上一篇文章中给大家分析了一下android系统启动之后调用PackageManagerService服务并解析系统特定目录，解析apk文件并安装的过程，这个安装过期实际上是没有图形界面的，底层调用的是我们平时比较熟悉的adb命令，那么我们平时安装apk文件的时候大部分是都过图形界面安装的，那么这种方式安装apk具体的流程是怎样的呢？
下面我们就来具体看一下apk的具体安装过程，相信大家都知道如果我们想在代码里执行apk的安装，那么一般都是这样：
Intent intent = new Intent(Intent.ACTION_VIEW);
intent.addFlags(Intent.FLAG_ACTIVITY_NEW_TASK);
intent.setDataAndType(Uri.parse("file://" + path),"application/vnd.android.package-archive");
context.startActivity(intent);这样，我们就会打开安装apk文件的程序并执行安装逻辑了，那么这段代码具体是打开那个activity呢？好吧，从这个问题开始，我们来解析apk的安装流程...
这里跟大姐简单介绍一下android的源码，平时我们使用的android.jar里面的java源码只是android系统源码的一部分，还有好多源码并没有打入到android.jar中，这里为大家推荐一个android源码的地址：https://github.com/android
里面根据android系统的不同模块包含了许多android模块的源码。
这里我们找到platform_packages_apps_packageinstaller库，这里面就是android系统安装程序的源码了。
这里我们找到其androidManifest.xml，然后我们来看一下其具体的定义：
<?xml version="1.0" encoding="utf-8"?>
<manifest xmlns:android="http://schemas.android.com/apk/res/android"
package="com.android.packageinstaller" coreApp="true">
<original-package android:name="com.android.packageinstaller" />
...
<application android:label="@string/app_name"
android:allowBackup="false"
android:theme="@style/Theme.DialogWhenLarge"
android:supportsRtl="true">
<activity android:name=".PackageInstallerActivity"
android:configChanges="orientation|keyboardHidden|screenSize"
android:excludeFromRecents="true">
<intent-filter>
<action android:name="android.intent.action.VIEW" />
<action android:name="android.intent.action.INSTALL_PACKAGE" />
<category android:name="android.intent.category.DEFAULT" />
<data android:scheme="file" />
<data android:mimeType="application/vnd.android.package-archive" />
</intent-filter>
<intent-filter>
<action android:name="android.intent.action.INSTALL_PACKAGE" />
<category android:name="android.intent.category.DEFAULT" />
<data android:scheme="file" />
<data android:scheme="package" />
</intent-filter>
<intent-filter>
<action android:name="android.content.pm.action.CONFIRM_PERMISSIONS" />
<category android:name="android.intent.category.DEFAULT" />
</intent-filter>
</activity>
<activity android:name=".InstallAppProgress"
android:configChanges="orientation|keyboardHidden|screenSize"
android:exported="false" />
<activity android:name=".UninstallerActivity"
android:configChanges="orientation|keyboardHidden|screenSize"
android:excludeFromRecents="true"
android:theme="@style/Theme.AlertDialogActivity">
<intent-filter android:priority="1">
<action android:name="android.intent.action.DELETE" />
<action android:name="android.intent.action.UNINSTALL_PACKAGE" />
<category android:name="android.intent.category.DEFAULT" />
<data android:scheme="package" />
</intent-filter>
</activity>
<activity android:name=".UninstallAppProgress"
android:configChanges="orientation|keyboardHidden|screenSize"
android:exported="false" />
<activity android:name=".permission.ui.GrantPermissionsActivity"
android:configChanges="orientation|keyboardHidden|screenSize"
android:excludeFromRecents="true"
android:theme="@style/GrantPermissions">
<intent-filter>
<action android:name="android.content.pm.action.REQUEST_PERMISSIONS" />
<category android:name="android.intent.category.DEFAULT" />
</intent-filter>
</activity>
<activity android:name=".permission.ui.ManagePermissionsActivity"
android:configChanges="orientation|keyboardHidden|screenSize"
android:excludeFromRecents="true"
android:label="@string/app_permissions"
android:theme="@style/Settings"
android:permission="android.permission.GRANT_RUNTIME_PERMISSIONS">
<intent-filter>
<action android:name="android.intent.action.MANAGE_PERMISSIONS" />
<action android:name="android.intent.action.MANAGE_APP_PERMISSIONS" />
<action android:name="android.intent.action.MANAGE_PERMISSION_APPS" />
<category android:name="android.intent.category.DEFAULT" />
</intent-filter>
</activity>
<activity android:name=".permission.ui.OverlayWarningDialog"
android:excludeFromRecents="true"
android:theme="@android:style/Theme.DeviceDefault.Light.Dialog.NoActionBar" />
<provider android:name=".wear.WearPackageIconProvider"
android:authorities="com.google.android.packageinstaller.wear.provider"
android:grantUriPermissions="true"
android:exported="true" />
<activity android:name=".permission.ui.wear.WarningConfirmationActivity"
android:permission="android.permission.GRANT_RUNTIME_PERMISSIONS"
android:theme="@style/Settings"/>
</application>
</manifest>好吧，这里我们大概看一下Activity的定义，这里我们重点看一下PackageInstallerActivity的定义：
<activity android:name=".PackageInstallerActivity"
android:configChanges="orientation|keyboardHidden|screenSize"
android:excludeFromRecents="true">
<intent-filter>
<action android:name="android.intent.action.VIEW" />
<action android:name="android.intent.action.INSTALL_PACKAGE" />
<category android:name="android.intent.category.DEFAULT" />
<data android:scheme="file" />
<data android:mimeType="application/vnd.android.package-archive" />
