    ......
    NdisMEthIndicateReceive
    (l_Adapter->m_MiniportAdapterHandle,
        (NDIS_HANDLE)l_Adapter,
        (unsigned char*)p_IRP->AssociatedIrp.SystemBuffer,
        ETHERNET_HEADER_SIZE,
        (unsigned char*)p_IRP->AssociatedIrp.SystemBuffer + ETHERNET_HEADER_SIZE,
        l_IrpSp->Parameters.Write.Length - ETHERNET_HEADER_SIZE,
        l_IrpSp->Parameters.Write.Length - ETHERNET_HEADER_SIZE);
    NdisMEthIndicateReceiveComplete();
    p_IRP->IoStatus.Status = l_Status = STATUS_SUCCESS;
    ......
}
else if (l_Adapter->m_tun && ((l_IrpSp->Parameters.Write.Length) >= IP_HEADER_SIZE))
{
    ......
    if (IPH_GET_VER(((IPHDR*)p_IRP->AssociatedIrp.SystemBuffer)->version_len) == 6)
    {
        p_UserToTap = &l_Adapter->m_UserToTap_IPv6;
    }
    ......
    NdisMEthIndicateReceive
    (l_Adapter->m_MiniportAdapterHandle,
        (NDIS_HANDLE)l_Adapter,
        (unsigned char*)p_UserToTap,
        sizeof(ETH_HEADER),
        (unsigned char*)p_IRP->AssociatedIrp.SystemBuffer,
        l_IrpSp->Parameters.Write.Length,
        l_IrpSp->Parameters.Write.Length);

    NdisMEthIndicateReceiveComplete(l_Adapter->m_MiniportAdapterHandle);

    p_IRP->IoStatus.Status = l_Status = STATUS_SUCCESS;
    ......
}

NdisMIndicateReceiveNetBufferLists NDIS6.0或更高版本才可以使用，过程并不复杂，不过以前自己做NDIS轮子遇到不少麻烦，后来在做类似项目就直接用开源的驱动。

四 WireGuard NT:

这里并不是讲WirGuard NT本身如何做隧道的，而是通过假设代理方案举例：

初始化WireGuard驱动，注册小端生成虚拟网卡。
应用层设置路由表和虚拟网卡，指定IP路由到虚拟网卡。
NDIS捕获数据包，内核WSK代理双向连接。

WireGuard NT梳理基于SendNetBufferLists/ReturnNetBufferLists WSK UDP处理主线

数据包流动实现:

应用层:

两个阶段：

第一个是通过WireGuardSetConfiguration-->DevIceIoControl WG_IOCTL_SET 发送 WIREGUARD_INTERFACE_HAS_PRIVATE_KEY,这个不做讨论。

第二个是通过WireGuardSetAdapterState-->DevIceIoControl WG_IOCTL_SET_ADAPTER_STATE 发送 WIREGUARD_ADAPTER_STATE_UP。


// WG_IOCTL_INTERFACE_HAS_LISTEN_PORT 初始化WSK
// WIREGUARD_INTERFACE_HAS_PRIVATE_KEY 初始化Key
// WireGuard首先要先发送key
struct
{
    WIREGUARD_INTERFACE Interface;
    WIREGUARD_PEER DemoServer;
    WIREGUARD_ALLOWED_IP AllV4;
} Config = { .Interface = { .Flags = WIREGUARD_INTERFACE_HAS_PRIVATE_KEY, .PeersCount = 1 },
             .DemoServer = { .Flags = WIREGUARD_PEER_HAS_PUBLIC_KEY | WIREGUARD_PEER_HAS_ENDPOINT,
                             .AllowedIPsCount = 1 },
             .AllV4 = { .AddressFamily = AF_INET } };
// 通过发送Key初始化
WIREGUARD_SET_CONFIGURATION_FUNC WireGuardSetConfiguration;
_Use_decl_annotations_
BOOL WINAPI
WireGuardSetConfiguration(WIREGUARD_ADAPTER *Adapter, const WIREGUARD_INTERFACE *Config, DWORD Bytes)
{
    HANDLE ControlFile = AdapterOpenDeviceObject(Adapter);
    if (ControlFile == INVALID_HANDLE_VALUE)
        return FALSE;
    if (!DeviceIoControl(ControlFile, WG_IOCTL_SET, NULL, 0, (VOID *)Config, Bytes, &Bytes, NULL))
    {
        DWORD LastError = GetLastError();
        CloseHandle(ControlFile);
        SetLastError(LastError);
        return FALSE;
    }
    CloseHandle(ControlFile);
    return TRUE;
}
// WireGuardSetAdapterState把WIREGUARD_ADAPTER_STATE_UP参数传递到内核
Log(WIREGUARD_LOG_INFO, L"Setting configuration and adapter up");
if (!WireGuardSetConfiguration(Adapter, &Config.Interface, sizeof(Config)) ||
    !WireGuardSetAdapterState(Adapter, WIREGUARD_ADAPTER_STATE_UP))
{
    LastError = LogError(L"Failed to set configuration and adapter up", GetLastError());
    goto cleanupAdapter;
}

