Python实现将xml导入至excel

最近在使用Testlink时，发现导入的用例是xml格式，且没有合适的工具转成excel格式，xml使用excel打开显示的东西也太多，网上也有相关工具转成csv格式的，结果也不合人意。

那求人不如尔己，自己写一个吧

需要用到的模块有：xml.dom.minidom(python自带)、xlwt

使用版本：

python:2.7.5

xlwt:1.0.0

一、先分析Testlink XML格式：

这是一个有两级testusuit的典型的testlink用例结构，我们只需要取testsuite name,testcase name，preconditions，actions，expectedresults

二、程序如下：

    #coding:utf-8
    '''
    Created on 2015-8-20

    @author: Administrator
    '''
    '''
    '''
    import xml.etree.cElementTree as ET
    import xml.dom.minidom as xx
    import os,xlwt,datetime

    workbook=xlwt.Workbook(encoding="utf-8")
    #
    booksheet=workbook.add_sheet(u'sheet_1')
    booksheet.col(0).width= 5120
    booksheet.col(1).width= 5120
    booksheet.col(2).width= 5120
    booksheet.col(3).width= 5120
    booksheet.col(4).width= 5120
    booksheet.col(5).width= 5120

    dom=xx.parse(r'D:\\Python27\test.xml')
    root = dom.documentElement
    row=1
    col=1

    borders=xlwt.Borders()
    borders.left=1
    borders.right=1
    borders.top=1
    borders.bottom=1


    style = xlwt.easyxf('align: wrap on,vert centre, horiz center') #自动换行、水平居中、垂直居中
    #设置标题的格式，字体方宋、加粗、背景色：菊黄
    #测试项的标题

    title=xlwt.easyxf(u'font:name 仿宋,height 240 ,colour_index black, bold on, italic off; align: wrap on, vert centre, horiz center;pattern: pattern solid, fore_colour light_orange;')
    item='测试项'
    Subitem='测试分项'
    CaseTitle='测试用例标题'
    Condition='预置条件'
    actions='操作步骤'
    Result='预期结果'
    booksheet.write(0,0,item,title)
    booksheet.write(0,1,Subitem,title)
    booksheet.write(0,2,CaseTitle,title)
    booksheet.write(0,3,Condition,title)
    booksheet.write(0,4,actions,title)
    booksheet.write(0,5,Result,title)
    #冻结首行
    booksheet.panes_frozen=True
    booksheet.horz_split_pos= 1


    #一级目录
    for i in root.childNodes:
      testsuite=i.getAttribute('name').strip()
      #print testsuite
      #print testsuite
      '''
      写测试项
      '''
      print "row is :",row
      booksheet.write(row,col,testsuite,style)


      #二级目录
      for dd in i.childNodes:
        print "    %s" % dd.getAttribute('name')
        testsuite2=dd.getAttribute('name')
        if not dd.getElementsByTagName('testcase'):
          print "Testcase is %s" % testsuite2
          row=row+1
          booksheet.write(row,2,testsuite2,style)  #写测试分项

        row=row+1

        booksheet.write(row,1,testsuite2,style)
        itemlist=dd.getElementsByTagName('testcase')

        for subb in itemlist:
          #print "         %s" % subb.getAttribute('name')
          testcase=subb.getAttribute('name')

          row=row+1
          booksheet.write(row,2,testcase,style)

          ilist=subb.getElementsByTagName('preconditions')
          for ii in ilist:
            preconditions=ii.firstChild.data.replace("<br />"," ")
            col=col+1
            booksheet.write(row,3,preconditions,style)
          steplist=subb.getElementsByTagName('actions')
          #print steplist
          for step in steplist:
            actions=step.firstChild.data.replace("<br />"," ")
            col=col+1
            booksheet.write(row,4,actions,style)
          #print "测试步骤：",steplist[0].firstChild.data.replace("<br />"," ")
          expectlist=subb.getElementsByTagName('expectedresults')

          for expect in expectlist:
            result=expect.childNodes[0].nodeValue.replace("<br />","" )
            booksheet.write(row,5,result,style)


      row=row+1

    workbook.save('demo.xls')

写入excel的效果如下：

我们再来看个实例：

需要下载一个module：xlwt，如下是source code

    import xml.dom.minidom
    import xlwt
    import sys

    col = 0
    row = 0


    def handle_xml_report(xml_report, excel):
      problems = xml_report.getElementsByTagName("problem")
      handle_problems(problems, excel)


    def handle_problems(problems, excel):
      for problem in problems:
        handle_problem(problem, excel)


    def handle_problem(problem, excel):
      global row
      global col
      code = problem.getElementsByTagName("code")
      file = problem.getElementsByTagName("file")
      line = problem.getElementsByTagName("line")
      message  = problem.getElementsByTagName("message")

      for node in code:
        excel.write(row, col, node.firstChild.data)
        col = col + 1
      for node in file:
        excel.write(row, col, node.firstChild.data)
        col = col + 1
      for node in line:
        excel.write(row, col, node.firstChild.data)
        col = col + 1
      for node in message:
        excel.write(row, col, node.firstChild.data)
        col = col + 1
      row = row+1
      col = 0

    if __name__ == '__main__':
      if(len(sys.argv) <= 1):
        print ("usage: xml2xls src_file [dst_file]")
        exit(0)
      #the 1st argument is XML report ; the 2nd is XLS report
      if(len(sys.argv) == 2):
        xls_report = sys.argv[1][:-3] + 'xls'
      #if there are more than 2 arguments, only the 1st & 2nd make sense
      else:
        xls_report = sys.argv[2]
      xmldoc = xml.dom.minidom.parse(sys.argv[1])
      wb = xlwt.Workbook()
      ws = wb.add_sheet('MOLint')
      ws.write(row, col, 'Error Code')
      col = col + 1
      ws.write(row, col, 'file')
      col = col + 1
      ws.write(row, col, 'line')
      col = col + 1
      ws.write(row, col, 'Description')
      row = row + 1
      col = 0
      handle_xml_report(xmldoc, ws)
      wb.save(xls_report)