</intent-filter>
<intent-filter>
<action android:name="android.intent.action.INSTALL_PACKAGE" />
<category android:name="android.intent.category.DEFAULT" />
<data android:scheme="file" />
<data android:scheme="package" />
</intent-filter>
<intent-filter>
<action android:name="android.content.pm.action.CONFIRM_PERMISSIONS" />
<category android:name="android.intent.category.DEFAULT" />
</intent-filter>
</activity>恩？这里不就是我们刚刚定义的启动安装Apk activity的intent filter？好吧，所以说一开始我们调用的startActivity其实启动的就是PackageInstallerActivity，那么下面我们就看一下PackageInstellerActivity的具体实现：
@Override
protected void onCreate(Bundle icicle) {
super.onCreate(icicle);
mPm = getPackageManager();
mInstaller = mPm.getPackageInstaller();
mUserManager = (UserManager) getSystemService(Context.USER_SERVICE);
final Intent intent = getIntent();
if (PackageInstaller.ACTION_CONFIRM_PERMISSIONS.equals(intent.getAction())) {
final int sessionId = intent.getIntExtra(PackageInstaller.EXTRA_SESSION_ID, -1);
final PackageInstaller.SessionInfo info = mInstaller.getSessionInfo(sessionId);
if (info == null || !info.sealed || info.resolvedBaseCodePath == null) {
Log.w(TAG, "Session " + mSessionId + " in funky state; ignoring");
finish();
return;
}
mSessionId = sessionId;
mPackageURI = Uri.fromFile(new File(info.resolvedBaseCodePath));
mOriginatingURI = null;
mReferrerURI = null;
} else {
mSessionId = -1;
mPackageURI = intent.getData();
mOriginatingURI = intent.getParcelableExtra(Intent.EXTRA_ORIGINATING_URI);
mReferrerURI = intent.getParcelableExtra(Intent.EXTRA_REFERRER);
}
final boolean unknownSourcesAllowedByAdmin = isUnknownSourcesAllowedByAdmin();
final boolean unknownSourcesAllowedByUser = isUnknownSourcesEnabled();
boolean requestFromUnknownSource = isInstallRequestFromUnknownSource(intent);
mInstallFlowAnalytics = new InstallFlowAnalytics();
mInstallFlowAnalytics.setContext(this);
mInstallFlowAnalytics.setStartTimestampMillis(SystemClock.elapsedRealtime());
mInstallFlowAnalytics.setInstallsFromUnknownSourcesPermitted(unknownSourcesAllowedByAdmin
&& unknownSourcesAllowedByUser);
mInstallFlowAnalytics.setInstallRequestFromUnknownSource(requestFromUnknownSource);
mInstallFlowAnalytics.setVerifyAppsEnabled(isVerifyAppsEnabled());
mInstallFlowAnalytics.setAppVerifierInstalled(isAppVerifierInstalled());
mInstallFlowAnalytics.setPackageUri(mPackageURI.toString());
if (DeviceUtils.isWear(this)) {
showDialogInner(DLG_NOT_SUPPORTED_ON_WEAR);
mInstallFlowAnalytics.setFlowFinished(
InstallFlowAnalytics.RESULT_NOT_ALLOWED_ON_WEAR);
return;
}
final String scheme = mPackageURI.getScheme();
if (scheme != null && !"file".equals(scheme) && !"package".equals(scheme)) {
Log.w(TAG, "Unsupported scheme " + scheme);
setPmResult(PackageManager.INSTALL_FAILED_INVALID_URI);
mInstallFlowAnalytics.setFlowFinished(
InstallFlowAnalytics.RESULT_FAILED_UNSUPPORTED_SCHEME);
finish();
return;
}
final PackageUtil.AppSnippet as;
if ("package".equals(mPackageURI.getScheme())) {
mInstallFlowAnalytics.setFileUri(false);
try {
mPkgInfo = mPm.getPackageInfo(mPackageURI.getSchemeSpecificPart(),
PackageManager.GET_PERMISSIONS | PackageManager.GET_UNINSTALLED_PACKAGES);
} catch (NameNotFoundException e) {
}
if (mPkgInfo == null) {
Log.w(TAG, "Requested package " + mPackageURI.getScheme()
+ " not available. Discontinuing installation");
showDialogInner(DLG_PACKAGE_ERROR);
setPmResult(PackageManager.INSTALL_FAILED_INVALID_APK);
mInstallFlowAnalytics.setPackageInfoObtained();
mInstallFlowAnalytics.setFlowFinished(
InstallFlowAnalytics.RESULT_FAILED_PACKAGE_MISSING);
return;
}
as = new PackageUtil.AppSnippet(mPm.getApplicationLabel(mPkgInfo.applicationInfo),
mPm.getApplicationIcon(mPkgInfo.applicationInfo));
} else {
mInstallFlowAnalytics.setFileUri(true);
final File sourceFile = new File(mPackageURI.getPath());
PackageParser.Package parsed = PackageUtil.getPackageInfo(sourceFile);
// Check for parse errors
if (parsed == null) {
Log.w(TAG, "Parse error when parsing manifest. Discontinuing installation");
showDialogInner(DLG_PACKAGE_ERROR);
setPmResult(PackageManager.INSTALL_FAILED_INVALID_APK);
mInstallFlowAnalytics.setPackageInfoObtained();
mInstallFlowAnalytics.setFlowFinished(
InstallFlowAnalytics.RESULT_FAILED_TO_GET_PACKAGE_INFO);
return;
}
mPkgInfo = PackageParser.generatePackageInfo(parsed, null,
PackageManager.GET_PERMISSIONS, 0, 0, null,
new PackageUserState());
mPkgDigest = parsed.manifestDigest;
as = PackageUtil.getAppSnippet(this, mPkgInfo.applicationInfo, sourceFile);
}
mInstallFlowAnalytics.setPackageInfoObtained();
//set view
setContentView(R.layout.install_start);
mInstallConfirm = findViewById(R.id.install_confirm_panel);
mInstallConfirm.setVisibility(View.INVISIBLE);
PackageUtil.initSnippetForNewApp(this, as, R.id.app_snippet);
mOriginatingUid = getOriginatingUid(intent);
// Block the install attempt on the Unknown Sources setting if necessary.