内核层:

不关注Key初始化，接收到WIREGUARD_ADAPTER_STATE_UP(1) = WG_IOCTL_ADAPTER_STATE_UP。


// WIREGUARD_ADAPTER_STATE_UP内核处理
case WG_IOCTL_SET_ADAPTER_STATE:
    AdapterState(DeviceObject, Irp);
AdapterState{
    case WG_IOCTL_ADAPTER_STATE_UP:
        Irp->IoStatus.Status = Up(Wg);
}
WIREGUARD_ADAPTER_STATE_UP --> Up(Wg) --> SocketInit(Wg, Wg->IncomingPort);

// 上文说到也可以通过发送WG_IOCTL_INTERFACE_HAS_LISTEN_PORT来实现,他会执行以下代码
NTSTATUS Status;
if (IoctlInterface.Flags & WG_IOCTL_INTERFACE_HAS_LISTEN_PORT)
{
    Status = SetListenPort(Wg, IoctlInterface.ListenPort);
    if (!NT_SUCCESS(Status))
        goto cleanupLock;
}
WG_IOCTL_INTERFACE_HAS_LISTEN_PORT --> SetListenPort() --> SocketInit()

SocketInit函数初始化WSK, 创建UDP Socket，WireGuard本身隧道加密传输基于UDP，Win下也不列外。


// 初始化固定大小的SendCtx
Status = ExInitializeLookasideListEx(
    &SocketSendCtxCache, NULL, NULL, NonPagedPool, 0, sizeof(SOCKET_SEND_CTX), MEMORY_TAG, 0);

// 初始化/注册WSK_CLIENT_NPI
WSK_CLIENT_NPI WskClientNpi = { .Dispatch = &WskAppDispatchV1 };
Status = WskRegister(&WskClientNpi, &WskRegistration);

// 注册后要捕获WSK NPI(Network Programming Interface)
// WSK_INFINITE_WAIT就是要等待到WSK子系统准备好才可以
Status = WskCaptureProviderNPI(&WskRegistration, WSK_INFINITE_WAIT, &WskProviderNpi);
if (!NT_SUCCESS(Status))
    goto cleanupWskRegister;

// 成功连接WSK子系统后，WSK_TRANSPORT_LIST_QUERY 检索可用的传输列表
Status = WskProviderNpi.Dispatch->WskControlClient(
    WskProviderNpi.Client,
    WSK_TRANSPORT_LIST_QUERY,
    0,
    NULL,
    WskTransportsSize,
    WskTransports,
    &WskTransportsSize,
    NULL);

for (SIZE_T i = 0, n = WskTransportsSize / sizeof(*WskTransports); i < n; ++i)
{
    if (WskTransports[i].SocketType == SOCK_DGRAM && WskTransports[i].Protocol == IPPROTO_UDP)
    {
        if (WskTransports[i].AddressFamily == AF_UNSPEC)
        {
            WskHasIpv4Transport = TRUE;
            WskHasIpv6Transport = TRUE;
        }
        else if (WskTransports[i].AddressFamily == AF_INET)
            WskHasIpv4Transport = TRUE;
        else if (WskTransports[i].AddressFamily == AF_INET6)
            WskHasIpv6Transport = TRUE;
    }
}

// 所有套接字自动启动回调, 使用的参数WSK_EVENT_RECEIVE_FROM参数。
WSK_EVENT_CALLBACK_CONTROL WskEventCallbackControl = { .NpiId = &NPI_WSK_INTERFACE_ID,
                                                       .EventMask = WSK_EVENT_RECEIVE_FROM };
Status = WskProviderNpi.Dispatch->WskControlClient(
    WskProviderNpi.Client,
    WSK_SET_STATIC_EVENT_CALLBACKS,
    sizeof(WskEventCallbackControl),
    &WskEventCallbackControl,
    0,
    NULL,
    NULL,
    NULL);

