Python使用matplotlib绘制动画的方法

本文实例讲述了Python使用matplotlib绘制动画的方法。分享给大家供大家参考。具体分析如下：

matplotlib从1.1.0版本以后就开始支持绘制动画

下面是几个的示例：

第一个例子使用generator，每隔两秒，就运行函数data_gen：

    # -*- coding: utf-8 -*-
    import numpy as np
    import matplotlib.pyplot as plt
    import matplotlib.animation as animation
    fig = plt.figure()
    axes1 = fig.add_subplot(111)
    line, = axes1.plot(np.random.rand(10))
    #因为update的参数是调用函数data_gen,
    #所以第一个默认参数不能是framenum
    def update(data):
      line.set_ydata(data)
      return line,
    # 每次生成10个随机数据
    def data_gen():
      while True:
        yield np.random.rand(10)
    ani = animation.FuncAnimation(fig, update, data_gen, interval=2*1000)
    plt.show()

第二个例子使用list（metric），每次从metric中取一行数据作为参数送入update中：

    import numpy as np
    import matplotlib.pyplot as plt
    import matplotlib.animation as animation
    start = [1, 0.18, 0.63, 0.29, 0.03, 0.24, 0.86, 0.07, 0.58, 0]
    metric =[[0.03, 0.86, 0.65, 0.34, 0.34, 0.02, 0.22, 0.74, 0.66, 0.65],
         [0.43, 0.18, 0.63, 0.29, 0.03, 0.24, 0.86, 0.07, 0.58, 0.55],
         [0.66, 0.75, 0.01, 0.94, 0.72, 0.77, 0.20, 0.66, 0.81, 0.52]
        ]
    fig = plt.figure()
    window = fig.add_subplot(111)
    line, = window.plot(start)
    #如果是参数是list,则默认每次取list中的一个元素,
    #即metric[0],metric[1],...
    def update(data):
      line.set_ydata(data)
      return line,
    ani = animation.FuncAnimation(fig, update, metric, interval=2*1000)
    plt.show()

第三个例子：

    import numpy as np
    from matplotlib import pyplot as plt
    from matplotlib import animation
    # First set up the figure, the axis, and the plot element we want to animate
    fig = plt.figure()
    ax = plt.axes(xlim=(0, 2), ylim=(-2, 2))
    line, = ax.plot([], [], lw=2)
    # initialization function: plot the background of each frame
    def init():
      line.set_data([], [])
      return line,
    # animation function. This is called sequentially
    # note: i is framenumber
    def animate(i):
      x = np.linspace(0, 2, 1000)
      y = np.sin(2 * np.pi * (x - 0.01 * i))
      line.set_data(x, y)
      return line,
    # call the animator. blit=True means only re-draw the parts that have changed.
    anim = animation.FuncAnimation(fig, animate, init_func=init,
                    frames=200, interval=20, blit=True)
    #anim.save('basic_animation.mp4', fps=30, extra_args=['-vcodec', 'libx264'])
    plt.show()

第四个例子:

    # -*- coding: utf-8 -*-
    import numpy as np
    import matplotlib.pyplot as plt
    import matplotlib.animation as animation
    # 每次产生一个新的坐标点
    def data_gen():
      t = data_gen.t
      cnt = 0
      while cnt < 1000:
        cnt+=1
        t += 0.05
        yield t, np.sin(2*np.pi*t) * np.exp(-t/10.)
    data_gen.t = 0
    # 绘图
    fig, ax = plt.subplots()
    line, = ax.plot([], [], lw=2)
    ax.set_ylim(-1.1, 1.1)
    ax.set_xlim(0, 5)
    ax.grid()
    xdata, ydata = [], []
    # 因为run的参数是调用函数data_gen,
    # 所以第一个参数可以不是framenum:设置line的数据,返回line
    def run(data):
      # update the data
      t,y = data
      xdata.append(t)
      ydata.append(y)
      xmin, xmax = ax.get_xlim()
      if t >= xmax:
        ax.set_xlim(xmin, 2*xmax)
        ax.figure.canvas.draw()
      line.set_data(xdata, ydata)
      return line,
    # 每隔10秒调用函数run,run的参数为函数data_gen,
    # 表示图形只更新需要绘制的元素
    ani = animation.FuncAnimation(fig, run, data_gen, blit=True, interval=10,
      repeat=False)
    plt.show()

再看下面的例子:

    # -*- coding: utf-8 -*-
    import numpy as np
    import matplotlib.pyplot as plt
    import matplotlib.animation as animation
    #第一个参数必须为framenum
    def update_line(num, data, line):
      line.set_data(data[...,:num])
      return line,
    fig1 = plt.figure()
    data = np.random.rand(2, 15)
    l, = plt.plot([], [], 'r-')
    plt.xlim(0, 1)
    plt.ylim(0, 1)
    plt.xlabel('x')
    plt.title('test')
    #framenum从1增加大25后,返回再次从1增加到25,再返回...
    line_ani = animation.FuncAnimation(fig1, update_line, 25,fargs=(data, l),interval=50, blit=True)
    #等同于
    #line_ani = animation.FuncAnimation(fig1, update_line, frames=25,fargs=(data, l),
    #  interval=50, blit=True)
    #忽略frames参数,framenum会从1一直增加下去知道无穷
    #由于frame达到25以后,数据不再改变,所以你会发现到达25以后图形不再变化了
    #line_ani = animation.FuncAnimation(fig1, update_line, fargs=(data, l),
    #  interval=50, blit=True)
    plt.show()

希望本文所述对大家的python程序设计有所帮助。