if (!requestFromUnknownSource) {
initiateInstall();
return;
}
// If the admin prohibits it, or we're running in a managed profile, just show error
// and exit. Otherwise show an option to take the user to Settings to change the setting.
final boolean isManagedProfile = mUserManager.isManagedProfile();
if (!unknownSourcesAllowedByAdmin
|| (!unknownSourcesAllowedByUser && isManagedProfile)) {
showDialogInner(DLG_ADMIN_RESTRICTS_UNKNOWN_SOURCES);
mInstallFlowAnalytics.setFlowFinished(
InstallFlowAnalytics.RESULT_BLOCKED_BY_UNKNOWN_SOURCES_SETTING);
} else if (!unknownSourcesAllowedByUser) {
// Ask user to enable setting first
showDialogInner(DLG_UNKNOWN_SOURCES);
mInstallFlowAnalytics.setFlowFinished(
InstallFlowAnalytics.RESULT_BLOCKED_BY_UNKNOWN_SOURCES_SETTING);
} else {
initiateInstall();
}
}这里我们主要先看一下PackageInstallerActivity的onCreate方法：
@Override
protected void onCreate(Bundle icicle) {
super.onCreate(icicle);
mPm = getPackageManager();
mInstaller = mPm.getPackageInstaller();
mUserManager = (UserManager) getSystemService(Context.USER_SERVICE);
final Intent intent = getIntent();
if (PackageInstaller.ACTION_CONFIRM_PERMISSIONS.equals(intent.getAction())) {
final int sessionId = intent.getIntExtra(PackageInstaller.EXTRA_SESSION_ID, -1);
final PackageInstaller.SessionInfo info = mInstaller.getSessionInfo(sessionId);
if (info == null || !info.sealed || info.resolvedBaseCodePath == null) {
Log.w(TAG, "Session " + mSessionId + " in funky state; ignoring");
finish();
return;
}
mSessionId = sessionId;
mPackageURI = Uri.fromFile(new File(info.resolvedBaseCodePath));
mOriginatingURI = null;
mReferrerURI = null;
} else {
mSessionId = -1;
mPackageURI = intent.getData();
mOriginatingURI = intent.getParcelableExtra(Intent.EXTRA_ORIGINATING_URI);
mReferrerURI = intent.getParcelableExtra(Intent.EXTRA_REFERRER);
}
final boolean unknownSourcesAllowedByAdmin = isUnknownSourcesAllowedByAdmin();
final boolean unknownSourcesAllowedByUser = isUnknownSourcesEnabled();
boolean requestFromUnknownSource = isInstallRequestFromUnknownSource(intent);
mInstallFlowAnalytics = new InstallFlowAnalytics();
mInstallFlowAnalytics.setContext(this);
mInstallFlowAnalytics.setStartTimestampMillis(SystemClock.elapsedRealtime());
mInstallFlowAnalytics.setInstallsFromUnknownSourcesPermitted(unknownSourcesAllowedByAdmin
&& unknownSourcesAllowedByUser);
mInstallFlowAnalytics.setInstallRequestFromUnknownSource(requestFromUnknownSource);
mInstallFlowAnalytics.setVerifyAppsEnabled(isVerifyAppsEnabled());
mInstallFlowAnalytics.setAppVerifierInstalled(isAppVerifierInstalled());
mInstallFlowAnalytics.setPackageUri(mPackageURI.toString());
if (DeviceUtils.isWear(this)) {
showDialogInner(DLG_NOT_SUPPORTED_ON_WEAR);
mInstallFlowAnalytics.setFlowFinished(
InstallFlowAnalytics.RESULT_NOT_ALLOWED_ON_WEAR);
return;
}
final String scheme = mPackageURI.getScheme();
if (scheme != null && !"file".equals(scheme) && !"package".equals(scheme)) {
Log.w(TAG, "Unsupported scheme " + scheme);
setPmResult(PackageManager.INSTALL_FAILED_INVALID_URI);
mInstallFlowAnalytics.setFlowFinished(
InstallFlowAnalytics.RESULT_FAILED_UNSUPPORTED_SCHEME);
finish();
return;
}
final PackageUtil.AppSnippet as;
if ("package".equals(mPackageURI.getScheme())) {
mInstallFlowAnalytics.setFileUri(false);
try {
mPkgInfo = mPm.getPackageInfo(mPackageURI.getSchemeSpecificPart(),
PackageManager.GET_PERMISSIONS | PackageManager.GET_UNINSTALLED_PACKAGES);
} catch (NameNotFoundException e) {
}
if (mPkgInfo == null) {
Log.w(TAG, "Requested package " + mPackageURI.getScheme()
+ " not available. Discontinuing installation");
showDialogInner(DLG_PACKAGE_ERROR);
setPmResult(PackageManager.INSTALL_FAILED_INVALID_APK);
mInstallFlowAnalytics.setPackageInfoObtained();
mInstallFlowAnalytics.setFlowFinished(
InstallFlowAnalytics.RESULT_FAILED_PACKAGE_MISSING);
return;
}
as = new PackageUtil.AppSnippet(mPm.getApplicationLabel(mPkgInfo.applicationInfo),