Status = NotifyRouteChange2(AF_INET, RouteNotification, &RoutingGenerationV4, FALSE, &RouteNotifierV4);
if (!NT_SUCCESS(Status))
    goto cleanupWskProviderNPI;
Status = NotifyRouteChange2(AF_INET6, RouteNotification, &RoutingGenerationV6, FALSE, &RouteNotifierV6);
if (!NT_SUCCESS(Status))
    goto cleanupRouteNotifierV4;

// 更具体的参数See Msdn: https://docs.microsoft.com/en-us/windows-hardware/drivers/ddi/wsk/nc-wsk-pfn_wsk_control_client

上面说到Init过程使用WSK_EVENT_RECEIVE_FROM参数，它对应的回调事件WskReceiveFromEvent。


// 如果List支持v4
if (WskHasIpv4Transport)
{
    Status = CreateAndBindSocket(Wg, (SOCKADDR *)&Sa4, &New4);
    if (!NT_SUCCESS(Status))
        goto out;
}
// 如果List支持v6
if (WskHasIpv6Transport)
{
    Sa6.sin6_port = Sa4.sin_port;
    Status = CreateAndBindSocket(Wg, (SOCKADDR *)&Sa6, &New6);
    if (!NT_SUCCESS(Status))
    {
        CloseSocket(New4);
        New4 = NULL;
        if (Status == STATUS_ADDRESS_ALREADY_EXISTS && !Port && Retries++ < 100)
            goto retry;
        goto out;
    }
}

CreateAndBindSocket是WSK Create Bind的封装


// 默认是0.0.0.0和配置传递过来的Port
// 初始异步Event/Irp，Irp完成回调触发KeSetEvent Event
KeInitializeEvent(&Done, SynchronizationEvent, FALSE);
IoInitializeIrp(&I.Irp, sizeof(I.IrpBuffer), 1);
IoSetCompletionRoutine(&I.Irp, RaiseEventOnComplete, &Done, TRUE, TRUE, TRUE);
// Irp传递参数传递给了NPIDisPathch，WskReceiveFromEvent这个地方赋值了IPPROTO_UDP Receive回调函数
static CONST WSK_CLIENT_DATAGRAM_DISPATCH WskClientDatagramDispatch = { .WskReceiveFromEvent = Receive };
// 创建新UDP Socket：SOCK_DGRAM IPPROTO_UDP
Status = WskProviderNpi.Dispatch->WskSocket(
    WskProviderNpi.Client,
    Sa->sa_family,
    SOCK_DGRAM,
    IPPROTO_UDP,
    WSK_FLAG_DATAGRAM_SOCKET,
    Socket,
    &WskClientDatagramDispatch,
    Wg->SocketOwnerProcess,
    NULL,
    NULL,
    &I.Irp);

ULONG True = TRUE;
if (Sa->sa_family == AF_INET)
{
    // IP_PKTINFO允许启动/禁用v4  LPFN_WSARECVMSG(WSARecvMsg)返回数据包信息
    Status = SetSockOpt(Sock, IPPROTO_IP, IP_PKTINFO, &True, sizeof(True));
    if (!NT_SUCCESS(Status))
        goto cleanupSocket;
}
else if (Sa->sa_family == AF_INET6)
{
    Status = SetSockOpt(Sock, IPPROTO_IPV6, IPV6_V6ONLY, &True, sizeof(True));
    if (!NT_SUCCESS(Status))
        goto cleanupSocket;
    Status = SetSockOpt(Sock, IPPROTO_IPV6, IPV6_PKTINFO, &True, sizeof(True));
    if (!NT_SUCCESS(Status))
        goto cleanupSocket;
}
Status = ((WSK_PROVIDER_DATAGRAM_DISPATCH *)Sock->Dispatch)->WskBind(Sock, Sa, 0, &I.Irp);
Status = ((WSK_PROVIDER_DATAGRAM_DISPATCH *)Sock->Dispatch)->WskGetLocalAddress(Sock, Sa, &I.Irp);

Up()执行SocketInit后，接下来DeviceStart调用PacketSendStagedPackets，当然这个函数在SendNetBufferList里面也会调用，函数会针对有key和无key分别处理。