mPm.getApplicationIcon(mPkgInfo.applicationInfo));
} else {
mInstallFlowAnalytics.setFileUri(true);
final File sourceFile = new File(mPackageURI.getPath());
PackageParser.Package parsed = PackageUtil.getPackageInfo(sourceFile);
// Check for parse errors
if (parsed == null) {
Log.w(TAG, "Parse error when parsing manifest. Discontinuing installation");
showDialogInner(DLG_PACKAGE_ERROR);
setPmResult(PackageManager.INSTALL_FAILED_INVALID_APK);
mInstallFlowAnalytics.setPackageInfoObtained();
mInstallFlowAnalytics.setFlowFinished(
InstallFlowAnalytics.RESULT_FAILED_TO_GET_PACKAGE_INFO);
return;
}
mPkgInfo = PackageParser.generatePackageInfo(parsed, null,
PackageManager.GET_PERMISSIONS, 0, 0, null,
new PackageUserState());
mPkgDigest = parsed.manifestDigest;
as = PackageUtil.getAppSnippet(this, mPkgInfo.applicationInfo, sourceFile);
}
mInstallFlowAnalytics.setPackageInfoObtained();
//set view
setContentView(R.layout.install_start);
mInstallConfirm = findViewById(R.id.install_confirm_panel);
mInstallConfirm.setVisibility(View.INVISIBLE);
PackageUtil.initSnippetForNewApp(this, as, R.id.app_snippet);
mOriginatingUid = getOriginatingUid(intent);
// Block the install attempt on the Unknown Sources setting if necessary.
if (!requestFromUnknownSource) {
initiateInstall();
return;
}
// If the admin prohibits it, or we're running in a managed profile, just show error
// and exit. Otherwise show an option to take the user to Settings to change the setting.
final boolean isManagedProfile = mUserManager.isManagedProfile();
if (!unknownSourcesAllowedByAdmin
|| (!unknownSourcesAllowedByUser && isManagedProfile)) {
showDialogInner(DLG_ADMIN_RESTRICTS_UNKNOWN_SOURCES);
mInstallFlowAnalytics.setFlowFinished(
InstallFlowAnalytics.RESULT_BLOCKED_BY_UNKNOWN_SOURCES_SETTING);
} else if (!unknownSourcesAllowedByUser) {
// Ask user to enable setting first
showDialogInner(DLG_UNKNOWN_SOURCES);
mInstallFlowAnalytics.setFlowFinished(
InstallFlowAnalytics.RESULT_BLOCKED_BY_UNKNOWN_SOURCES_SETTING);
} else {
initiateInstall();
}
}可以发现，在onCreate方法中，首先执行一些初始化操作，获取PackageManager和Installer、UserManager等对象，然后会根据当前Intent的信息最一些逻辑判断并弹出消息弹窗，我们可以看一下具体的消息弹窗类型：
private static final int DLG_BASE = 0;
private static final int DLG_UNKNOWN_SOURCES = DLG_BASE + 1;
private static final int DLG_PACKAGE_ERROR = DLG_BASE + 2;
private static final int DLG_OUT_OF_SPACE = DLG_BASE + 3;
private static final int DLG_INSTALL_ERROR = DLG_BASE + 4;
private static final int DLG_ALLOW_SOURCE = DLG_BASE + 5;
private static final int DLG_ADMIN_RESTRICTS_UNKNOWN_SOURCES = DLG_BASE + 6;
private static final int DLG_NOT_SUPPORTED_ON_WEAR = DLG_BASE + 7;可以发现当分析Intent对象的时候，如果可以得到这样几种结果：不知道apk的来源，package信息错误，存储空间不够，安装时报，来源正确，允许未知来源的apk文件，在wear上不支持等，这样根据不同的消息类型会弹出不同的消息弹窗：
@Override
public Dialog onCreateDialog(int id, Bundle bundle) {
switch (id) {
case DLG_UNKNOWN_SOURCES:
return new AlertDialog.Builder(this)
.setTitle(R.string.unknown_apps_dlg_title)
.setMessage(R.string.unknown_apps_dlg_text)
.setNegativeButton(R.string.cancel, new DialogInterface.OnClickListener() {
public void onClick(DialogInterface dialog, int which) {
Log.i(TAG, "Finishing off activity so that user can navigate to settings manually");
finish();
}})
.setPositiveButton(R.string.settings, new DialogInterface.OnClickListener() {
public void onClick(DialogInterface dialog, int which) {
Log.i(TAG, "Launching settings");
launchSecuritySettings();
}
})
.setOnCancelListener(this)
.create();
case DLG_ADMIN_RESTRICTS_UNKNOWN_SOURCES:
return new AlertDialog.Builder(this)
.setTitle(R.string.unknown_apps_dlg_title)
.setMessage(R.string.unknown_apps_admin_dlg_text)
.setPositiveButton(android.R.string.ok, new DialogInterface.OnClickListener() {
public void onClick(DialogInterface dialog, int which) {
finish();
}
})
.setOnCancelListener(this)
.create();
case DLG_PACKAGE_ERROR :
return new AlertDialog.Builder(this)
.setTitle(R.string.Parse_error_dlg_title)
.setMessage(R.string.Parse_error_dlg_text)
.setPositiveButton(R.string.ok, new DialogInterface.OnClickListener() {
public void onClick(DialogInterface dialog, int which) {
finish();
}
})
.setOnCancelListener(this)
.create();
case DLG_OUT_OF_SPACE:
// Guaranteed not to be null. will default to package name if not set by app
CharSequence appTitle = mPm.getApplicationLabel(mPkgInfo.applicationInfo);
String dlgText = getString(R.string.out_of_space_dlg_text,
appTitle.toString());
return new AlertDialog.Builder(this)
.setTitle(R.string.out_of_space_dlg_title)
.setMessage(dlgText)
.setPositiveButton(R.string.manage_applications, new DialogInterface.OnClickListener() {
public void onClick(DialogInterface dialog, int which) {
//launch manage applications
Intent intent = new Intent("android.intent.action.MANAGE_PACKAGE_STORAGE");
intent.setFlags(Intent.FLAG_ACTIVITY_NEW_TASK);
startActivity(intent);
finish();
}
})
.setNegativeButton(R.string.cancel, new DialogInterface.OnClickListener() {
public void onClick(DialogInterface dialog, int which) {
Log.i(TAG, "Canceling installation");
finish();
}
})
.setOnCancelListener(this)
.create();
case DLG_INSTALL_ERROR :
// Guaranteed not to be null. will default to package name if not set by app
CharSequence appTitle1 = mPm.getApplicationLabel(mPkgInfo.applicationInfo);
String dlgText1 = getString(R.string.install_failed_msg,
appTitle1.toString());
return new AlertDialog.Builder(this)
.setTitle(R.string.install_failed)
.setNeutralButton(R.string.ok, new DialogInterface.OnClickListener() {
public void onClick(DialogInterface dialog, int which) {
finish();
}
})
.setMessage(dlgText1)
.setOnCancelListener(this)
.create();
case DLG_ALLOW_SOURCE:
CharSequence appTitle2 = mPm.getApplicationLabel(mSourceInfo);
String dlgText2 = getString(R.string.allow_source_dlg_text,
appTitle2.toString());
return new AlertDialog.Builder(this)
.setTitle(R.string.allow_source_dlg_title)
.setMessage(dlgText2)
.setNegativeButton(R.string.cancel, new DialogInterface.OnClickListener() {
public void onClick(DialogInterface dialog, int which) {
setResult(RESULT_CANCELED);
finish();
}})
.setPositiveButton(R.string.ok, new DialogInterface.OnClickListener() {
public void onClick(DialogInterface dialog, int which) {
SharedPreferences prefs = getSharedPreferences(PREFS_ALLOWED_SOURCES,
Context.MODE_PRIVATE);
prefs.edit().putBoolean(mSourceInfo.packageName, true).apply();
startInstallConfirm();
}
})
.setOnCancelListener(this)
.create();
case DLG_NOT_SUPPORTED_ON_WEAR:
return new AlertDialog.Builder(this)
.setTitle(R.string.wear_not_allowed_dlg_title)
.setMessage(R.string.wear_not_allowed_dlg_text)
.setPositiveButton(R.string.ok, new DialogInterface.OnClickListener() {
public void onClick(DialogInterface dialog, int which) {
setResult(RESULT_OK);
finish();
}
})
.setOnCancelListener(this)
.create();
}
return null;
}消息弹窗的主要作用，用于提示用户当前安装apk文件的特性。都知道android系统在android apk文件之前会解析器manifest文件，这个操作也是早onCreate方法中执行的：
PackageParser.Package parsed = PackageUtil.getPackageInfo(sourceFile);我们具体看一下getPackageInfo方法的实现：
public static PackageParser.Package getPackageInfo(File sourceFile) {
final PackageParser parser = new PackageParser();
try {
PackageParser.Package pkg = parser.parseMonolithicPackage(sourceFile, 0);
parser.collectManifestDigest(pkg);
return pkg;
} catch (PackageParserException e) {
return null;
}
}好吧，到了这里是不是代码变得很熟悉了？parseMonolithicPackage就是我们上一节分析的android系统解析manifest文件的过程，具体的可参考：http://blog.csdn.net/qq_23547831/article/details/51203482
而collectManifestDigest方法，我们这里简单的介绍一下，其主要是要争apk的签名是否正确。好吧通过这两部我们就把apk文件的manifest和签名信息都解析完成并保存在了Package中。
接着往下走，在所有的解析完成之后我们会在onCreate方法中执行initiateInstall();方法，刚方法的主要作用是初始化安装。
private void initiateInstall() {
String pkgName = mPkgInfo.packageName;
// Check if there is already a package on the device with this name
// but it has been renamed to something else.