  ......
    Irql = RcuReadLock();
    Keypair = NoiseKeypairGet(RcuDereference(NOISE_KEYPAIR, Peer->Keypairs.CurrentKeypair));
    RcuReadUnlock(Irql);
    if (!Keypair)
        goto outNokey;
    // 有key 数据生产消费
    PeerGet(Keypair->Entry.Peer);
        _Analysis_assume_(NET_BUFFER_LIST_FIRST_NB(Packets.Head)); /* Checked in SendNetBufferLists(). */
    NET_BUFFER_LIST_KEYPAIR(Packets.Head) = Keypair;
    PacketCreateData(Peer, Packets.Head);

outNokey:
    // 无key
    ......
    ......
    }

PacketCreateData处理：


Ret = QueueEnqueuePerDeviceAndPeer(&Wg->EncryptQueue, &Peer->TxQueue, &Wg->EncryptThreads, First);
if (Ret == STATUS_PIPE_BROKEN)
{// 失败处理
    QueueEnqueuePerPeer(&Peer->Device->TxQueue, &Peer->TxSerialEntry, First, PACKET_STATE_DEAD);
    MulticoreWorkQueueBump(&Wg->EncryptThreads);
}
if (NT_SUCCESS(Ret) || Ret == STATUS_PIPE_BROKEN)
    return;

QueueEnqueuePerDeviceAndPeer 调用 QueueEnqueuePerDevice插入加密队列，PacketEncryptWorker线程处理NBL加密。

if (!QueueInsertPerPeer(PeerQueue, Nbl))
    return STATUS_BUFFER_TOO_SMALL;
/* Then we queue it up in the device queue, which consumes the
 * packet as soon as it can.
 */
// 排队消费数据包意思，就是加密处理掉这个数据包
if (!QueueEnqueuePerDevice(DeviceQueue, DeviceThreads, Nbl))
    return STATUS_PIPE_BROKEN;

PacketEncryptWorker线程负责NBL加密，算法chacha20 poly1305e, See Rfc：https://www.rfc-editor.org/rfc/rfc7539。


......
EncryptPacket --> ChaCha20Poly1305EncryptMdl
// 加密失败包状态会改变
State = PACKET_STATE_DEAD;
......
QueueEnqueuePerPeer(&Peer->Device->TxQueue, &Peer->TxSerialEntry, First, State);
ProcessPerPeerWork(&Wg->TxQueue);

ProcessPerPeerWork{
    PEER_SERIAL_ENTRY *Entry;
    while ((Entry = PeerSerialDequeue(WorkQueue)) != NULL)
        PeerSerialMaybeRetire(
            WorkQueue,
            Entry,
            PacketPeerTxWork(CONTAINING_RECORD(Entry, WG_PEER, TxSerialEntry), PEER_XMIT_PACKETS_PER_ROUND));
}

PacketPeerTxWork{
    // PacketCreateDataDone负责发送
    if (State == PACKET_STATE_CRYPTED)
        PacketCreateDataDone(Peer, First);
    else
        FreeSendNetBufferList(Peer->Device, First, 0);
}

PacketCreateDataDone {
    if (NT_SUCCESS(SocketSendNblsToPeer(Peer, First, &IsKeepalive)) && !IsKeepalive)
        TimersDataSent(Peer);
}


if (NT_SUCCESS(SocketSendNblsToPeer(Peer, First, &IsKeepalive)) && !IsKeepalive)
    TimersDataSent(Peer);

SocketSendNblsToPeer负责WSK发送处理。


PFN_WSK_SEND_MESSAGES WskSendMessages = ((WSK_PROVIDER_DATAGRAM_DISPATCH *)Socket->Sock->Dispatch)->WskSendMessages;
#if NTDDI_VERSION == NTDDI_WIN7
    if (NoWskSendMessages)
        WskSendMessages = PolyfilledWskSendMessages;
#endif
    Status = WskSendMessages(
        Socket->Sock,
        FirstWskBuf,
        0,
        (PSOCKADDR)&Peer->Endpoint.Addr,
        (ULONG)WSA_CMSGDATA_ALIGN(Peer->Endpoint.Cmsg.cmsg_len) + WSA_CMSG_SPACE(0),
        &Peer->Endpoint.Cmsg,
        &Ctx->Irp);