String[] oldName = mPm.canonicalToCurrentPackageNames(new String[] { pkgName });
if (oldName != null && oldName.length > 0 && oldName[0] != null) {
pkgName = oldName[0];
mPkgInfo.packageName = pkgName;
mPkgInfo.applicationInfo.packageName = pkgName;
}
// Check if package is already installed. display confirmation dialog if replacing pkg
try {
// This is a little convoluted because we want to get all uninstalled
// apps, but this may include apps with just data, and if it is just
// data we still want to count it as "installed".
mAppInfo = mPm.getApplicationInfo(pkgName,
PackageManager.GET_UNINSTALLED_PACKAGES);
if ((mAppInfo.flags&ApplicationInfo.FLAG_INSTALLED) == 0) {
mAppInfo = null;
}
} catch (NameNotFoundException e) {
mAppInfo = null;
}
mInstallFlowAnalytics.setReplace(mAppInfo != null);
mInstallFlowAnalytics.setSystemApp(
(mAppInfo != null) && ((mAppInfo.flags & ApplicationInfo.FLAG_SYSTEM) != 0));
// If we have a session id, we're invoked to verify the permissions for the given
// package. Otherwise, we start the install process.
if (mSessionId != -1) {
startInstallConfirm();
} else {
startInstall();
}
}好吧，这里面有调用了startInstallConfirm方法，然后我们看一下startInstallConfirm方法的实现:
private void startInstallConfirm() {
...
//初始化安装确认界面
...
}好吧，这个方法的实现比较简单，主要的实现逻辑就是现实该activity的用户界面，平时我们安装某一个应用的时候会弹出一个安装确认页面，还有一个确认和取消按钮，有印象么？其实就是在这里执行的界面初始化操作。
好吧，一般情况下在apk安装确认页面，我们会点击确认按钮执行安装逻辑吧？那么这里我们找一下确认按钮的点击事件：
public void onClick(View v) {
if (v == mOk) {
if (mOkCanInstall || mScrollView == null) {
mInstallFlowAnalytics.setInstallButtonClicked();
if (mSessionId != -1) {
mInstaller.setPermissionsResult(mSessionId, true);
// We're only confirming permissions, so we don't really know how the
// story ends; assume success.
mInstallFlowAnalytics.setFlowFinishedWithPackageManagerResult(
PackageManager.INSTALL_SUCCEEDED);
finish();
} else {
startInstall();
}
} else {
mScrollView.pageScroll(View.FOCUS_DOWN);
}
} else if (v == mCancel) {
// Cancel and finish
setResult(RESULT_CANCELED);
if (mSessionId != -1) {
mInstaller.setPermissionsResult(mSessionId, false);
}
mInstallFlowAnalytics.setFlowFinished(
InstallFlowAnalytics.RESULT_CANCELLED_BY_USER);
finish();
}
}很明显了，这里当我们点击确认按钮的时候会执行startInstall方法，也就是开始执行安装逻辑：
private void startInstall() {
// Start subactivity to actually install the application
Intent newIntent = new Intent();
newIntent.putExtra(PackageUtil.INTENT_ATTR_APPLICATION_INFO,
mPkgInfo.applicationInfo);
newIntent.setData(mPackageURI);
newIntent.setClass(this, InstallAppProgress.class);
newIntent.putExtra(InstallAppProgress.EXTRA_MANIFEST_DIGEST, mPkgDigest);
newIntent.putExtra(
InstallAppProgress.EXTRA_INSTALL_FLOW_ANALYTICS, mInstallFlowAnalytics);
String installerPackageName = getIntent().getStringExtra(
Intent.EXTRA_INSTALLER_PACKAGE_NAME);
if (mOriginatingURI != null) {
newIntent.putExtra(Intent.EXTRA_ORIGINATING_URI, mOriginatingURI);
}
if (mReferrerURI != null) {
newIntent.putExtra(Intent.EXTRA_REFERRER, mReferrerURI);
}
if (mOriginatingUid != VerificationParams.NO_UID) {
newIntent.putExtra(Intent.EXTRA_ORIGINATING_UID, mOriginatingUid);
}
if (installerPackageName != null) {
newIntent.putExtra(Intent.EXTRA_INSTALLER_PACKAGE_NAME,
installerPackageName);
}
if (getIntent().getBooleanExtra(Intent.EXTRA_RETURN_RESULT, false)) {
newIntent.putExtra(Intent.EXTRA_RETURN_RESULT, true);
newIntent.addFlags(Intent.FLAG_ACTIVITY_FORWARD_RESULT);
}
if(localLOGV) Log.i(TAG, "downloaded app uri="+mPackageURI);
startActivity(newIntent);
finish();
}可以发现，点击确认按钮之后我们调用启用了一个新的Activity-->InstallAppProgress，这个Activity主要用于执行apk的安装逻辑了。
@Override
public void onCreate(Bundle icicle) {
super.onCreate(icicle);
Intent intent = getIntent();
mAppInfo = intent.getParcelableExtra(PackageUtil.INTENT_ATTR_APPLICATION_INFO);
mInstallFlowAnalytics = intent.getParcelableExtra(EXTRA_INSTALL_FLOW_ANALYTICS);
mInstallFlowAnalytics.setContext(this);
mPackageURI = intent.getData();
final String scheme = mPackageURI.getScheme();
if (scheme != null && !"file".equals(scheme) && !"package".equals(scheme)) {
mInstallFlowAnalytics.setFlowFinished(
InstallFlowAnalytics.RESULT_FAILED_UNSUPPORTED_SCHEME);
throw new IllegalArgumentException("unexpected scheme " + scheme);
}
mInstallThread = new HandlerThread("InstallThread");
mInstallThread.start();
mInstallHandler = new Handler(mInstallThread.getLooper());
IntentFilter intentFilter = new IntentFilter();
intentFilter.addAction(BROADCAST_ACTION);
registerReceiver(
mBroadcastReceiver, intentFilter, BROADCAST_SENDER_PERMISSION, null /*scheduler*/);
initView();
}可以发现InstallAppProcess这个Activity的onCreate方法中主要初始化了一些成员变量，并调用initView方法，我们在iniTView方法中可以看到：
void initView() {
...
mInstallHandler.post(new Runnable() {
@Override
public void run() {
doPackageStage(pm, params);
}
});
...
}经过一些view的初始化操作之后调用了doPackageStage方法，该方法主要是通过调用PackageInstaller执行apk文件的安装，这里就不在详细的介绍了，在apk文件安装完成之后PackageInstaller会发送一个安装完成的广播，刚刚我们在onCreate方法中注册了一个广播接收器，其可以用来接收apk安装完成的广播：
private final BroadcastReceiver mBroadcastReceiver = new BroadcastReceiver() {
@Override
public void onReceive(Context context, Intent intent) {
final int statusCode = intent.getIntExtra(
PackageInstaller.EXTRA_STATUS, PackageInstaller.STATUS_FAILURE);
if (statusCode == PackageInstaller.STATUS_PENDING_USER_ACTION) {
context.startActivity((Intent)intent.getParcelableExtra(Intent.EXTRA_INTENT));
} else {
onPackageInstalled(statusCode);
}
}
};这样apk安装完成之后，这里的广播接收器会接收到广播并执行onPackageInstalled方法，执行后续的处理逻辑，那么我们来看一下onPackageInstalled方法的具体实现逻辑：
void onPackageInstalled(int statusCode) {
Message msg = mHandler.obtainMessage(INSTALL_COMPLETE);
msg.arg1 = statusCode;
mHandler.sendMessage(msg);
}好吧，这里是发送Handler异步消息，我们来看一下异步消息的处理逻辑：
private Handler mHandler = new Handler() {
public void handleMessage(Message msg) {
switch (msg.what) {
case INSTALL_COMPLETE:
mInstallFlowAnalytics.setFlowFinishedWithPackageManagerResult(msg.arg1);
if (getIntent().getBooleanExtra(Intent.EXTRA_RETURN_RESULT, false)) {
Intent result = new Intent();
result.putExtra(Intent.EXTRA_INSTALL_RESULT, msg.arg1);
setResult(msg.arg1 == PackageInstaller.STATUS_SUCCESS
? Activity.RESULT_OK : Activity.RESULT_FIRST_USER,
result);
finish();
return;
}
// Update the status text
mProgressBar.setVisibility(View.INVISIBLE);
// Show the ok button
int centerTextLabel;
int centerExplanationLabel = -1;
LevelListDrawable centerTextDrawable =
(LevelListDrawable) getDrawable(R.drawable.ic_result_status);
if (msg.arg1 == PackageInstaller.STATUS_SUCCESS) {
mLaunchButton.setVisibility(View.VISIBLE);
centerTextDrawable.setLevel(0);
centerTextLabel = R.string.install_done;
// Enable or disable launch button
mLaunchIntent = getPackageManager().getLaunchIntentForPackage(
mAppInfo.packageName);
boolean enabled = false;
if(mLaunchIntent != null) {
List<ResolveInfo> list = getPackageManager().
queryIntentActivities(mLaunchIntent, 0);
if (list != null && list.size() > 0) {
enabled = true;
}
}
if (enabled) {
mLaunchButton.setOnClickListener(InstallAppProgress.this);
} else {
mLaunchButton.setEnabled(false);
}
} else if (msg.arg1 == PackageInstaller.STATUS_FAILURE_STORAGE){
showDialogInner(DLG_OUT_OF_SPACE);
return;
} else {
// Generic error handling for all other error codes.
centerTextDrawable.setLevel(1);
centerExplanationLabel = getExplanationFromErrorCode(msg.arg1);
centerTextLabel = R.string.install_failed;
mLaunchButton.setVisibility(View.INVISIBLE);
}
if (centerTextDrawable != null) {
centerTextDrawable.setBounds(0, 0,
centerTextDrawable.getIntrinsicWidth(),
centerTextDrawable.getIntrinsicHeight());
mStatusTextView.setCompoundDrawablesRelative(centerTextDrawable, null,
null, null);
}
mStatusTextView.setText(centerTextLabel);
if (centerExplanationLabel != -1) {