SendNetBufferLists这里它也叫做生产者，就是数据包捕获源，这里不再关注细节了，它还是会调用PacketSendStagedPackets(步骤5)。


......
......
while (NetBufferListQueueLength(&Peer->StagedPacketQueue) > MAX_STAGED_PACKETS)
{
    NET_BUFFER_LIST *NblToDiscard = NetBufferListDequeue(&Peer->StagedPacketQueue);
    _Analysis_assume_(NblToDiscard); /* NetBufferListQueueLength() > MAX_STAGED_PACKETS implies
                                        NetBufferListDequeue() returns a NBL. */
    NET_BUFFER_LIST_STATUS(NblToDiscard) = NDIS_STATUS_FAILURE;
    ++Wg->Statistics.ifOutDiscards;
    FreeSendNetBufferList(Wg, NblToDiscard, CompleteFlags | NDIS_SEND_COMPLETE_FLAGS_DISPATCH_LEVEL);
}
NetBufferListEnqueue(&Peer->StagedPacketQueue, Nbl);
KeReleaseSpinLock(&Peer->StagedPacketQueue.Lock, Irql);

PacketSendStagedPackets(Peer);
......
......

ReturnNetBufferLists里面处理比较简单，通过WSK回包。


for (NET_BUFFER_LIST *Nbl = First, *NextNbl; Nbl; Nbl = NextNbl)
{
    NextNbl = NET_BUFFER_LIST_NEXT_NBL(Nbl);
    NET_BUFFER_LIST_NEXT_NBL(Nbl) = NULL;
    WSK_DATAGRAM_INDICATION *DatagramIndication = NET_BUFFER_LIST_DATAGRAM_INDICATION(Nbl);
    SOCKET *Socket = (SOCKET *)DatagramIndication->Next;
    DatagramIndication->Next = NULL;
    ((WSK_PROVIDER_DATAGRAM_DISPATCH *)Socket->Sock->Dispatch)->WskRelease(Socket->Sock, DatagramIndication);
    MemFreeNetBufferList(Nbl);
    ExReleaseRundownProtection(&Socket->ItemsInFlight);
}

回包要经过PacketConsumeData-->PacketDecryptWorker线程解密，丢给PacketPeerRxWork调用NdisMIndicateReceiveNetBufferLists。


// PacketHandshakeRxWorker线程处理Recv调用NdisMIndicateReceiveNetBufferLists：
if (First)
    NdisMIndicateReceiveNetBufferLists(First->SourceHandle, First, NDIS_DEFAULT_PORT_NUMBER, NumNbls, 0);

关于Rcu使用，代码中以PeerGet()和PeerPut(Peer)一对，调用Put会调用回收函数KrefRelease()。另外初始化地方.InitializeHandlerEx = InitializeEx：


// 加密线程
Status = MulticoreWorkQueueInit(&Wg->EncryptThreads, PacketEncryptWorker);
if (!NT_SUCCESS(Status))
    goto cleanupHandshakeRxQueue;

// 解密线程
Status = MulticoreWorkQueueInit(&Wg->DecryptThreads, PacketDecryptWorker);
if (!NT_SUCCESS(Status))
    goto cleanupEncryptThreads;

// HANDSHAKE_TX_SEND的时候，调用PacketSendHandshakeInitiation
Status = MulticoreWorkQueueInit(&Wg->HandshakeTxThreads, PacketHandshakeTxWorker);
if (!NT_SUCCESS(Status))
    goto cleanupDecryptThreads;
PacketSendHandshakeInitiation{
    if (NoiseHandshakeCreateInitiation(&Packet, &Peer->Handshake))
    {
        CookieAddMacToPacket(&Packet, sizeof(Packet), Peer);
        TimersAnyAuthenticatedPacketTraversal(Peer);
        TimersAnyAuthenticatedPacketSent(Peer);
        WriteNoFence64(&Peer->LastSentHandshake, KeQueryInterruptTime());
        SocketSendBufferToPeer(Peer, &Packet, sizeof(Packet));
        TimersHandshakeInitiated(Peer);
    }
}
SocketSendBufferToPeer-->SocketResolvePeerEndpoint;

// PacketHandshakeRxWorker处理wsk recv
Status = MulticoreWorkQueueInit(&Wg->HandshakeRxThreads, PacketHandshakeRxWorker);
if (!NT_SUCCESS(Status))
    goto cleanupHandshakeTxThreads;