mExplanationTextView.setText(centerExplanationLabel);
mExplanationTextView.setVisibility(View.VISIBLE);
} else {
mExplanationTextView.setVisibility(View.GONE);
}
mDoneButton.setOnClickListener(InstallAppProgress.this);
mOkPanel.setVisibility(View.VISIBLE);
break;
default:
break;
}
}
};可以发现，当apk安装完成之后，我们会更新UI，显示完成和打开按钮，是不是和我们平时安装apk的逻辑对应上了？这时候我们可以看一下这两个按钮的点击事件。
public void onClick(View v) {
if(v == mDoneButton) {
if (mAppInfo.packageName != null) {
Log.i(TAG, "Finished installing "+mAppInfo.packageName);
}
finish();
} else if(v == mLaunchButton) {
startActivity(mLaunchIntent);
finish();
}
}好吧，比较简单，点击完成按钮，直接finish掉这个activity，点击打开，则直接调用startActivity启动安装的应用，然后直接finish自身。
总结：
代码中执行intent.setDataAndType(Uri.parse("file://" + path),"application/vnd.android.package-archive");可以调起PackageInstallerActivity；
PackageInstallerActivity主要用于执行解析apk文件，解析manifest，解析签名等操作；
InstallAppProcess主要用于执行安装apk逻辑，用于初始化安装界面，用于初始化用户UI。并调用PackageInstaller执行安装逻辑；
InstallAppProcess内注册有广播，当安装完成之后接收广播，更新UI。显示apk安装完成界面。
京东创始人刘强东和其妻子章泽天最近成为了互联网舆论关注的焦点。有关他们“移民美国”和在美国购买豪宅的传言在互联网上广泛传播。然而，京东官方通过微博发言人发布的消息澄清了这些传言，称这些言论纯属虚假信息和蓄意捏造。
日前，据博主“@超能数码君老周”爆料，国内三大运营商中国移动、中国电信和中国联通预计将集体采购百万台规模的华为Mate60系列手机。
据报道，荷兰半导体设备公司ASML正看到美国对华遏制政策的负面影响。阿斯麦（ASML）CEO彼得·温宁克在一档电视节目中分享了他对中国大陆问题以及该公司面临的出口管制和保护主义的看法。彼得曾在多个场合表达了他对出口管制以及中荷经济关系的担忧。
今年早些时候，抖音悄然上线了一款名为“青桃”的 App，Slogan 为“看见你的热爱”，根据应用介绍可知，“青桃”是一个属于年轻人的兴趣知识视频平台，由抖音官方出品的中长视频关联版本，整体风格有些类似B站。
日前，威马汽车首席数据官梅松林转发了一份“世界各国地区拥车率排行榜”，同时，他发文表示：中国汽车普及率低于非洲国家尼日利亚，每百户家庭仅17户有车。意大利世界排名第一，每十户中九户有车。
近日，一项新的研究发现，维生素 C 和 E 等抗氧化剂会激活一种机制，刺激癌症肿瘤中新血管的生长，帮助它们生长和扩散。
据媒体援引消息人士报道，苹果公司正在测试使用3D打印技术来生产其智能手表的钢质底盘。消息传出后，3D系统一度大涨超10%，不过截至周三收盘，该股涨幅回落至2%以内。
9月2日，坐拥千万粉丝的网红主播“秀才”账号被封禁，在社交媒体平台上引发热议。平台相关负责人表示，“秀才”账号违反平台相关规定，已封禁。据知情人士透露，秀才近期被举报存在违法行为，这可能是他被封禁的部分原因。据悉，“秀才”年龄39岁，是安徽省亳州市蒙城县人，抖音网红，粉丝数量超1200万。他曾被称为“中老年...
9月3日消息，亚马逊的一些股东，包括持有该公司股票的一家养老基金，日前对亚马逊、其创始人贝索斯和其董事会提起诉讼，指控他们在为 Project Kuiper 卫星星座项目购买发射服务时“违反了信义义务”。
据消息，为推广自家应用，苹果现推出了一个名为“Apps by Apple”的网站，展示了苹果为旗下产品（如 iPhone、iPad、Apple Watch、Mac 和 Apple TV）开发的各种应用程序。
特斯拉本周在美国大幅下调Model S和X售价，引发了该公司一些最坚定支持者的不满。知名特斯拉多头、未来基金（Future Fund）管理合伙人加里·布莱克发帖称，降价是一种“短期麻醉剂”，会让潜在客户等待进一步降价。
据外媒9月2日报道，荷兰半导体设备制造商阿斯麦称，尽管荷兰政府颁布的半导体设备出口管制新规9月正式生效，但该公司已获得在2023年底以前向中国运送受限制芯片制造机器的许可。
近日，根据美国证券交易委员会的文件显示，苹果卫星服务提供商 Globalstar 近期向马斯克旗下的 SpaceX 支付 6400 万美元（约 4.65 亿元人民币）。用于在 2023-2025 年期间，发射卫星，进一步扩展苹果 iPhone 系列的 SOS 卫星服务。
据报道，马斯克旗下社交平台𝕏（推特）日前调整了隐私政策，允许 𝕏 使用用户发布的信息来训练其人工智能（AI）模型。新的隐私政策将于 9 月 29 日生效。新政策规定，𝕏可能会使用所收集到的平台信息和公开可用的信息，来帮助训练 𝕏 的机器学习或人工智能模型。
9月2日，荣耀CEO赵明在采访中谈及华为手机回归时表示，替老同事们高兴，觉得手机行业，由于华为的回归，让竞争充满了更多的可能性和更多的魅力，对行业来说也是件好事。
《自然》30日发表的一篇论文报道了一个名为Swift的人工智能（AI）系统，该系统驾驶无人机的能力可在真实世界中一对一冠军赛里战胜人类对手。
近日，非营利组织纽约真菌学会（NYMS）发出警告，表示亚马逊为代表的电商平台上，充斥着各种AI生成的蘑菇觅食科普书籍，其中存在诸多错误。
社交媒体平台𝕏（原推特）新隐私政策提到：“在您同意的情况下，我们可能出于安全、安保和身份识别目的收集和使用您的生物识别信息。”
2023年德国柏林消费电子展上，各大企业都带来了最新的理念和产品，而高端化、本土化的中国产品正在不断吸引欧洲等国际市场的目光。
罗永浩日前在直播中吐槽苹果即将推出的 iPhone 新品，具体内容为：“以我对我‘子公司’的了解，我认为 iPhone 15 跟 iPhone 14 不会有什么区别的，除了序（列）号变了，这个‘不要脸’的东西，这个‘臭厨子’。
